- Page 1 Upright 54cm Wide Freezer Instruction Manual Model number(s): RH54FR3FZ146 (B) (S) For Customer Services & Spare Parts please call 0345 208 8750 or visit us at mda.russellhobbs.com IMPORTANT: RETAIN FOR FUTURE REFERENCE - 1 -...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Electrical Safety ………………………………………. Transportation & Handling ………………………………………. Installing & Switching on your Appliance ………………………………………. Before Switching On ………………………………………. Product Overview ………………………………………. Unit & Spare Parts ………………………………………. Usage ………………………………………. 10-11 Temperature Selection ………………………………………. Functions ………………………………………. Door Reversal ………………………………………. -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. Warning: When positioning the appliance, ensure the supply cord is not trapped or damaged. - Page 4 • D o not plug in damaged plugs. • D o not pull, twist or damage the power cable. • D o not plug-in or un-plug the appliance with wet hands to prevent electrical shock. • T his appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards...
-
Page 5: Electrical Safety
• One-, two- and three -star compartments (if they are presented in the appliance) are not suitable for the freezing of fresh food. • If the appliance is left empty for long periods, switch off, defrost, clean, dry and leave the door open to prevent mount developing within the appliance. -
Page 6: Installing & Switching On Your Appliance
Installing and Switching on Your Appliance • Operating voltage for your appliance is 220-240V at 50Hz. • Before plugging in the power supply, ensure that the voltage on the rating label corresponds to the working voltage of your electrical system in your home. •... -
Page 7: Before Switching On
WARNING! During use, service and disposal of the appliance, please pay attention to symbol similar to the one shown, which is located on rear of the appliance (rear panel or compressor) and with a yellow or orange colour. It’s risk of fire warning symbol. There are flammable materials in refrigerant pipes and compressor. - Page 8 • Once the appliance has settled, locate the thermostat dial on the product and set to “-20" position and switch on the power. The compressor will begin to work. Close the door. • You may hear faint gurgling or bubbling sounds when the refrigerant is pumped to the cooling system and through the coils or tubing at the rear of the appliance.
-
Page 9: Product Overview
Product Overview Temperature control & indicators Adjustable Feet Freezer flaps (4 star rating) Ice Cube Tray Freezer drawers (4 star rating) Vacuum Balancer* Unit Parts & Spare Parts Before installation, check that all parts detailed in the product overview are present. -
Page 10: Usage
Usage Allow to stand for a minimum of 3 hours before plugging in to the mains The temperature in the appliance is controlled by the temperature control panel located inside the freezer above the cavity. Press the control buttons to regulate the temperature inside the freezer. -
Page 11: Functions
Usage Super Freeze This function should be used as a rapid cool/freeze setting and is beneficial when freezing large amounts of food and preventing the loss of nutrients. Set this function 3 hours before a large amount of food is placed in the freezer. The temperature control will automatically revert back to its previous setting after a period of maximum 54 hours. -
Page 12: Door Reversal
Door Reversal You will need to tilt the appliance backward to access the lower hinge which holds screws. Do not tilt more than 45 degrees and do not lay the appliance flat on its side. For your own safety, a minimum of 2 people should lift or tilt this product. Tools Required: Cross headed screwdriver, flat headed screwdriver and hexagonal spanner. - Page 13 Door Reversal 4. Tilt the appliance carefully, no more than 45 degrees and remove the adjustable foot. 5. Take off the bottom hinge by removing the screws and moving the pin. 6. Move the hinge to the opposite side, install and affix feet. - 13 -...
- Page 14 Door Reversal 7. Move the bung on the bottom of the door to the opposite side. 8. Place the door on to the bottom hinge and put the pin of the upper/top hinge into the top of the door and fix the hinge in to place by screwing it to the top of the freezer (use a spanner to tighten it if necessary.
-
Page 15: Energy Saving Advice
Energy Saving Advice • Do not install the appliance close to sources of heat, such as a cooker, dishwasher or radiator. • Locate the appliance in a cool well-ventilated room and make sure that the air vents are clear. • Try to avoid keeping the doors open for a long time, warm air will enter the cabinet and may cause a build-up of ice as well as affecting the energy consumption. -
Page 16: Power Failure
Power Failure If there is a power failure during the storage of frozen foods, keep the door closed. If the temperature within your freezer should rise, do not refreeze the food without checking it's condition. • Ice Cream: Once thawed should be discarded. •... -
Page 17: Food Storage Advice
Food Storage Guidelines Refrigerator compartments Type of food Freezer drawer(s)/shelf Foods for long-term storage. Bottom drawer/shelf for raw meat, poultry, fish. Middle drawer/shelf for frozen vegetables, chips. Top drawer/shelf for ice cream, frozen fruit, frozen baked goods. - 17 -... -
Page 18: Maintenance & Cleaning
Maintenance & Cleaning Disconnect the appliance from the power supply before cleaning. Internal Cleaning • Do not pour water over the appliance. • The cavity should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water (5ml to 0.5 litre of water) •... -
Page 19: Defrosting
Maintenance & Cleaning Defrosting The refrigerator is a frost free product and will therefore defrost itself automatically. However in case the refrigerator is not defrosting then the refrigerator can be defrosted manually. Note: Care must be taken when performing the following procedure. •... -
Page 20: Trouble Shooting
Trouble shooting Problem Solution Check that the appliance is switched on. Check that there has not been a power cut. Check that the plug is not faulty. Check that the fuse has not blown. The freezer doesn't work Check that the voltage is correct for the appliance. Are there any faults with the socket? For this purpose, try the plug of your appliance by connecting it to a socket which you are sure is working. - Page 21 Trouble shooting Problem Solution Check all the food and drink that is in the freezer is correctly packaged. If it isn’t then it should be removed immediately or repackaged. Smell/odour Check for spillages on each shelf, flap and drawer. You may need to remove the drawers to check that no spillages have settled underneath them.
-
Page 22: Error Codes
Error codes Error code Solution When the alarm indicator keeps flashing (with the corresponding Indicates fault with the refrigerator. Please contact indicator light of “-16, -20, -24, or customer services. fast freezing” flickering simultaneously) - 22 -... -
Page 23: Connection To The Mains Supply
Connection to the Mains Supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC220V - 240V; 50HZ. Check that the voltage marked on the product corresponds with your supply voltage. For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which... -
Page 24: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Product Care. -
Page 25: Technical Specification
Technical Specification Model number RH54FR3FZ146 (B) (S) Rated Voltage 220V – 240V ~ 50Hz Capacity 175L External Dimensions(HxWxD) 1455mm x 540mm x 595mm (with handle) - 25 -... -
Page 26: Product Fiche
Product Fiche Model RH54FR3FZ146/B/S Fresh Food Storage Compartment Volume (L) Frozen Food Storage Volume (L) Storage Temperature ( ° C) -12 to -26 Energy Consumption (kWh/per year) Energy Consumption (kWh/per year), based on standard test results for 24 hours Household Appliance Category Energy Rating Defrosting Type Frost Free... - Page 27 Notes This page is intentionally blank. - 27 -...
- Page 28 Made by Product Care Trading Limited under license from Spectrum Brands (UK) Limited. Product Care Trading Limited, Wigan, WN2 4AY/ PCT (NI) Ltd, Belfast, BT5 5AD. Russell Hobbs is the registered trademark of Spectrum Brands (UK) Ltd. Russell Hobbs Support: call 0345 208 8750 or visit: mda.russellhobbs.com The ‘wheelie bin’...
