- Page 1 INSTRUCTION MANUAL SL500 Sliding Gate Motor Rack Drive SL500 Sliding Gate Motor Chain Drive Version –V2.0...
-
Page 2: Table Of Contents
ATTENTION To prevent electrical shock, disconnect from power source before installing or service ATTENTION Electricity and power motors associated accessories could be fatal or at least cause seriously injury. All main voltage wiring must be installed by a licensed electrician. ATTENTION Additional safety device MUST be fitted such as Photo Electric Beam, Loop Detectors. -
Page 3: General Layout
GENERA LAYOUT 1) Motor Cabinet 4) Chain drive guide roller 2) Limit Switch 5) 12V motor 3) Steel base 6) Manual release Limit Rack Drive Limit Chain Drive Encoder Rack Drive Encoder Chain drive... -
Page 4: Specifications
CONTROL INPUIT AND BUTTON 1. General Descriptions The SL500 sliding gate motors was designed for domestic sliding gate or swing gate, rack drive or chain drive, limit switch or encoder control. The controller can receive the signals from swipe card, loop detectors, remote control, photo-electric beams and any kind of access control system. -
Page 5: Control Board Input
CONTROL INPUIT AND BUTTON 4. Control Board Input OSC input The OSC inputs terminal input can be from switch, push button or relay (from any other brand standalone receiver) N/O. It became active when short to COM. This terminal can be set to OSC or OPN function by jumper on board. -
Page 6: Chain Drive
This motor has three different power can be choose. 240V, Low voalteg and Solar. If has 240V power near at the gate, then use 240V version SL500 eithe encoder or limit control. If no 240V power at gate, but has 240V power in the gararge or house, then choose SL500LV low volatge model. -
Page 7: Manual Release
9. Manual release A: What to do during a power failure (battery run out) or faulty: If got battery back, then take the red cap off or take whole cover off, using the 8mm Allen key, insert to the release bolts holes or use hand, clockwise turn the bolts several turns, then can manually push gate open. -
Page 8: 10. Trouble Shooting Guide
TROUBLE SHOOTING GUIDE 10. Trouble Shooting Guide 10.1 Display information on main control board. Between Pot and OSC button on the control board, there are two LEDs --- GREEN and RED. Different combination and show different gate situations. (1) Gate status LED Gate Status (Position) \ LEDs Status LED-Green Status LED-Red... -
Page 9: 11. Condition Of Sales
(b) Digiway control boards can be up to two years warranty. subject the application conditions. (c) In lieu of all other warranties expressed or implied. Digiway shall not be liable for any special indirect, incidental or consequent damages of any kind or nature.
