BK TECHNOLOGIES BKR0701 User Instructions

Cloning cable
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

BKR0701 Cloning Cable
User Instructions
Contents
Operation ..............................................................................................1
Source Radio .......................................................................................2
....................................................................................4
Cloneable Information .........................................................................5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BKR0701 and is the answer not in the manual?

Questions and answers

Related Manuals for BK TECHNOLOGIES BKR0701

Summary of Contents for BK TECHNOLOGIES BKR0701

  • Page 1 BKR0701 Cloning Cable User Instructions Contents Operation ....................1 Source Radio ..................2 Target Radio ..................4 Cloneable Information .................5...

  • Page 3: Operation

    Operation The BKR0701 Cloning Adaptor offers radio users the ability to share programmed information between BKR portable and KNG portable radios. For proper operation, the BKR0701 Cloning Adaptor must be used in conjuction with the KAA0700 Cloning Cable. For BKR to KNG cloning, one BKR0701 Cloning Adaptor and one...

  • Page 4: Source Radio

    Source Radio On the Source radio select the zone with the information to be cloned by pressing the Zone button, or selecting “Zone Select” from the menu, then entering the number of the desired zone. On the Target radio select the Zone or Group to which the information is to be sent.
  • Page 5 Receiving Information Target radios display a message to indicate receiving incoming information. Destination Clone Target radios display “Destination Clone Start” Start during the cloning process. When the cloning process is successfully completed, the Target radio will automatically shut down and reset. NOTE: Upon reset the Target radio reverts to Zone 1.

  • Page 6: Target Radio

    Target Radio To clone to a BKR or KNG radio, it must be put in “Destination Clone Mode.” The BKR and KNG radio can only receive “Active Zone” or “Picklist” clone information. On the target radio: Cloning 1. Select the Menu button. 1: Label 1 Clone Active Zone Clone Picklists...

  • Page 7: Cloneable Information

    Cloneable Information Cloning Information The Source radio sends only information the Target radio requires. Channel Capacity Considerations When a BKR Source zone is programmed with less channels than a Target radio, channels about the highest programmed Source channel will be set to inactive. A Target zone will assume the channel structure of the Source radio.
  • Page 8 Cloned Picklist Values Source radio Default values and Default values and Tone selected Picklist references Picklist references No tone selected Default values Default values If the cloning process fails or the Target radio’s zone is blocked from accepting an incoming clone, a fail message will appear on the Source radio.
