IDLE-MODE:
(DigitalIO.Output.NoX.IdleMode) x=1,2
(DigitalIO.Relay.NoX.IdleMode)
ACTIVE-STATE:
(DigitalIO.Output.NoX.ActiveState) x=1,2
(DigitalIO.Relay.No1.ActiveState)
IN-ACTIVE:
(DigitalIO.Input.NoX.Mode)x=1,2
OUT1-TIME and REL1/2-TIME
(DigitalIO.Output.No1.SettlingTime)
(DigitalIO.Relay.NoX.SettlingTime) x=1,2
Defines the status of the signal emitters (OUT1,2 and REL1,2)
during the idle mode.
Bit 15 14 13
Function REL1 OUT2
mode mode
7 6 5
1 0 1
Ä
Mode
b01 ON Signal emitter on
b10 OFF Signal emitter off
b11 FLASH signal emitter alternating on with 1Hz
Defines the status of the signal emitters (OUT1,2 and REL1,2)
during the idle mode.
Bit 15 14 13
Function REL1 frq OUT2 frq
7 6 5
0 0 0
Ä
Bit combination
b11
b10
b01
b00
Determines if the input is active with a closed or open contact:
Bit 7 6 5
Function 0 0 0
b0: closed contact activates input
b1: open contact activates input
Defines the holding time of the digital output OUT1 / REL1 /
REL2. If the reader receives a valid transponder response the
antenna assigned to the output by 7.8. CFG9: Input / Output
II (Assignment – output to antenna read event) is activated for
the value in OUT1 / RELx-TIME.
If OUT1 / RELx -TIME is zero the function is disabled.
If OUT1 / RELx is high in idle mode, OUT1 / RELx will low for
OUT1 / RELx -TIME.
If the flash mode is enabled, the output goes low.
Range: 0x0000 ... 0xFFFF ( * 100ms) = 0s ... 6553,5s
