INTU Recessed Electric Fireplace
Model # :
INTU 36
INTU 50
INTU 60
INTU 72
OWNER'S MANUAL
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
WARNING
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
Advertisement
Table of Contents
Related Manuals for Ignis INTU 36
Summary of Contents for Ignis INTU 36
- Page 1 ® IGNIS INTU Recessed Electric Fireplace Model # : INTU 36 INTU 50 INTU 60 INTU 72 OWNER’S MANUAL Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could WARNING result in fire, electric shock, or serious personal injury.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION! WARNING ⚫ Read all instructions before using this electric fireplace! ⚫ This electric fireplace is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this electric fireplace. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3-feet (0.9m) from the front of the fireplace and keep them away from the sides and rear. - Page 3 ⚫ Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside! ⚫ ALWAYS turn this appliance off before unplugging it from the outlet. ⚫ ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace. ⚫...
-
Page 4: Parts And Hardware
I - Plastic Tray Pebbles Crystals Fixed on back of firebox Specification and Dimension PRODUCT DIMENSIONS Model Number 36" 21.46" 33.63" 5.86" 31" 11.69" 5.03" INTU 36 915CM 54.4CM 855CM 14.9CM 788CM 297CM 128CM 50" 21.46" 47.63" 5.86" 45" 11.69"... -
Page 5: Installation And Assembly
Installation and Assembly ALWAYS unplug this fireplace heater before assembly or cleaning, or before relocating. Failure to do so could result in electric shock, fire, or personal injury. Your appliance is a wall-mounted, recessed and/or mantel installed appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture, and high traffic areas. - Page 6 Select a dry wall to open a hole for the fireplace. Recess opening may be found in the chart below: Figure ( A ) Recess Opening Dimensions Model Number Width Height INTU 36 34.19 (869CM) 22.28 (56.59CM) " " INTU 50 48.19...
- Page 7 Figure ( B ) STEP 2. Place the fireplace to a soft, clean place. using the screwdriver to take off the TWO screws in both sides. Figure (B) Figure ( C ) STEP 3. Have two people to pull the trim up, then take them out of the fireplace box. Figure (C)
- Page 8 Figure ( D ) STEP 4. Using the screwdriver, take off the 8 screws as in above Figure (D). Have two people take out the glass panel as in Figure (E) and move it to a clean, soft place to avoid scratching. Figure ( E )
- Page 9 STEP 5. Have two people lift the fireplace box and place it into the recess. Fixing the FOUR wall screws in each side of the fireplace box. Figure (F) Figure ( F ) STEP 6. Place the decorative crystals (For crystals ember installation please refer to Page 10). Move and replace the glass panel and metal trim with screws.
-
Page 10: Wall Mounted Installation
Wall Mounted Installation Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. Select a location that is not prone to moisture and is located at least 36" (914mm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc. - Page 11 HARD WIRING INSTALLATION WARNING TURN OFF THE APPLIANCE COMPLETELY AND LET COOL BEFORE SERVICING. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE. HARD WIRING CONNECTION If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the household wiring.
- Page 12 Glass front must be removed, and the appliance must be mounted in its final location before the log / crystal / pebble ember sets are installed. If your fireplace includes a log set, remove the log set from the package, place it into the fireplace’s designated place.
-
Page 13: Operation
Operation Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. Power Make sure the ON/OFF switch, located on the left side panel, is in the OFF position. Plug the power cord into a 110~120 Volt 15 Amp grounded outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3). - Page 14 FLAME button: Makes flame effect 1. Press once. Flame brightness effect dimmer and brighter. gets changing. NOTE: Flame effect stays on until power 2. Press again. until desired setting is button is turned off. Flame effect must be FLAME reached. on for heater to turn on.
-
Page 15: Care And Maintenance
Care and Maintenance Cleaning ALWAYS turn the appliance OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury. - Page 16 Ignis Development Inc. 409 Joyce Kilmer Ave, Unit 5B New Brunswick, NJ 08901 1.855.694.4647 info@ignisproducts.com...
