- Page 1 Control Box Wiring & Programming Guide G8-2-23-1...
- Page 2 Gel Pad Buttons and Functions The Gel Pad is the primary control center for your lift. Here you can turn your unit off and on, send the unit to its levels, or stop travel in any direction. The remotes are also programmed from the Gel Pad.
- Page 3 1. Have all remotes present. 2. Press and hold the learn button on the gel pad until the green LED beside the button lights up (approximately 3 seconds). 3. Press either the up or down button on your remote; you will see a corresponding flash from the learn LED.
- Page 4 1. Have all remotes present. 2. Press and hold the learn button on the gel pad until the green LED beside the button lights up (approximately 3 seconds). 3. Press either the up or down button on your remote, you will see a corresponding flash from the learn LED.
- Page 5 This diagram is only for 60Hz 240VAC. Verify line in voltage before connecting. If you are not sure of the operation and/or installation of this unit, contact an electrician or contact our office. Galaxy Unlimited, LLC is not responsible for incorrect field wiring, damages to equipment or harm to anyone or anything.
- Page 6 This diagram is only for 60Hz 120VAC. Verify line in voltage before connecting. If you are not sure of the operation and/or installation of this unit, contact an electrician or contact our office. Galaxy Unlimited, LLC is not responsible for incorrect field wiring, damages to equipment or harm to anyone or anything.
- Page 7 Verify that the lift does indeed go up and down with the remote and gel pad. On a 2-stop these are the three wires (five for 3- stop) with wire nuts coming off the control board. Separate these wires. Then, connect these wires to your limit switch cord, color to color.
- Page 8 Limit Switch Setup Continued 3. While observing cams of the limit switch raise the lift a foot or so and take note of the direction that the cams are rotating. It is good practice to mark this direction of rotation; an example is shown to the right.
- Page 9 Failure to follow these instructions will void all warranties to equipment as written or implied. Galaxy Unlimited LLC will assume no responsibility to damages that were a result of improper installation or user error.
- Page 10 Not-Used 5) Route all wires and tuck the circuit board back in its place. 6) Reinstall Gel Pad. Route the ribbon cable so that it does not kink sharply. 7) Reconnect power to the Galaxy control box and test!
- Page 11 Pan Switch The Pan Switch Assembly connects as shown. Mount each rocker approximately 6” from the edge of the unit on the subfloor beams. Then you will drill an 11/16” hole in the beam and install the cable gland as shown.
- Page 12 Galaxy Unlimited, LLC Remote Control Box Warranty This warranty is for the electrical components of the Remote Control Box which begins on the day of purchase from Galaxy Unlimited, LLC for a period of 1 year thereafter. During this period, Galaxy Unlimited, LLC will...
