AVPTC**14**
AIR HANDLERS
INSTALLATION & OPERATING INSTRUCTIONS
Contents
1 Important Safety Instructions .................................... 2
2 Shipping Inspection ................................................... 3
3 Codes & Regulations .................................................. 3
4 Replacement Parts ..................................................... 3
5 Pre-Installation Considerations ................................. 3
6 Installation Location ................................................... 3
7 Refrigerant Lines ........................................................ 5
8 Condensate Drain Lines ............................................. 8
9 Ductwork ..................................................................... 9
10 Return Air Filters ......................................................... 9
Leakage Rate ............................................................... 9
12 Electric Heat ................................................................ 9
13 Electrical and Control Wiring................................... 10
14 AVPTC Motor Orientation ......................................... 11
15 Cool Cloud HVAC Phone Application ...................... 11
Outdoor Units ............................................................ 12
Outdoor Units ............................................................ 12
18 Dehumidification ....................................................... 14
19 Auxiliary Alarm Switch ............................................ 14
20 Start-Up Procedure ................................................... 14
21 Accessories ............................................................... 14
22 Ramping Profiles ...................................................... 15
23 Electric Air Cleaner Warning.................................... 15
24 Start-Up Procedure ................................................... 16
25 Regular Maintenance ................................................ 16
26 Air Handler Troubleshooting Matrix ........................ 17
27 Air Handler Display .................................................. 19
28 Airflow Label ............................................................ 22
29 Wiring Diagram ........................................................ 23
ATTENTION INSTALLING PERSONNEL
Prior to installation, thoroughly familiarize yourself with this Instal-
lation Manual. Observe all safety warnings. During installation or
repair, caution is to be observed. It is your responsibility to install the
product safely and to educate the customer on its safe use.
RECOGNIZE THIS SYMBOL AS A
SAFETY PRECAUTION.
is a registered trademark of Maytag Corporation or its related companies and is used under license. All rights reserved.
© 2018-2020 Goodman Manufacturing Company, L.P.
19001 Kermier Rd., Waller, TX 77484
www.goodmanmfg.com - or - www.amana-hac.com
P/N: IOA-4030C Date: June 2020
Only personnel that have been trained to install, adjust, ser-
vice or repair(hereinafter, "service") the equipment specified
in this manual should service the equipment. The manufac-
turer will not be responsible for any injury or property dam-
age arising from improper service or servide procedures.
If you service this unit, you assume responsibility for any
injury or property damage which may result. In addition, in
jurisdictions that require one or more licenses to service the
equipment specified in this manual, only licensed personnel
should servise the equipment.
Improper installation, adjustment, servicing or repair of the
equipment specified in this manual, or attempting to install,
adjust, service or repair the equipment specified in this
manual without proper training may result in product dam-
age, property damage, personal injury or death.
PROP 65 WARNING
FOR CALIFORNIA CONSUMERS
WARN ING
www.P65Warnings.ca.gov
This device, which was assembled by Goodman Manufacturing
Company, L.P., contains a component that is classified as an
intentional radiator. This intentional radiator has been certified by
the FCC: FCC ID QOQBGM111. And this international radiator has
an Industry Canada ID: IC 5123A-BGM111.
This device complies with Part 15 of the FCC's Rules. Operation of
this device is subject to two conditions:
(1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including
interference that may cause undesirable operation.
And this device meets the applicable Industry Canada technical
specifications.
The manufacturer of the intentional radiator (model no. BGM111) is
Silicon Laboratories Finland Oy, which can be contacted by calling
617-951-0200. (www.silabs.com)
The FCC responsible party is Goodman Manufacturing Company,
L.P., and may be contacted by calling (713)-816-2500, or at 19001
Kermier RD., Waller TX 77484. (www.GoodmanMFG.com)
This equipment complies with FCC radiation exposure limits. To
ensure compliance, human proximity to the antenna shall not be
less the 20cm during normal operations.
WARNING
-
0140M00517-A
