  • Page 1 STEREO-ZOOM-MICROSKOPE OPERATING INSTRUCTIONS Lampert Tools USA, Inc. 115 V...
  • Page 3 Requirements” and “Personal Protection” before use. Note on Symbols The equipment manufactured by “Lampert Tools GmbH“ fulfil the standard requirements of CE certification and are manufactured according to VDE guidelines. The arc welding filter is in conformity with the “Practice For Occupational And Educational Eye And Face Protection”...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS SECTION 1 – GENERAL APPLICATION ........SECTION 2 –...
  • Page 5: Section 1 - General Application

    SECTION 1 – GENERAL APPLICATION Proper Use of the PUK Microscope includes: • Observation of welding processes through the Microscope Shutter and workspace lighting. • The PUK Microscope may only be used in combination with PUK precision welding machine • The PUK Microscope may only be used when properly connected.
  • Page 6: Section 3 - General Safety Instructions - Read Before Using

    SECTION 3 – GENERAL SAFETY INSTRUCTIONS - READ BEFORE USING 3-1. SAFETY INSTRUCTIONS • from the mains. In the case of more complex Opening the device is permitted only by activity where you must leave the work area – trained experts. Before opening the device, even for a short time –...
  • Page 7: Principal Safety Standards

    4-2. Principal Safety Standards Safety in Welding, Cutting, and Allied Processes, ANSI Standard Z49.1, from American Welding Society, 550 N.W. LeJeune Rd, Miami FL 33126 (phone: 305-443-9353, website: www.aws.org). Recommended Safe Practices for the Preparation for Welding and Cut-ting of Containers and Piping, American Welding Society Standard AWS F4.1, from American Welding Society, 550 N.W.
  • Page 8: Section 5 - Operation And Instructions

    SECTION 5 – OPERATION AND INSTRUCTIONS 5-1. UNPACKING All stereo microscope components have been packaged carefully so that you can receive them in perfect condition. We recommend that you keep the packaging material. It may be required again should you have to send in the microscope or wish to store it for a longer period, or whenever the mircoscope needs to be transported to a technical customer service center for maintenance or repair.
  • Page 9: Description Of The Operating Elements

    5-3. DESCRIPTION OF THE OPERATING ELEMENTS (Figure 1) 10. Head 11. Zoom knob Eyepiece Diopter regulator 12. Lighting cable Eyepiece tubes 14. Lighting adjustment knob 4.Prisma casing 15. Focus knob Attachment holder adjustment knob 16. Head support screw 25. face protector 17.
  • Page 10: Operation

    (Figure 2) 5-4. Operation A. First steps The lighting switch is located on the microscope cable. 1. Turn on the main switch (22). 2. The angle of the lighting can be set using the adjustment knob (14) which can be used to change the lens direction.
  • Page 11: Section 6 - Care And Maintenance

    d. Slide the adjusting ring (18) back up towards the attachment support and fasten the ring tightly. Now the attachment can be released. e. It is not necessary to reset the attachment each time an object is changed, unless the object extends beyond the focus range. 5.
  • Page 12: Maintenance Of Optic Components

    6-2. Maintenance of optic components Do not disassemble optic components. Please contact your local customer technical sevice to handle repairs not covered by these instructions. Before cleaning the lens surface, first remove dust using a special brush or pressurized air. Suitable cleaning tools may be purchased from any camera shop.
  • Page 13: Section 7 - Problem Correction

    (Figure 3) 17. Attachment support 15. Focus head SECTION 7 – PROBLEM CORRECTION 7-1. PROBLEMS WITH ELECTRICAL COMPONENTS PROBLEM CAUSE SOLUTION The lamp does not work. Electrical socket not working. Have professionally repaired. Cable not connected. Plug mains cable into socket. Lamp burnt out.
  • Page 14: Section 8 - Transporting The Microscope And Repairs

    SECTION 8 – TRANSPORTING THE MICROSCOPE AND REPAIRS 8-1. Transporting the microscope • Avoid moving the stereo microscope as much as possible. • Carry the microscope with both hands. Hold the tripod column (19) with one hand and use the other hand to hold the base (9).
  • Page 15: Section 10 - Warranty

    DUE TO POSSIBLE MODIFICATIONS OR IMPROVEMENTS DURING PRODUCTION, STEREO MICROSCOPES MAY BE CHANGED WITHOUT NOTICE. Text and figures are those available at the time of printing. Subject to change. SECTION 11 – CONTACT Lampert Tools USA, Inc. 67 East Madison, #512 Chicago, IL 60603 Phone: 1-866-4-PUK111 (1-866-478-5111) Fax: 1-312-641-2678 info@lampertusa.com...
