Product Specification and User Manual
Originator
Guy Gingras
Last modified
Guy Gingras
Release
Modifications
1
Initial Release – Based on 1001114151-06
2
Modification to FCC / IC statement
Product Specification and User Manual
RFID GEN3 System
ORIGIN
RELEASE HISTORY
CONFIDENTIAL
Date
2022-09-14
Date
2022-10-14
Date
Changes made by
2022-09-14
Guy Gingras
2022-10-14
Guy Gingras
RFID GEN3 System
Page 1 of 34

Advertisement

Table of Contents
loading

Summary of Contents for Kongsberg 1001316154

  • Page 1 Product Specification and User Manual RFID GEN3 System Product Specification and User Manual RFID GEN3 System ORIGIN Originator Guy Gingras Date 2022-09-14 Last modified Guy Gingras Date 2022-10-14 RELEASE HISTORY Release Modifications Date Changes made by Initial Release – Based on 1001114151-06 2022-09-14 Guy Gingras Modification to FCC / IC statement...
  • Page 2: Table Of Contents

    Product Specification and User Manual RFID GEN3 System Contents Contents .......................... 2   Figures ..........................4   Tables ..........................5   Manufacturer Information ....................6   FCC Compliance Statement .................... 7   FCC SAR Statement ....................... 7   ISED Compliance Statement ................... 8  ...
  • Page 3 Product Specification and User Manual RFID GEN3 System Metallic Materials....................26     Noise Sources Identifications ................27     Diagnostic Tool ....................... 28     CAN Variant ...................... 28     MOWP Variant ....................29     Performance Criteria ..................33  ...
  • Page 4: Figures

    Product Specification and User Manual RFID GEN3 System Figures Figure 1: RFID Key and Post System ................15   Figure 2: RFID DESS System Block Diagram ............... 16   Figure 3: RFID DESS Key Composition ................ 17   Figure 4: RFID GEN3 Post - CAN ................. 18  ...
  • Page 5: Tables

    Product Specification and User Manual RFID GEN3 System Tables Table 1: Terminology ..................... 13   Table 2: RFID GEN3 System Part Numbers ..............14   Table 3: RFID GEN3 System Software ................. 14   Table 4: RFID GEN3 Post Pinout .................. 22  ...
  • Page 6: Manufacturer Information

    Manufacturer Information Manufacturer’s Name: KONGSBERG Inc.  Manufacturer’s Address: 90, 28e rue, PO Box 10034, Shawinigan, QC, G9T 5K7 Canada Product Name: RFID GEN3 System Model Name: 1001316154 and 1001316155 Product Name: BRP RF/DESS Post Model Name: 1001385887 Brand: KONGSBERG AUTOMOTIVE...
  • Page 7: Fcc Compliance Statement

    Product Specification and User Manual RFID GEN3 System FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 8: Ised Compliance Statement

    Product Specification and User Manual RFID GEN3 System ISED Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 9: Ifetel Statement

    Product Specification and User Manual RFID GEN3 System IFETEL Statement: “La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.”...
  • Page 10: Applicable Standard And Regulations

    Product Specification and User Manual RFID GEN3 System Applicable Standard and Regulations  ISO/IEC 15693-1:2000 Identification cards — Contactless integrated circuit(s) cards — Vicinity cards — Part 1: Physical characteristics.  ISO/IEC 15693-2:2006 Identification cards — Contactless integrated circuit cards —...
  • Page 11 Product Specification and User Manual RFID GEN3 System  ISO 7637 (2011) Road vehicles Electrical disturbances from conduction and coupling  RSS-GEN General Requirements and Information for the Certification of Radio Apparatus  RSS-210 License-exempt Radio Apparatus (All Frequency Bands): Category I Equipment ...
  • Page 12: References

    Product Specification and User Manual RFID GEN3 System References  Technical requirement document "TRD-12-0016 Ski-Doo DESS key Rev 2.pdf"  Technical requirement document “TRD-18-0019 RF-CAN DESS post MY21 V02.pdf"  000001 FO-QA-029 KA SKIDOO 600 ETEC Capacitor Grounding Return Problems ...
  • Page 13: Terminology

    Product Specification and User Manual RFID GEN3 System Terminology Terms and abbreviations Description MOWP Megatech One Wire Protocol Controller Area Network Electronic Control Unit ISO15693 compliant transponder Antenna Guide for wave transmission Printed Circuit Board Hertz Hall effect sensor Sensor affected by magnetic change. Unique IDentifier Table 1: Terminology CONFIDENTIAL...
  • Page 14: General Information

    Mechanical details are found on the product drawings listed in Table 2. Software and communication details are found in the software specification (1001392597). Drawing numbers, Kongsberg and customer part numbers are listed in the table below. Part Description Generic Drawing Number...
  • Page 15: Rfid Gen3 System Overview

    Product Specification and User Manual RFID GEN3 System 2 RFID GEN3 System Overview The RFID System is composed of 2 parts, the RFID Key and the RFID Post. Details about these are provided in section 0and 0 respectively. Figure 1: RFID Key and Post System CONFIDENTIAL Page 15 of 34...
  • Page 16: Figure 2: Rfid Dess System Block Diagram

    Product Specification and User Manual RFID GEN3 System Figure 2: RFID DESS System Block Diagram The vehicle ECU powers the RFID Post from the positive switched battery connection (KL15). Once powered, the RFID Post senses the RFID Key’s magnet using its internal hall sensor.
  • Page 17: Rfid Key

    Product Specification and User Manual RFID GEN3 System 2.1 RFID Key As illustrated in Figure 3, the RFID Key is composed of a plastic housing, 2 trim caps (not shown), a magnet, a RFID tag and a spacer. The last 3 elements are contained in an intermediate shell (not shown), needed to seal them from the external environment.
  • Page 18: Rfid Dess Post

    Product Specification and User Manual RFID GEN3 System 2.2 RFID DESS Post As illustrated in Figure 4 and Figure 5, the Post is composed of a plastic cover, an O-ring, a main PCB, a header, a secondary PCB and a plastic housing. The plastic cover, plastic housing and O-ring protect the internals from the external environment.
  • Page 19: Rfid Gen3 Functional Specification

    Product Specification and User Manual RFID GEN3 System 3 RFID GEN3 Functional Specification 3.1 Bidirectional Communication 3.1.1 CAN variant The RFID Post is designed to exchange information via CAN protocol with the ECU. Refer to software specification. 3.1.2 MOWP variant The RFID Post is designed to exchange information via Maxim 1-Wire protocol with the ECU.
  • Page 20: Operating And Storage Temperature

    Product Specification and User Manual RFID GEN3 System Figure 6: Cut-off System 3.3 Operating and Storage Temperature The RFID DESS System has an operating and storage temperature range of -40°C to +85°C. 3.4 RFID Tag Reading Sequence Figure 7 shows the sequence performed by the RFID Post’s microcontroller to acquire the UID from power up.
  • Page 21: Figure 7: Uid Reading Sequence

    Product Specification and User Manual RFID GEN3 System Start Init Debug Debug? RFID wait mode Erase key Magnet? saved? Init ISO Monitoring Read key Reset retry? found? Save EEPROM Save key Deinit ISO Figure 7: UID Reading Sequence. CONFIDENTIAL Page 21 of 34...
  • Page 22: Rfid Gen3 Electrical Specification

    Product Specification and User Manual RFID GEN3 System 4 RFID GEN3 Electrical Specification 4.1 Connector The electrical connection between the RFID Post shall use the sealed connector Delphi GT 150 series. Refer to product drawing for more details. Figure 8: CAN Variant Connector Figure 9: MOWP Variant Connector The following table outlines the RFID Post’s pinout.
  • Page 23: Table 5: Gnd Characteristics

    Product Specification and User Manual RFID GEN3 System 4.1.1 Pin A: GND This pin is used as the RFID Post power return, to be connected to the vehicle’s main ground. Characteristic Unit Minimum Nominal Maximum Voltage, absolute maximum rating (steady state) Table 5: GND Characteristics.
  • Page 24: Table 8: 1-Wire / Mowp Characteristics

    Product Specification and User Manual RFID GEN3 System 4.1.4 Pin C: 1-WIRE / MOWP This pin is used for communication with an ECU or a diagnostic tool. Characteristic Unit Minimum Nominal Maximum Voltage, absolute maximum rating (steady state) Voltage, operating Logic level Low: 1.45 High: 3.25...
  • Page 25: Rf Specifications

    Product Specification and User Manual RFID GEN3 System 5 RF Specifications The RFID Post has the following RF performance over temperature. Characteristic Unit Minimum Nominal Maximum RF Output Power Operating Frequency 13.55 13.56 13.57 Frequency Stability Table 11: RF Characteristics The antenna is built-in the PCB and cannot be replaced without modifying the PCB.
  • Page 26: Localization And Installation On Vehicle

    Product Specification and User Manual RFID GEN3 System 7 Localization and Installation on Vehicle The RFID GEN3 System shall be installed as the previous DESS System generation. The RFID Post should be secured to the vehicle’s body using the Post retaining ring 278 002 963.
  • Page 27: Noise Sources Identifications

    Product Specification and User Manual RFID GEN3 System 7.2 Noise Sources Identifications The RFID Post shall be located away from vehicle radiated sources. A minimum of 15 cm in any direction between a radiated noise source and the RFID GEN3 System is recommended.
  • Page 28: Diagnostic Tool

    Product Specification and User Manual RFID GEN3 System 8 Diagnostic Tool KA has designed a tool to analyze performance using the RFID Post. This tool allows the monitoring of performance of the RF transmission between the RFID Key and Post in real time.
  • Page 29: Mowp Variant

    Product Specification and User Manual RFID GEN3 System 8.2 MOWP Variant Figure 11: RFID Diagnostic Tool The diagnostic tool reads the RFID tag every 30 ms. In case of reading error, the probe wire will be pulled low during a period of 30 ms. The probe wire can be monitored using an oscilloscope having a minimum bandwidth of 100 MHz.
  • Page 30: Figure 13: Example Of Probe Wire Output

    Product Specification and User Manual RFID GEN3 System Figure 12: Example of probe wire output At power up, the RFID diagnostic tool will send the RFID tag’s UID over the 1-wire interface. This last approximately five (5) seconds. During this period, the switch allows a temporary connection of the 1-Wire output to the vehicle’s ECU for it to authenticate the RFID Key.
  • Page 31: Figure 14: Configuration For Radiated Noise Validation

    Product Specification and User Manual RFID GEN3 System 8.2.1 Radiated Noise Validation The main purpose of this validation is to determine whether the RFID GEN3 System is in the presence of a radiated noise source that could potentially affect the transmission of the RF transmission between the RFID Key and Post.
  • Page 32: Figure 15: Configuration For Noise Validation Performance

    Product Specification and User Manual RFID GEN3 System 8.2.2 Metallic Presence Validation The main purpose of this validation is to determine whether the RFID GEN3 System is in the presence of a metallic material that could affect the RF transmission between the RFID Key and Post.
  • Page 33: Performance Criteria

    Product Specification and User Manual RFID GEN3 System Once the system is powered-up and the vehicle is started, the diagnostic tool can be used to monitor whether conducted noise could be affecting the performance of the RFID signal. The following documents can be used as a guidance for measurement or source identification: 000001 FO-QA-029-KA Skidoo 600 ETEC Capacitor Grounding Return Problems 000002 FO-QA-029-KA RFID DESS Grounding Problems...
  • Page 34: Validation Plan

    The product meets the requirements laid out in the Technical Requirement Document as detailed in the test plan 111550 - DVP&R PV1.xslx. 10 International RF certification Product 1001316154 and 1001316155 have been certified in the following countries or regions: Canada, USA, Europe, UK, Mexico City, Cayman Islands, Costa Rica, Peru, Brazil, Chile,...
