  • Page 1 User's manual A-OK of an motor...
  • Page 2 1. Connection scheme: - Connection scheme of the radio controlled motor and a switch Phase N Neutral/ blue Neutral Top/ black Protective conductor Bottom/ brown Protective conductor / yellow and green Power socket Motor If the motor directions are reversed, the location of the black and brown wires shall be respectively changed.
  • Page 3 3. Resetting the end-limit switch positions and the motor: 1. On the somfy remote control, simultaneously press the WT and DOWN buttons. 2. Release the WT button, pressing and holding the DOWN button. 3. After one 1 second, press and hold the WT button again and press and hold for about 3 seconds both buttons - the double UP/DOWN motor movement will confirm successful performance of the operation.
  • Page 4 WARNING - FOR THE SAFETY OF PEOPLE, IT IS IMPORTANT TO FOLLOW THESE USER'S INTRUCTIONS. KEEP THESE USER'S MANUAL AT ALL TIMES. PORTOS TR7 spółka z ograniczoną odpowiedzialnością s. k.
