Page 2: Table Of Contents
Content 1.Product Features ................. 1 2. Applications ..................2 3.Hardware Overview ................3 3.1 Front Panel ..................... 3 3.2 Back Panel ...................... 4 4. Features ..................... 5 4.1 Multiple video inputs ..................5 4.2 Duplicate video output interface with Audio ........... 6 4.3 Multiple output resolutions ................ -
Page 3: Product Features
1.Product Features Seamless switching between any source Free customized among 2.5 million Plug & Play USB Media Player EDID Management Open Protocol Control Built-in Sending Card Slot Signal Hot Backup Audio & Video Sync Switching ... -
Page 4: Applications
2. Applications... -
Page 5: Hardware Overview
3.Hardware Overview 3.1 Front Panel OLED display panel Display the current working status and menu for buttons control. Operating Keys Rotary Button： Adjust the menu position and parameters MENU Button： Press to enter into the menu, by using knob to find the specified menu, press MENU again to return to the previous menu. -
Page 6: Back Panel
Output： Enable CVB input HDMI Button： Enable HDMI input DVI Button： Enable DVI input VGA Button： Enable VGA input CV Button： Enable CVBS input USB Button： Switch to USB player/ Access to USB play list SDI Button： Enable SDI input 3.2 Back Panel... -
Page 7: Features
Sending Card Slot Support 2 sending card installation 4. Features 4.1 Multiple video inputs VA1 has 7-channel video inputs, including 1 composite video (Video), 1 channel VGA, 1 channel DVI and 1-channel HDMI, 2 channel USB Player and 1 Channel... -
Page 8: Duplicate Video Output Interface With Audio
2 Channel USB can support hot-swap. Then screen will not go constant black during update USB content. 4.2 Duplicate video output interface with Audio VA1 has two video outputs (2 DVI) with 1x 3.5mm Audio Output jack to play audio from HDMI DVI or USB player. 4.3 Multiple output resolutions VA1 has up to 20 presets of output resolutions. -
Page 9: Black/Freeze Images
When the screen freezes, the operator can also change the current input or change cables, etc. 4.7 Part Function VA1 can crop part of screen or play the full screen. Any input channel can be independently set cropped, and each channel is still able to achieve a seamless switching. -
Page 10: Sending Card Installation
4.9 Sending Card Installation VA1 have built-in sending card slots. It can support 2 x sending cards with small load capacity (MSD300, TS802.etc) or 1 x sending cards with big load capacity (MSD600, TS902.etc) 5. General...
