Summary of Contents for Powersmart PS6109
- Page 1 INSTRUCTION MANUAL Electric Pole Saw Model # PS6109 Have product questions or need technical support? Please feel free to contact us! Website: www.PowerSmartUSA.com Toll free: 1-800-791-9458Mon-Fri9-5EST Email: support@amerisuninc.com Website...
-
Page 3: Table Of Contents
Knowing your pole saw..…… ..…………………………………..… 9 Assembly instruction……………………………………………………… 10 Operation....…………………………………………………..12 Maintenance.……………………………………………………………… 13 Exploded view & parts list……………………………………………...… 16 Warranty .....…………………………………………………….…… 18 TECHNICAL DATA Electric Pole Saw: Model#PS6109 Motor: 120V, 60Hz,6A Motor speed: 6200 RPM Saw chain: Chinese, 3 / 8" Pitch Chain gauge: 0.050"... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the information in this manual. PowerSmart ® reserves the right to change this product and specifications at any time without prior notice. - Page 5 following: READ ALL INSTRUCTIONS Make sure you read and understand all instructions. Improper use of this pole saw can cause severe injury or death from fire, electrical shock, and body contact with moving chain, on falling wood. BEFORE OPERATING SAW 1.
- Page 6 11. Inspect tree before cutting down. Make sure there are no dead limbs or branches that may fall on you. 12. To reduce the risk of electric shock, this saw has a polarized plug ( one blade is wider than the other )This plug will fit in a polarized outlet only one way.
- Page 7 Carry the extended-reach pruner by the handle with the saw chain stopped. When transporting or storing the extended-reach pruner, always fit the saw chain device cover. Proper handling of the extended-reach pruner will reduce possible personal injury from the saw chain. Hold the extended-reach pruner by insulated gripping surfaces only, because the saw chain may ...
-
Page 8: Electrical Information
ELECTRICAL INFORMATION DOUBLE INSULATION Double insulation is a concept in safety in electric power tools that eliminates the need for the usual three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. Double insulated tools do not need to be grounded. WARNING: The double insulated system is intended to protect the user from shock resulting from a break in the tools internal insulation. -
Page 9: Knowing Your Pole Saw
KNOWING YOUR POLE SAW... -
Page 10: Assembly Instruction
ASSEMBLY INSTRUCTIONS Unpacking Unpack the pole saw and all its parts, and compare against the list below. Do not discard the carton or any packaging materials. Please call 1-800-791-9458 or E-mail us at support@amerisuninc.com if any parts are damaged or missing. PACKING LIST Pole saw*1 Saw chain*1... - Page 11 Install the guide bar&saw chain 1. Loosen the screw on the machine in the direction of the arrow with an inner hexagon wrench. 2. Install the saw chain hook teeth into the groove of the guide bar. Note: ensure that the saw chain is installed in the correct direction of rotation. 3.
-
Page 12: Operation
Chain Lubricating Oil Use high quality chain lubricating oil to minimize wear between the saw chain and guide bar while in use. We recommend using SAE No 30 in the summer and SAE No 10 in the winter or when cutting resinous wood. -
Page 13: Maintenance
MAINTENANCE Change saw chain 1. Remove the screw and turn Sprocket Locking Knob counterclockwise to remove the guide bar cover. 2. Move the chain tension pin fully back towards the sprocket using the chain tension screw. ( See direction arrow) 3. - Page 14 10. Tighten the guide bar cover by turning the sprocket locking knob and using a screwdriver to tighten crew. WARNING: Never try to run the chainsaw without sprocket cover securely tightened. Caution: Proper saw chain tension is extremely important. If saw chain is too tight, the guide bar and saw chain will be quickly damaged.
- Page 15 Saw chain Inspect and check the sharpness Check chain tension Sharpen Guide bar Check(wear,damage) Clean and turn over Debugger Replace Chain Check sprocket Screw and Re-tighten nuts Power cord Check Replace...
-
Page 16: Exploded View & Parts List
EXPLODED VIEW & PART LIST... - Page 17 Item Stock# Description Item Stock# Description 203020664A Sprocket Locking Knob 303030062 Locknut 303010325 Screw ST4.2X14 303160653 Small Gear 203020323A Guide bar Cover 301030087 Stator 302070005 Seal ring 303100023 Bearing 608Z 303150035 Guide Bar 301110057 Carbon brush 303143006 Saw Chain 301110034 Brush holder 302010005 O-ring seal...
-
Page 18: Warranty
TWO (2) YEARS LIMITED WARRANTY OF POWER SMART PRODUCTS FOR HOME USE. PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days for all Power Smart Products, if the tool is used for professional or commercial use.
