  • Page 1 INSTRUCTION BOOKLET CU3002 BUILT IN GAS COOKER INSTALLATION MAINTENANCE...
  • Page 2 CAN S.r.l. Via Nazionale 65, 25080 Puegnago del Garda – (BS) ITALY www.cansrl.com info@cansrl.com tel. +39 0365 555909 fax. +39 0365 651822 CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 3 Fig. X () These data refer to an element in a figure CAN S.r.l., as the manufacturer, reserves the right to make changes to its products and to this manual which it deems necessary without being obliged to provide advance notification.

  • Page 4: Table Of Contents

    LONG PERIODS OF INACTIVITY ....................36 DISPOSAL ON DECOMMISSIONING.................... 36 AFTER SALES SUPPORT ........................36 PROCEDURE IN THE EVENT OF A MALFUNCTION ..............37 SPARE PARTS ..........................38 SPARE PARTS ..........................38 NOTES ............................39 CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 5: Equipment And Content Of Packaging

    Inside the packaging, there is the installation, use and maintenance manual (Fig. 3) and a mounting kit (Fig. 4) including the screws and any accessories for installation of the product on kitchen furniture. Fig. 1 Fig. 3 Fig. 4 Fig. 2 CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 6: Labelling - Ce Marking

    PRODUCT RANGE MODEL CE CERTIFICATION SERIAL NO. DESCRIPTION OF THE WORKING PRESSURE - CERTIFICATION PARAMETERS - COUNTRIES POWER AND TOTAL CONSUMPTION BARCODE - PRODUCTION SERIAL NO. DATE OF MANUFACTURE CE MARK CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 7: Technical Data Sheet - Product Data

    Button and generator 12 V / DC ▪ IGN ONLY VERY LOW VOLTAGE CONNECTION POWER SUPPLY: ▪ BUTANE (I3+) G30 (28-30 mbar) ▪ PROPANE(I3+) G31 (37 mbar) ▪ BUTANE-PROPANE (I3B/P) G30-G31 (30 mbar) Fig. 6 CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 8 0.55 kW 0.65 mm 0.36 mm 127.50 g/h OVEN 2.10 kW 0.90 kW 0.80 mm 0.52 mm 152.00 g/h GRILL 1.70 kW 0.90 kW 0.69 mm 0.52 mm 125.50 g/h CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 9: Installation

    THE MANUFACTURER CANNOT BE HELD LIABLE IN THE EVENT OF NON-COMPLIANCE WITH THE AFOREMENTIONED. Incorrect, improper or irresponsible use can seriously prejudice the health and safety of people, property and animals. ATTENTION - During installation, maintenance and repair operations, always close the gas supply taps.

  • Page 10: Disposal Of Packaging

    The appliances can only be assembled on furniture whose material is resistant to heat. The work counter must be fitted in a perfectly horizontal position and perpendicular to all the surrounding vertical panelling.
  • Page 11 650 mm (minimum distance between the work counter/installation of the kitchen and the press above) ATTENTION - The installation premises must have continuous air exchange or however such to guarantee normal and correct gas CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 12: Switch On And Electrical Connection

    “-“ (negative polarity) should be connected to the counterpart negative pole. CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 13 FORBIDDEN - NEVER CONNECT THE APPLIANCE TO MAINS WITH VOLTAGE OVER 12V AND IN ALTERNATING CURRENT. A similar connection would cause irreversible damage to the appliance and pose a significant danger to the user's life. CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 14: Gas Connection

    All installation and connection operations must be performed only by qualified technical staff. CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 15 The operation should be carried out by a professional. FORBIDDEN - NEVER USE OPEN FLAMES BEFORE PASSING THE INSPECTION TEST! IF THE OUTCOME OF THE TEST IS SATISFACTORY, you can proceed to switch on all the burners (consult page 24) to check the flame is stable and regular.
  • Page 16 • Check compatibility and correct calibration of the pressure regulator if present. • Check the gas supply tube (tube obstructed, tube bent/crushed, tube excessively long, unsuitable tube, etc...). CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 17: Appliance Fitting

    Arrange the appliance over the fitting hole by pushing it against the top. Block the appliance with the fastening kit screws supplied with the product. Fig. 9 For non-standard manufactures, the fastening system is customised. CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 18: Use

    (e.g. extractor hood). ATTENTION - The appliance is equipped with a glass cover to protect and decorate the hob. The glass covers can break if heated with a direct flame or if placed in immediate contact with very high sources of heat.
  • Page 19 DANGER OF FIRE - Never position heat-sensitive or inflammable objects (pot holders, curtains, bottles of alcohol, etc...) near the appliance. The area near the appliance can be very hot, pay attention to positioning of electricity sockets, other electrical appliances, electrical cables, tubing and any other heat-sensitive or inflammable material in this space.

  • Page 20: Specific Warnings For Cooking

    If the flame is accidentally extinguished on the burner, turn the knob “off” and do not re-attempt to switch back on for a minute. Intensive and prolonged use of the appliance can require additional ventilation (for example opening a window) or a more efficient...

  • Page 21: Before Starting

    BEFORE STARTING KNOW THE APPLIANCE (the images have a purely indicative value) Fig. 10 CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 22 (the images have a purely indicative value) CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 23 OVEN/GRILL COMPARTMENT INNER GRILL OVEN/GRILL COMPARTMENT INNER DRIPPING PAN GAS MAIN RAMP TERMINAL 12V GENERATOR CONNECTION CABLES EYELETS FOR COMBUSTIVE AND COOLING AIR CIRCULATION STEEL SIDE FRAMES GAS TAPS ADJUSTMENT KNOB CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 24 (Fig. 11). (the images have a purely indicative value) Fig. 11 CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 25 DETAIL D – TYPICAL GAS TAP FOR HOB BURNER Fig. 12 DETAIL C - GAS TAP FOR OVEN AND GRILL BURNER Fig. 13 CLOSED (0°) CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 26: Use Of Appliance

    (e.g. liquid overflows from the pan), the thermocouple will cool in a few seconds and this blocks the gas exiting the nozzle, preventing the premises being saturated with unburned gas. CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 27 THERMOCOUPLE FOR FAST-ON MAGNET TAP CLIP FOR CANDLE CANDLE FOR BURN. IGNITION L 350 COVER 055 BURN 2 SERIES AUX PERFORATED AND ENAMELLED GAS RING FOR BURNER 2nd SR AUX CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 28 4) Check the flame is regular and stable. Then, turn the knob to the desired position (MIN or MAX). You can position the knob in the intermediate position, between the maximum and minimum, but NOT between the maximum and “closed” position (0°...
  • Page 29 Periodically, check the openings are not accidentally blocked and the extraction system is working perfectly. 3) any other system or device compatible with the type of application in question CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 30: Description And Use Of The Oven And Grill

    - The burners go out when the kitchen doors move. - The gas valves are difficult to rotate. If the appliance is not working, contact the authorised local dealer. DESCRIPTION AND USE OF THE OVEN AND GRILL CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 31 CANDLE FASTENING SPRING INJECTOR 0.80 FOR GRILL BURNER The oven burner is controlled by a thermostat which constantly adjusts the flame to obtain and maintain the temperature set by the user. CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 32 A graduated scale representing the temperature field within which adjustment is possible is represented on the commands front panel around the thermostat knob: you can also position the knob at intermediate positions not expressly indicated between the maximum position (231° angle) and the minimum(52°...

  • Page 33: Accessories

    Only use saucepan, pans and accessories expressly designed for this use, made from materials resistant to high temperatures and suitable for contact with food. ACCESSORIES No accessories are planned for this type of product. CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 34: Maintenance

    If some particular acidic substances (e.g. vinegar, lemon juice, etc..) remain for long periods on the appliance, they could damage the surface creating unsightly stains which would not however prejudice functionality of the appliance. ROUTINE MAINTENANCE CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...

  • Page 35: Cleaning

    Gas rings, caps, grates: after the components have cooled, remove them from their compartment and wash them with hot water and detergent for plates. Stubborn dirt on cast iron components can be removed using a slightly abrasive sponge and a greaser, taking care not to damage the enamelled parts.

  • Page 36: Long Periods Of Inactivity

    If the product is found in a country other than Italy, you must comply with legislation in force for your country. The equipment can be decommissioned for disposal by removing the electrical power cables.

  • Page 37: Procedure In The Event Of A Malfunction

    CAN Srl assures you of its maximum collaboration and support if technical problems should arise or of any other nature on each of its products. For any information or support request, contact your nearest dealer or contact the manufacturer. PROCEDURE IN THE EVENT OF A MALFUNCTION Before contacting your nearest Support Centre, run the following operations: •...

  • Page 38: Spare Parts

    SPARE PARTS The user or installation technician can find in this booklet the list of all components of the hob subject to wear and replacement of parts and original spare parts. (see pages 20-21) ATTENTION –...

  • Page 39: Notes

    ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
  • Page 40 CAN S.r.l. Via Nazionale 65, 25080 Puegnago del Garda – (BS) ITALY www.cansrl.com info@cansrl.com tel. +39 0365 555909 fax. +39 0365 651822 CAN Srl – CU 3002 – ENGLISH – Rev 1/2018...
