SAS Sleep System
1
1 Open the kit and remove and tear open Nox Medical Bag 1.
4
4. Remove the A1 device and place the neck band around your
neck.
2
Right
Left
2. Open 1 alcohol swab and clean the 4 areas on the torso
indicated in the image. Apply 1 single snap electrode to each
cleaned area.
5
5. Connect the red and blue body cables to the body cable
connector.
3
Alcohol
swab
x4
Right
3. Place the left (red) body cable inside the neck opening of your
sleepwear and snap the cables to the electrodes on the left side of
the body. Repeat with the right (blue) body cable.
6
6. Apply the chest belt (red triangle) first, and then apply the
abdomen belt (yellow diamond).
x4
Left
