GLIDEROL TM390 REMOTE
CODING INSTRUCTIONS
CODING REMOTES
GRD
1. Carefully remove cover from control box by lifting tab at bottom
2. Press the receiver button once (located on the receiver board top left corner of control box) A red light will
illuminate
3. Press large button on the handset once and hold until red-light on receiver board turns off - This confirms that the
handset is programmed
GTS
1. Ensuring the power is switched o remove or loosen the screw on the GTS cover using screw driver
2. Remove the GTS cover by pulling in the directions of arrows as shown in the picture
3. Switch ON the power supply and press the LEARN button on receiver once (located on receiver board as shown) •
A red light will illuminate on the receiver board Note: The receiver picture may vary depending on the model of the
receiver compare to the picture shown in the picture
4. Press and hold large button on the handset once until red-light on receiver board turns off - This confirms that the
handset is programmed
If you require any assistance encoding the remotes, please contact us
Advertisement
Table of Contents
Related Manuals for Gliderol TM390
Summary of Contents for Gliderol TM390
- Page 1 GLIDEROL TM390 REMOTE CODING INSTRUCTIONS CODING REMOTES 1. Carefully remove cover from control box by lifting tab at bottom 2. Press the receiver button once (located on the receiver board top left corner of control box) A red light will illuminate 3.
- Page 2 GRD+ The following instructions demonstrate how to program a new or additional Gliderol handset to suit your existing Glidermatic GRD+ garage door operator. Please note, if you are replacing a lost or stolen handset we recommend erasing all existing handset data from your operator prior to programming your new handset.
