- Page 1 Quick Start Guide UA-SNVR UA-SNVR3240-N UA-SNVR1620-P UA-SNVRL810-P Before attempting to connect or operate this product, UVSSNVR-QG-A please read these instructions carefully and save this manual for future use.
- Page 2 Every effort has been made to ensure that the information in this manual is accurate. USAVision makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Table Of Contents
Contents 1. Introduction ......................2 1.1 Front View ......................2 1.2 Rear View ....................... 3 1.2.1 UA-SNVR3240-N ...................... 3 1.2.2 UA-SNVR1620-P ...................... 4 1.2.3 UA-SNVRL810-P ...................... 5 2. Installation ......................6 2.1 Connection Diagram ....................6 2.2 HDD Installation ...................... 7 2.3 Power Supply Connection .................. -
Page 4: Introduction
1. Introduction Welcome to the UA-SNVR Quick Start Guide. In the following sections, you will learn about the basic installations and configurations. For more details, see UA-SNVR User’s Manual. Note: The first time you run the NVR, you will be required to set your password immediately in order to protect your privacy. -
Page 5: Rear View
1.2 Rear View 1.2.1 UA-SNVR3240-N Item Description Power Switch Start up and shut down the NVR system. Power Port Connect the attached power supply. USB Port Connect a USB device, such as USB mouse and USB flash disk. Sensor / Alarm / RS-485 Connect to sensor, alarming devices, and/or RS-485 PTZ Terminal Block cameras. -
Page 6: Ua-Snvr1620-P
1.2.2 UA-SNVR1620-P Item Description Power Switch Start up and shut down the NVR system. Power Port Connect the attached power supply. USB Port Connect a USB device, such as USB mouse and USB flash disk. Sensor / Alarm Terminal Block Connect to sensor or alarming devices. -
Page 7: Ua-Snvrl810-P
1.2.3 UA-SNVRL810-P Item Description Power Switch Start up and shut down the NVR system. Power Port Connect the attached power supply. USB Port Connect a USB device, such as USB mouse and USB flash disk. Reset Restore the device to its default settings. The reset hole is under the USB Port. -
Page 8: Installation
2. Installation 2.1 Connection Diagram The following diagram is for reference only. The practical connection may be different depending on the NVR you purchased. You can connect to other IP cameras remotely over the Internet. Connect a CAT.5E or higher RJ45 Ethernet cable for local connectivity. You can connect to other IP cameras through your local network. -
Page 9: Hdd Installation
2.2 HDD Installation The number of 3.5" / 2.5" SATA hard drives that the NVR can support varies depending on the model. The following procedures are for reference only. The practical operation may be different depending on the NVR you purchased. Caution: Do not install or remove the hard disk drive while the power is turned b) Carefully flip the NVR case and secure the hard... -
Page 10: Power Supply Connection
2.3 Power Supply Connection Caution: Only use the supplied power adapter that comes with the NVR. Connect one end of the power adapter to the power connector on the back of the NVR. Plug the other end of the power adapter into the wall outlet. And press the Power Switch to turn on the power. -
Page 11: Getting Started
3. Getting Started 3.1 Start Wizard Note: The Start Wizard does not work for UA-SNVR3240-N. For the first-time users of this model, see 3.2 Getting Started for UA-SNVR3240-N. 3.1.1 Start Wizard Click Start Wizard to proceed to the next step. 3.1.2 Connecting IP Cameras After finishing setting Network Configuration and Date and Time, this page appears. - Page 12 Click Search to search for IP cameras in the same network. Select the IP camera(s) you want to add, and then click icon to add to the NVR. Or, click button to manually add an individual IP camera to a single channel. This dialog box appears.
- Page 13 IMPORTANT: The system fills in the ID and password using admin/admin by default. Make sure to enter the correct ID and password of the IP cameras when adding them to the NVR. There is no default password for UA-B580F3 / UA-R500F2 / UA-R560F2 / UA-R580F2 / UA-R800F2.
-
Page 14: Getting Started For Ua-Snvr3240-N
3.2 Getting Started for UA-SNVR3240-N UA-SNVR3240-N has two network ports, LAN and WAN. Both ports are not linked, and the LAN port does not have the internet access. Therefore, there are two methods for connecting IP cameras to UA-SNVR3240-N. 1. Connect IP cameras and UA-SNVR3240-N to the WAN port, using a router. 2. - Page 15 4. On the NVR’s taskbar, click Start Menu > Setup > Channel > Channel. 5. Click Search to search for IP cameras from local network. The cameras found should be displayed in a list. 6. Select desired cameras in the list, and click Add or Add All. The Add IP Camera dialog box appears.
- Page 16 ◼ Protocol: Select the protocol of the IP camera from the dropdown menu. Select Onvif for UA-B20004F / UA-B40004F / UA-B4000VF-S / UA-D20004F / UA-D40002F / UA-D4000VF-S / UA-R40002F-SA / GV-IP cameras Select Private for UA-B580F3 / UA-R500F2 / UA-R560F2 / UA-R580F2 / UA-R800F2 ...
-
Page 17: Live View Overview
3.3 Live View Overview 3.3.1 Main Window Name Description Camera Title Display channel number. Status Icon This indicates that the NVR is currently recording. This icon appears when the camera has detected motion. The icon indicates that the external I/O alarm device is triggered. - Page 18 admin: To switch user. Start Menu Search: Search & Playback. Setup: System Setup. Lock Screen: Lock and unlock screen. Shutdown: Shutdown, reboot, and log out the system. Locate at the bottom of the live view screen. Refer to 4.2.2 Task Menu Bar Taskbar in the manual for details.
-
Page 19: Remote Access Via Web Client
4. Remote Access via Web Client Use the Web Client to remotely access your NVR at any time via a PC. Before you access the Web Client, ensure that your PC’s system meets the basic requirements and that the network settings of the NVR are configured properly. 4.1 Basic System Requirements Item Minimum... -
Page 20: Looking Up The Dynamic Ip Address
4.2 Looking Up the Dynamic IP Address By default, when the NVR is connected LAN with DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address. Download and install UVS Device Utility from our website. On the UVS Device Utility window, click Search to search for the devices connected in the same LAN. -
Page 21: Upgrading Firmware
5. Upgrading Firmware You can upgrade the firmware on the device remotely through UVS Device Utility. Follow the instructions below. 5.1 Upgrading Firmware Download and install UVS Device Utility from our website. On the UVS Device Utility window, click Upgrade and select the device you wish to upgrade the firmware on.
