- Page 1 InPlay NanoBeacon™ IN100 Development Kit User Manual Specifications and information are subject to change without notice.
-
Page 2: Table Of Contents
InPlay NanoBeacon™ IN100 Development Kit user manual Contents About Documentation ................... 3 General Description ................4 Hardware Description ................6 Schematic ..................... 10 Revision History ..................11 Legal Disclaimer ..................11 1 / 11... - Page 3 InPlay NanoBeacon™ IN100 Development Kit user manual List of Figures Figure 1：Development Kit ....................4 Figure 2：Development board ..................5 Figure 3：Programmer board ................... 5 Figure 4：Development board ..................6 Figure 5：Programmer board ................... 9 Figure 6：Development Kit schematic ................10...
-
Page 4: About Documentation
InPlay NanoBeacon™ IN100 Development Kit user manual About Documentation InPlay NanoBeacon™ IN100 Document name Development Kit user manual Part number IN1BN-DKC0-100-C0 Control number IN1IDOC-HW-IN1BN-EN-V1_01 External user Revision V1.01 Product status Document content Data status In development Target specification / MRD... -
Page 5: General Description
InPlay NanoBeacon™ IN100 Development Kit user manual 1. General Description IN1BN-DKC0-100-C0 is an InPlay NanoBeacon development kit that includes three IN100 development boards and one programmer board. The development kit provides all the I/Os available on IN100 (QFN18 package) that allow users to easily connect peripheral devices such as sensors, and by connecting the RF cables using SMA, users can evaluate the RF performance more accurately. -
Page 6: Figure 2：Development Board
InPlay NanoBeacon™ IN100 Development Kit user manual Development Board NanoBeacon IN100 SoC device ⚫ 3.5mm SMA male RF connector ⚫ Device I/O pins ⚫ Reset button ⚫ CR1220 coin cell battery socket ⚫ Power supply source selection switch : On-board coin cell Battery / ⚫... -
Page 7: Hardware Description
InPlay NanoBeacon™ IN100 Development Kit user manual 2. Hardware Description Figure 4：Development board Development board Connectors/Pins/Jumpers/Button Definition Designator Function Description Pin # Pin name Description VDDQ OTP (eFuse) memory programming power pin MGPIO7 IN100 mixed-signal GPIO System power supply, connected to the VCC pin of the... - Page 8 InPlay NanoBeacon™ IN100 Development Kit user manual Designator Function Description Pin # Pin name Description No connect OTP (eFuse) memory programming power pin VDDQ Power On/Off controlled by S1 Power supply, controlled by SW1 Connector Power supply, controlled by SW1...
- Page 9 InPlay NanoBeacon™ IN100 Development Kit user manual Designator Function Description External power supply ( 1.1~3.6V input). External power When this power supply is available, keep no coin cell supply battery installed and switch the programmer board SW1 to OFF. - For normal operation, a jumper needs to be installed - For current measurement •...
-
Page 10: Figure 5：Programmer Board
InPlay NanoBeacon™ IN100 Development Kit user manual Figure 5：Programmer board Programmer board Connectors/Pins/Jumpers/Button Definition Designator Function Description PC UART interface The UART between the device (IN100) and PC is disconnected J6, J7 jumpers when no jumpers are installed. USB interface Micro USB female connector for connecting with a PC OTP memory power supply switch. -
Page 11: Schematic
InPlay NanoBeacon™ IN100 Development Kit user manual 3. Schematic Figure 6：Development Kit schematic 10 / 11... -
Page 12: Revision History
(or inability to use) this document, or from your use of (or failure to use) the information on this document. InPlay Inc and its company logo are registered trademarks of InPlay Inc with its registered office at 1 Technology Drive, STE J728, Irvine, CA, USA 92618.
