Technical Data - Mayr ROBA-multiswitch 019.00.2 Series Installation And Operating Instructions Manual

Installation and Operating Instructions for
ROBA -multiswitch Type 019._00.2
®

Technical Data

Input
Frequency
voltage
at ≤ 45 °C
Output current
at max. 70 °C
Fitted protective varistors
Device fuses
Protection
Terminals
Ambient temperature
Storage temperature
Conformity markings
Installation conditions
Sizes Type
10 019.100.2
019.100.2
019.200.2
019.100.2
20 019.200.2
019.200.2
019.200.2
019.100.2
* On special designs, deviating values are possible. The values stated on the Type tag are decisive.
Special designs with other input and output voltages as well as longer overexcitation times are available on
request!
29/03/2022 GC/TH/MA/SU
Page 3 of 6
[Hz]
I [A]
RMS
I [A]
RMS
U [V]
RMS
T 5 A (H) 5 x 20 mm
[°C]
[°C]
Please ensure sufficient heat dissipation and air convection!
DANGER
Danger of death! Do not touch voltage-
carrying lines and components.
No mains separation!
Voltage control through phase angle
control system
Input voltage *
± 10 % acc. EN 50160
Overexcitation voltage
[VAC]
100 – 275
200 – 500
200 – 500
230
230
230
230
300 – 500
Chr. Mayr GmbH + Co. KG
Eichenstraße 1, D-87665 Mauerstetten, Germany
Tel.: +49 8341 804-0, Fax: +49 8341 804-421
www.mayr.com, E-Mail:
Type 019.100.2
Size 10 Size 20
50 – 60 50 – 60
2.0 2.0
1.0 1.0
300 550
T 5 A (H) 6.3 x 32 mm
IP65 components / IP20 terminals / IP20 DIP switch
Nominal cross-section 1.5 mm
screws M3, max. tightening torque 0.5 Nm
-25 to +70
-40 to +70
The installation position can be user-defined.
Do not install near to sources of intense heat!
Output voltage *
± 10 %
U
O
[VDC]
90
180
180
207
207
207
207
240
public.mayr@mayr.com
(B.019+002.EN)
Type 019.200.2
Size 20
50 – 60
4.5
2.25
550
T 10 A (H) 6.3 x 32 mm
(AWG 22-14),
2
Article number
Holding voltage
U
H
[VDC]
52 8186586
104 8185591
104 8242954
30 8225580
30 8237887
40 7078520
- 7075719
52 8220914
3 3
