WIS -EAP510-OUTDOOR Quick Installation Manual

Outdoor ap
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Quick Installation Guide
OUTDOOR AP
WIS-EAP510-OUTDOOR
WIS-EAP520-OUTDOOR
www.wisnetworks.in

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WIS-EAP510-OUTDOOR and is the answer not in the manual?

Questions and answers

Related Manuals for WIS WIS-EAP510-OUTDOOR

Summary of Contents for WIS WIS-EAP510-OUTDOOR

  • Page 1 Quick Installation Guide OUTDOOR AP WIS-EAP510-OUTDOOR WIS-EAP520-OUTDOOR www.wisnetworks.in...

  • Page 2: Device Installation

    Device installation (1)、Make sure the device is power off (2)、Follow Figure 1 ,insert clamp hoop into the hole on backside of the enclosure (3)、Fasten the AP to the pole(diameter 40-60mm) with clamp hoop,after confirming the angle and direction ,use screwdriver to fix the clamp hoop tightly. Hardware connection (1)、AP connects to the POE port of POE adapter through LAN cable(make sure the impedence of the LAN cable wires should be less than 6 Ω)
  • Page 3 Figure 1 Figure 2 Figure 3...
  • Page 4 (2)、After setting the IP address of PC, connect PC with AP in wireless, double-click "Wireless network Connection", in the pop-up wireless SSID list, select "Wireless 2.4G", click "Connect", then enter the password in the pop-up password dialogue box, the default password is "66666666", click "OK" to connect. WIS 2.4...
  • Page 5 Connect PC by wired port Using the wired connection, set the IP address of the TCP/IP properties of the wired network card to 192.168.2.2.X (X is number range of 2-252), and the PC will be the same IP segment as AP.
  • Page 6 WEB Login from PC Input password Login 2.By default it is in Fit AP mode, users need click the button at the right corner to change it to FAT AP mode if needed. Fit AP Information IP Address 192.168.2.2 Subnet 255.255.255.0 Mac Address 44:D1:FA:75:BF:3F...
  • Page 7 3.In FAT AP mode user interace home page is as shown below: Operation Mode AP Mode Fat AP Flow(2G Wifi)bps Home Wizard WIFI Uptime 01:05:39 Network Device Information Device Description LAN Information WIFI Information IP Mode Get IP From AC Status Lan IP 192.168.2.2...
  • Page 8 5. Enter AP Mode setup page,choose “Get IP from AC” in connection type, click Next. AP Mode √ LAN Settings IP Mode Get IP From AC Static IP Get IP From AC Get IP From Gateway Next 6. Enter Wifi setup page,set up SSID, Channel, Encryption parameters as below: AP Mode √...
  • Page 9 AP Mode √ 5G WIFI Setting WifiStatus SSID Wireless5.8G Hide your SSID? Channel Encrypt Encruption Password 66666666 Timing Back Next Click Next and setup completed AP模式 AP Mode √ Have completed your configuration！...

  • Page 10: Wireless Testing

    Wireless testing Use Laptop or mobile phone to test whether the wireless network can surf the Internet: click wireless network , select the wireless SSID, enter the password to connect the wireless AP, test whether you can surf the Internet. 192.168.2.2 192.168.2.2 Check the status of the wireless network connection: signal quality, speed, Bytes sent...

  • Page 11: Wisp Mode

    Other mode Current Mode Gateway Repeater Mode WISP Mode AP Mode Gateway Mode Realize router function, WAN port connect with modem (ADSL or Fiber) , or WAN port connect internet by dynamic or static IP type. Repeater mode Realize wireless bridge and forwarding without compatibility matching with the upper device.

  • Page 12: Device Management

    Device Management Users can backup,reboot and reset to factory default settings through device management menu options. Also you can modify the WEB login password, upgrade firmware, time synchronization and system log statistics and other functional settings as shown in picture below. Configure Reboot Modify Password...
  • Page 13 Use mobile phone to login Mobile phone login web page of AP (default password is admin)
  • Page 14 When mobile phone connect to AP through wireless, need to configure static IP according to below steps Android system setup steps How to set static IP for Android system mobile phone Open the phone click "settings", choose "WLAN" , find and long press the SSID of the AP, pop-up menu select "Static IP", set a static IP 192.168.2.X (X can not be 253 or 252) (the static IP should be same IP segment as AP) for mobile phone, then input the right Gateway IP, network mask and DNS.
  • Page 15 ISO system setup steps How to set static IP for IOS system mobile phone Click "settings", choose "Wi-Fi", click exclamation mark after connect wireless signal successfully, setup the static IP 192.168.188.X(X can not be 253 or 252), then input gateway IP, subnet mask and DNS, please note: the static IP should be in the same IP segment as AP.

  • Page 16: Faq And Solutions

    FAQ and Solutions Q1: Forget login name and password ? A1: Reset to factory default settings: press the reset button for above 10 seconds and release it , the device will reboot and reset to factory default settings automatically. Q2: Can not Login wireless AP management WEB interface ? A2: 1.Check if PC with static IP and if this IP is in the same IP segment of AP, make sure it is not set to other IP range.

This manual is also suitable for:

Wis-eap520-outdoor
