User Manual
50 LPH RO SKID
ION EXCHANGE (INDIA) LTD.
Ion House, Dr. E. Moses Road,
Mahalaxmi, Mumbai-400011
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zero B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ION Exchange Zero B

  • Page 1 User Manual 50 LPH RO SKID ION EXCHANGE (INDIA) LTD. Ion House, Dr. E. Moses Road, Mahalaxmi, Mumbai-400011...
  • Page 2 Technical Specifications of RO 50 LPH Reverse Osmosis water purifier with up to 50 Liters per hour purification capacity Reverse osmosis system designed to deliver up to 50 liters of purified water per hour through a 6 stage purification process. Its membrane have a pore size of 0.0001 micron size which prevents the passage of micro organisms and total dissolved salts making the water lighter, taste natural and safe to drink.
  • Page 3 Water Flow Schematic...
  • Page 4 TECHNICAL SPECIFICATION FOR RO SYSTEM The RO water purifier units have 6 purifier stages in a CRCA steel skid frame powder coated for corrosion protection. Stage 1: Particulate Filter : 2.5” Dia 20” Height Size MOC of Cartridge : PP Yarn Nominal rating of Cartridge : 10 microns Qty :...
  • Page 5 Front View Inlet Water Stage 4: Stage 3: Stage 1: Pre carbon Sediment Particulate filter filter filter...
  • Page 6 Stage 6: Stage 5: Post Carbon filter Membrane filter Stage 2: Membrane Life Enhancer Filter Booster Pumps 2 nos driven by 48V DC Auto Flush Timer Valve Tank level control valve...
  • Page 7 Stage 2: Membrane Life Enhancer Filter Flow Restrictor 1.2 mm here Rejected water out Flow Restrictor 0.5 mm here...
  • Page 8 2. Insist on installing NRV (non returnable valve) in the permeate line before the HP Switch. 3. Use Ion Exchange (ZERO B) genuine spare parts only. 4. Allow only ZERO B authorized persons to service this machine. 5. Insist on cleaning the Flow restrictors during the servicing the machine.
