InPlay NanoBeacon™ IN100 Development Kit User Manual Contents About Documentation ................... 3 1. General Description ................. 4 2. Hardware Description ................6 3. Schematic ....................9 4. Revision History ..................10 5. Legal Disclaimer..................10 1 / 10... - Page 3 InPlay NanoBeacon™ IN100 Development Kit User Manual List of Figures FIGURE 1：DEVELOPMENT KIT ..................4 FIGURE 2：DEVELOPMENT BOARD................. 5 FIGURE 3：PROGRAMMER BOARD .................. 5 FIGURE 4：PROGRAMMER BOARD .................. 6 FIGURE 5：PROGRAMMER BOARD .................. 8 FIGURE 6：DEVELOPMENT KIT SCHEMATIC ..............9...
-
Page 4: About Documentation
InPlay NanoBeacon™ IN100 Development Kit User Manual About Documentation InPlay NanoBeacon™ IN100 Development Document Name Kit User Manual Part number IN1BN-DKC0-100-C0 Control Number IN1EDOC-HW-IN1BN-EN-V1_0 External User Revision V1.0 Product Status Document Content Data Status In Development Target specification / MRD... -
Page 5: General Description
InPlay NanoBeacon™ IN100 Development Kit User Manual 1. General Description IN1BN-DKC0-100-C0 is an InPlay NanoBeacon development kit that includes 3 IN100 evaluation boards and a programming board. The development kit provides all the I/Os available on IN100 (QFN18 package) that allow users to easily connect peripheral devices such as sensors, and by connecting the RF cables using SMA, users can evaluate the RF performance more accurately. -
Page 6: Figure 2：Development Board
InPlay NanoBeacon™ IN100 Development Kit User Manual Development Board NanoBeacon IN100 SoC chipset ⚫ SMA Connector ⚫ System current measurement jumper ⚫ Power supply source selection: Coin Battery / ⚫ External power supply / Programmer board Figure 2：Development Board Programmer Board OTP power switch ⚫... -
Page 7: Hardware Description
InPlay NanoBeacon™ IN100 Development Kit User Manual 2. Hardware Description Figure 4：Programmer Board Development board Key Connectors Definition Designator Function Description Pin number Pin name Description Connect to IN100 Chip_En pin, Pull low to Reset disable the chip, Pull up to enable the chip... - Page 8 InPlay NanoBeacon™ IN100 Development Kit User Manual Pin number Pin name Description VDDQ OTP (eFuse) programming voltage supply MGPIO4 IN100 MIX signal GPIO GPIO3 IN100 digital signal GPIO Connector for IOs GPIO2 IN100 digital signal GPIO and power Power ground...
-
Page 9: Figure 5：Programmer Board
InPlay NanoBeacon™ IN100 Development Kit User Manual Figure 5：Programmer Board Key Connectors Definition Designator Function Description Disconnect UART between IN100 and PC when jumper not J6,J7 PC UART Jumpers installed Uart Interface UART for external PC -On: eFuse programming, J2 pin2(FUSE) output 3.3V and connect to IN100 VDDQ. -
Page 10: Schematic
InPlay NanoBeacon™ IN100 Development Kit User Manual 3. Schematic Figure 6：Development Kit Schematic 9 / 10... -
Page 11: Revision History
(or inability to use) this document, or from your use of (or failure to use) the information on this document. InPlay Inc and its company logo are registered trademarks of InPlay Inc with its registered office at 1 Technology Drive, STE J728, Irvine, CA, USA 92618.
