Page 1: Operating Instructions
2.4 GHz WIRELESS VIDEO SECURITY SYSTEM Before operating the unit, please read this manual thoroughly This product broadcasts over public airwaves and its video and audio signals may be intercepted without your consent. OPERATING INSTRUCTIONS Rev 03/01-1... -
Page 2: Specifications
SPECIFICATIONS WIRELESS CAMERA Image sensor CMOS Lens 3.6mm 510 x 492 (Color), 320X240 (B&W) Picture Elements 2:1 interlace Scanning system 15.734 KHz(H) 59.94Hz (V) Scanning frequency Internal Negative synchronization Sync. system 240 Lines (B&W), 380 Lines (color) Resolution 0 Lux (B&W) 2 Lux (Color) Min. - Page 3 SYSTEM INCLUDES System includes 1- Wireless Camera with camera stand 1- 5.5” Monitor 1 – Battery Compartment (for Camera) 1 - Battery Compartment (for monitor) 2- AC Adapters --12 V DC 500mA Adapter (Camera) --13.5 V DC 1000mA Adapter (Monitor) 1- RCA A/V Cables 1- Owner's Manual/Warranty Card Screws and Anchors...
- Page 4 TROUBLE SHOOTING If the system does not function properly, check the following points. Causes and remedies Problems Camera No power - AC adapter not plugged (no picture/sound) - Power switch not turned - AC adapter not plugged Poor reception - Power switch not turned -Strong spot light in the Picture flickering field of view...
- Page 5 OPTIONAL ACCESSORIES The following optional accessories are available to add to your existing system Accessory Camera - Used to view other camera locations (Available in B&W and Color). For Information on accessories please contact sales@kingavon.co.uk 7. DAMAGE REQUIRING SERVICE - Unplug this product from the wall outlet and refer servicing or repairs to qualified service personnel under the following conditions：...
- Page 6 OPERATION USING SYSTEM WITH MORE THAN ONE CAMERA Monitor AC Adapter or plug from RCA CABLES Battery Case Connections Connect the supplied audio/video cable from the back of the monitor to the Audio/Video In of the VCR. Did you know? You have the option of connectiing this system to a Time Lapse VCR.
- Page 7 MULTIPLE CHANNEL OPERATION AUTO AND MANUAL VIEWING OPTIONS This system is preset to Manual mode, with a dwell mode of 2 seconds. In Auto mode, the LED light will be ON. To manually view a specific camera location, press the Auto/Manual button.
- Page 8 MULTIPLE CHANNEL OPERATION USING SYSTEM WITH MORE THAN ONE CAMERA This video security system allows you to view up to four different camera locations. When connecting more than one camera to the monitor/camera system, you will need to set each camera to a different channel (Channels 1-4).
- Page 9 INSTALLATION CAMERA Ensure the power switch on the monitor and camera are set to NOTE the OFF position before proceed following steps. Camera (1) Connect the power adapter to the camera power input and ensure the camera is turned ‘ON’ Ensure the camera is set to channel 1 Monitor (1) Connect the supplied power adapter to the power input of the monitor OR connect the DC plug from the battery box to the DC input jack at the back of the monitor...
- Page 10 2. INSTALLATION MONITOR DC INPUT Jack 1.Connect the supplied AC adapter to the DC INPUT JACK at the rear of the receiver monitor and plug it into the 120V electrical outlet. 1a. Connect the DC Plug from Battery Case to the DC INPUT JACK at the rear of the Receiver Monitor.
