R&B Wire Products 100 Series Assembly Instructions

R
· Never allow children or adults to ride in or on
cart, as it can cause serious injury or death.
!
· Be sure casters roll freely and turn easily.
· Place all loads in center of basket for balance.
@
SALES RBWIRE.COM
NOTE: Although this instruction sheet depicts the 100 series cart,
it also applies to the 100, 200, 201 and 350 series.
STEP
Set base upside down with legs pointing up to install
casters. Place raceway cover onto caster stem and insert
caster stem into base leg. While holding raceway cover
up against caster, insert a hex head bolt into each leg
hole, and secure with nuts facing toward inside of unit.
Repeat with remaining casters.
STEP
Place basket on base and align holes in bottom of
basket with holes in top of base. Insert flathead bolts
through hole in basket and through base, and secure
with nuts. Tighten until bolt head engages nylon lock
on nut.
NOTE: Your laundry cart is assembled and ready for use. If you purchased
the Single Pole Rack or Double Pole Rack accessories, continue to page 2.
HARDWARE INCLUDED
x12 Nuts
x4 Raceway covers
(800) 634-0555
ASSEMBLY INSTRUCTIONS
100, 200, 201, 350 SERIES

TOOLS REQUIRED:

(2) 7/16 wrenches or sockets
(1) Large flathead screwdriver
1 person assembly
1
2
(Not to scale)
x8 Hex bolts
RBWIRE.COM
Wire Cart
x4 Flathead bolts
