Summary of Contents for THORENS TD 190
- Page 2 Thorens Factory Warranty Technical Specification Unpacking and Assembly Electrical Connections and Installation Tonearm and Pickup Cartridge Vertical alignment of cartridge Operation of the TD 190_E...
- Page 3 If the original shipping box is no longer in your possession your THORENS representative will be in the position to supply a new one for a small charge. Shipping costs to THORENS or to an authorized service centre must be prepaid because otherwise the parcel will be rejected upon arrival.
- Page 4 Measured values = typical values electronic2controlled DC motor 100 – 240 V (AC) (Mains set) & 50 / 60 Hz & 1,5 W , 45 , 78 U / min (DIN/WRMS) ± 0,07/0,04 % Ø 304 mm (DIN 45 500) Rumble unweighted signal2to2noise ratio 46 dB Rumble weightes signal2to noise ratio...
- Page 5 Fig. 1 Fig. 2 Fig. 3 By choosing the appropriate THORENS mains transformer this record player can be operated from nearly all existing public mains supplies. The low2voltage plug on the cable that is coming from the mains transformer unit is to be inserted into jack 17 (Fig.
- Page 6 '> ' ( ,2 ( Turn the tracking force adjuster ( ) to "0" and the anti2skating knob (?) counter2clockwise until it stops (Fig. 6). Screw the tonearm counter weight (7) onto the rear tonearm tube (Fig. 5). Unlock the tone arm (@) and move it a bit towards the centre of the platter.
- Page 7 In order to playback vintage shellac records (78's) with optimal results the original stylus should be exchanged with a suitable special stylus for shellacs. Please consult your THORENS dealer for further information and details. Fig. 9 TD 190_E...
- Page 8 With the knob on the left the speed can be set at 33, 45 und 78rpm (Fig. 10) With the button (A) on the right near the tone arm, the diameter of the records can be pre2set, whereby 17 cm is used for "Single" and 30 cm for "Long Play (LP)"...
- Page 9 Thorens Export Company Ltd. Im Hübel 1, CH-4304 Giebenach – Basel / Switzerland Tel. ++41 (0) 61 – 8 13 03 37 Fax Tel. ++41 (0) 61 – 8 13 03 39 Internet: http://www.thorens.ch, Email: info@thorens.ch TD 190_E...
