- Page 1 TROUBLESHOOTING GUIDE TROUBLESHOOTING GUIDE...
- Page 2 Designed with the pool owner in mind Designed with the pool owner in mind Control box • One pipe to cut and glue Replaceable electrolysis • Unique sliding slots for quick cartridge cartridge removal (no need to remove the entire Built in temperature &...
-
Page 3: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING... -
Page 4: Before Troubleshooting
Before Troubleshooting Before Troubleshooting 1. Check that the salinity in the pool water is above 2400 PPM. 2. Check for scale buildup on the cartridge and clean it if necessary. 3. Disconnect the plug, Dismantle the power box, connect the plug and check that all the LED is on for 1 sec. - Page 5 NO FLOW NO FLOW LED “no flow” Turns On When: Flow switch paddle is centered Gas bubbles And / OR There are air bubbles in the salinity sensor Possible Causes What to do This may happen if there is air in the pipe lines or for a few minutes at initial startup.
- Page 6 LOW SALT LED LOW SALT Turns On when: Measured water salinity levels are below 2400 ppm Possible Causes What to do Manually check the salinity of the pool water with a stick. If needed, Not enough salt in pool water add salt according to the salinity table in the installation manual Visually inspect the cartridge for lime-scale.
-
Page 7: Cold Water
COLD WATER COLD WATER LED Turns On when: Measured Water temperature is below 68 ° F – When below 68 ° F/ 20 ° c - max. chlorine output level – 50% When below 59 F/ 15 c - max. chlorine output level – 25% °... - Page 8 CLEAN CELL CLEAN CELL LED Turns On when: Chlorine output level doesn’t reach the set point and the following parameters are OK: - Salinity levels above 2400 ppm - Water temperature above 68 °F Possible Causes What to do Scale build-up inside the cartridge Clean cartridge, refer to relevant chapter in manual or appropriate YouTube video Low salinity...
- Page 9 CELL LIFE LOW CELL LIFE LOW LED Turns On when: Cell operating hours above 8000, Chlorine output level doesn’t reach the set point and the following parameters exist: - Salinity levels above 2400 ppm - Temperature water above 68 °F Possible Causes What to do Scale build-up inside the cartridge...
- Page 10 SYSTEM ERROR (blinking) LED SYSTEM ERROR (blinking) LED LED is Blinking when: No communication is detected between the cartridge and control box Possible Causes What to do Assemble correct refer to relevant chapter in “clean cartridge” Incorrect assemble of the power box YouTube video Debris is stuck in the electrical Clean cartridge, refer to relevant chapter in manual or appropriate...
- Page 11 SYSTEM ERROR (constant) LED SYSTEM ERROR (constant) LED Turns on when: The control box can’t deliver power (current) to the cartridge. Possible Causes What to do Salinity High, too much salt has been Test salt levels in pool water, if high, it is recommended to drain part added of the pool water and refill with fresh water Low salt levels...
- Page 12 No Display (power supply does not turn on) No Display (power supply does not turn on) Possible Causes What to do System is turned off Turn the system on Power supply is disconnected Connect the plug into socket Unit should be wired in such a way that it operates only when the Circulation pump is off circulation pump is on, verify that pump is in fact operating Other malfunction in the unit...
- Page 13 Chlorine Output levels does not reach 100% Chlorine Output levels does not reach 100% Possible Causes What to do Display (LED) Press the "+" button to set the output level Output level set too low to a higher setting Low pool water temperature In case Cold Water LED is on refer to slide 9 Not enough salt due to heavy rain, In case Low Salt LED is on, refer to the Low...
- Page 14 LEAKING LEAKING Possible Causes What to do Tight the nut Side/Top nut leaking Replace the O-ring TOP NUT CRACKED/BROKEN TOP NUT CRACKED/BROKEN Possible Causes What to do Production problem – Old version Replace control box and the O-ring to the latest version...
- Page 15 Thank you! Thank you!
