- Page 1 USER MANUAL...
-
Page 2: Unpacking Checklist
The primary function of the Zero B Auto Iron Remover filter is to remove dissolved iron from the raw water which will enhance performance of softener and larger RO systems. -
Page 3: Components Identification
COMPONENTS IDENTIFICATION Auto Filter Valve Top Strainer Pressure Vessel Riser Pipe ISR Resin Coarse Silex Bottom Strainer... - Page 4 KNOW YOUR AUTO IRON REMOVER FILTER 1. The display screen 2. This display screen communicates the status of the Iron Remover filter. • The Iron Remover filtration process stages such as Service, Backwash and Fast Rinse are indicated with appropriate icons as shown above. •...
- Page 5 CAUTION For drinking - • The Zero B Auto Iron Remover filter only removes dissolved iron from raw water. It can be used for bathing, washing and laundering. • This water may not be microbially safe for direct drinking. Always use a point of use water purifier for drinking.
- Page 6 PROCESS AND FEATURES Process 1. When raw water passes through the Auto Iron Remover filter the filtration media removes dissolved iron and manganese. 2. Auto iron removes dissolved iron from raw water which enhances performance of Softener & larger RO systems. Process Cycles Service cycle Backwash cycle...
-
Page 7: Technical Specification
TECHNICAL SPECIFICATION Model 3 Auto NGIF Tank size (Pressure vessel) 14” x 65”, 2.5” Top Opening Flow rate up to 3.0 m³/h Working pressure (Kg/cm²) Minimum Maximum Filter media ISR Resin & Coarse Silex ISR resin (Liter) Coarse Silex (Kg) Output @5ppm Iron (m³) Inlet, Outlet &... -
Page 8: Do's And Don'ts
AUTO VALVE POSITION & PROCESS CYCLE DOS AND DON'TS • Ensure that the product is installed inside the building or a shed. • Always use genuine spares and filter media. • Keep an “Air gap” between drain line and drainage sump. •... - Page 9 INLET WATER CONDITION Specifications Sr. No. Parameter >6.5 Dissolved Oxygen >15% of Iron content Alkalinity Minimum 100 ppm Hydrogen Sulfide Free Chlorine Oil & Greece Suspended Solids 5 ppm Iron Max 5 ppm 2500 ppm Water Temp. <38°C Inlet water pressure 2- 3.5 kg/cm²...
- Page 10 / maloperation of the equipment by the buyer. Ion Exchange (India) Limited shall be excused from any delay or failure in performance required hereunder if caused by reason of any occurrence or contingency beyond its reasonable control, including, but not limited to, acts of god, acts of war, fire, laws, proclamations, edits, ordinances or regulations, riots, earthquakes, floods, explosions or other acts of nature.
-
Page 11: Warranty Card
WARRANTY CARD (To be filled in by the sales representative and retained by the customer for reference) Unit Serial No. : ........Model : Auto Iron Remover Filter Invoice No. : ........Product Serial No. : ..........Dated : ..........Date of Expiry of Warranty : ........ - Page 12 Ion Exchange (India) Ltd., is a leader in the business of water treatment and solutions that are so vital to people’s lives and the environment. For more than five decades, Ion Exchange (India) Ltd., has pioneered many path-breaking innovations in the field of engineering and marketing to provide “a one-stop solution for industries, homes and communities".
