- Page 1 User Manual 67182 NSH3 Slag Removal Tool for narrow slat spacing for use on laser cutting machines with minimum 1.25” between slats Slatpro LLC 4757 Mustang Circle Mounds View, MN USA Phone: +1 763-452-4550 Fax: +1 763-452-4560 sales@slatpro.com www.slatpro.com...
-
Page 2: General Safety Instructions
1. Safety 1.1 General Safety Instructions ΔWARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. 1.2 Slaghog Specific Safety Warnings and Instructions A. - Page 3 2.3 Maintenance The ventilation slots must be kept clear or over-heating may result. If the supply cord is damaged it must only be replaced by qualified personnel. Only use Slatpro replacement parts when performing repairs or maintenance. 2.4 Technical Information Technical Data ...
-
Page 4: Initial Assembly
2.5 Symbols Caution! Warning! Danger! Always disconnect the plug from the socket before carrying out any instructions Please read the instructions carefully before starting the machine. Tool uses protective earth and must be plugged into grounded outlet 3. Description The tool is moved along the slats on the bed of a laser machine to remove slag that accumulates while cutting. - Page 5 The tool has two on/off switches Rocker switch on handle end, in off position, acts as circuit breaker reset in case of over- Rocker Switch on power unit in off position. current Both switches must be in ON or “l” position to run. Turning either switch OFF (“0” position) stops motor operation.
- Page 6 To see the unit in operation, go to Youtube and search for Slaghog. The best video is: https://www.youtube.com/watch?v=PDvEFRREdgg The cutter geometry is ideal for most slat/pallet bed configurations. If the fit of the cutters on the slats does not seem correct contact the factory to find out options that are available. When storing in upright position the unit is unstable and care must be taken to ensure that it does not fall over, which may lead to damage of handle end components.
-
Page 7: Maintenance
6. Maintenance WARNING Disconnect power by unplugging from outlet before performing any work on the tool 6.1 Cutters The cutters will wear over time and require replacement. Tools required for replacement 6mm L hex wrench 6mm male hex socket wrench ... - Page 8 Place adjustable wrench on flats of right shaft and remove left cutter with counterclockwise rotation. Slide the new right hand and the left-hand cutters so that the flats between the shaft are facing the base plate as shown. The cutters rotate so that the slag chips are pulled up toward the base plate. The cutters must be installed as shown.
-
Page 9: Motor Brushes
6.2 Motor Brushes If the tool has less torque while in use, it is likely that the brushes need replacement. Parts Required: Qty 1 of 67179SET Brush Kit for SH3 There are access holes to brushes in top and bottom of Motor Enclosure Unthread and remove Brush Caps from motor Remove old brushes and install new and thread caps back in place 6.3 Other maintenance... - Page 10 EXCLUSIVE REMEDY. In the event that Slatpro determines that a Product contains a defect in materials or workmanship, then Slatpro, in its sole discretion, will (a) repair the Product, (b) replace the Product with new or rebuilt (c) refund the purchase price of the Product. THIS LIMITED WARRANTY IS EXCLUSIVE...
- Page 12 Slag Hog Assembly P/N: 67182-120V or -230V Model NSH3 Item Part No. Description sheet 1 of 2 The following items are for the drive portion of the assembly Input Shaft 67121 66143 Cutter Shaft 66135 Idler Shaft 67077 Driven Idler Shaft 66140 Gear Support Plate Cutter Side 66141...
- Page 13 Slag Hog Assembly P/N: 67182 Model NSH3 Item Part No. Description sheet 2 of 2 The following items are for the housing portion of the assembly 67114 Side Plate Set 67164 Base Plate Motor Mount Plate 67120 Oring -047 9452K312 67118 Motor -120V or -230V Gear 93T 67155...
