1. Product Features Support 4 Port Split in Any Configuration Seamless Switching Between Any Signals Smooth Fade in Fade out Transition Support 4Kx2K 8Kx1K 2Kx4K Pixel to Pixel Split Flexible Quad Layers display Support 4 Optional Module RCA Audio Output Jack Third Party Control with Open Protocol Optional Genlock Input for Cascade Split...
2. Product Introduction VS2 is a 4 output channels video processor. Can support flexible 4 port 3 Windows Display based split with 4 layers configuration. It can realize On 8Kx1K Split. Ideal for large scale or multiple layers project. VS2 Diagram Solution...
3. Hardware Overview 3.1 Front Panel OLED Display Panel Display the current working status and menu for buttons control. Knob For menu selection: rotating knob to find the option & press the knob to confirm. Buttons SAVE Button To save the parameters after setting, by using “LOAD” to load the saved data.
Page 6
Scale Button To adjust the size and position of the image by the number buttons”1-0” under M1-DVI4, or using the knob to adjust the number. INPUT Button To select source signal, the button lights up while used as input. When there are more than 2 buttons lighting up, the one flashing is the one just be chosen, and the steady lighting one is the source signal displayed, M1 represents SDI input.
3.2 Back Panel Comm & Update Connector USB port for update RS232 port for the use of communication and API and Third-Party control Input Connector Optional input module Support 4 input modules with HDMI\DVI\VGA\SDI\USB HDMI1.4 input Support 3840*2160@30HZ & 4K1K\2K1K inputs and customized input HDMI1.3 input Support 2K1K input and customized input resolution...
Page 8
Output connectors HDMI Loop The current image or window will be looped automatically without output processing DVI1 Output Support 2.5million pixels with widest 3840 pixels or highest 1920 pixels DVI2 Output Support 2.5million pixels with widest 3840 pixels or highest 1920 pixels RCA1 Audio Output External (LR stereo) output port match with the DVI1 output video...
4. Operations Menu structure Output Resolution Two Split Four Split Multi Picture Preview Mode EDID Management Volume System Factory reset Language 4.1 Menu Structure...
4.2 Output Resolution VS2 default output resolution is 1920*1080@60Hz, if user would like to change to 1536*1536@60Hz, the steps are as follows: 1.Press MENU button to find the output resolution and press knob to confirm. output Format 》 Two Split 》...
4.The setting is success after the arrow is disappear, press MENU and return to the previous menu to check if it was changed successfully. 1PA: HDMI1 1920 X 1080 @ 60 OUT: 1536 X 1536 @ 60 4.3 Two Port Split Two Port Split: DVI1 &...
Page 12
Set V total to be 960 Set the first display width to be 1792 by number button or rotation knob Split Mode Horizontal H Total 3228 V Total Width 1 1792 Rotate the knob to image layout menu and select single image, PIP, PBP and three images layouts.
4.4 Four Port Split Four Port Split: VS2 has 4 DVI outputs for 1x4 Horizontal Split, 4x1 Vertical Split and 2x2 Cross Split. With several image layout. Horizontal 1x4 Split with 3 Windows Display If user has a main screen with 3840x1152, the side screen is 640x960.
Page 14
The steps are as follows: 1. Set the Output Format as 2048x1152@60Hz. 2. Select the split model:Press Menu and rotate the knob to enter to Four Port Split, select horizontal 1x4 split: Output Format 》 Two Port Split 》 Four Port Split 》...
Current Window Width Height H Position Current Window Width Height H Position 6144 4.4 Multi-layer Multi-layer in single output Model 1:Single image with single output, in this model, press the layer buttons A, B, C & D to add any layer, edit the size of layer and the change the signal source Model 2:Four images in Cross, in this model, press layer buttons A,B,C &...
Page 16
input DVI1 as the source of layer B. IMAGE 》 WIDTH 》 HEIGHT 1080 》 H POSITION 》 V POSITION 》 》 》 》 2.After step 1 is done, we configure the layer A width and height to be 960 x 1080, move the layer A horizontal position to be 480 and the vertical position keep 0, press the relative input HDMI1 as the source of layer A.
4.5 Preview Mode Single Port Preview: DVI2 is for preview output and DVI1 is for program output, the signal input will be edited in preview output and switch to program output after pressing “TAKE” button. Quick Layout Single image switching Single image switch to PIP/PBP Single image switch to three images PIP switch...
User also are able to add and edit layer A,B,C & D and save the settings in advance, in the future, user can load the settings to the preview output by “LOAD” button and then switch the setting to program output by “TAKE”...
》 》 》 》 3. Select HDMI1 and press the knob to confirm, we can choose HDMI1.4(4K30Hz) or HDMI1.3(2K), but we will use the customized resolution to change the EDID. CUSTOMIZED 》 EDID HDMI 1.4 》 EDID HDMI 1.3 》 》...
Page 20
ZOOM:Cut off the image size. ZOOM UP ZOOM DOWN ZOOM UP & DOWN ZOOM FROM LEFT ZOOM FROM RIGHT ZOOM LEFT & RIGHT ZOOM IN MIDDLE RESET Output Port:change DVI1 & DVI2 output content IMAGE TYPE BIT WIDTH 10bit RANGE Image quality adjustment: adjust screen brightness, color temperature and GAMMA CONTRAST...
Page 21
RESET System information:View the information of version SERIES NO. 0031 SOFTWARE 》 HARDWARE 》 OLED BRIGHTNESS 12 4.8 Factory reset:Clear all Settings and restore the device 4.9 Language: select equipment in Chinese and English 4.10 Volume: adjust the volume from 0 to 100...
