Summary of Contents for Genesis LGHW-3020
- Page 1 Hard Wired Hard Wired PIR Detector PIR Detector Installation Installation Handbook Handbook Type: LGHW-3020 Issue 2. 2a BELLEVUE ROAD, FRIERN BARNET, LONDON, N11 3ER Tel: 0044 (0) 208 368 7887 Fax: 0044 (0) 208 368 3952...
- Page 2 When the product is sealed it is water resistant to IP67. Box Contents. 1 x GENESIS 3020 Hard wired PIR detector 1 x sun shield 4 x no 8 wall plugs 4 x no 8 2”...
- Page 3 IR transmission detects masking (cloak) and a light and thermal sensor allow the detector to compensate for the outdoor environment. Operating voltage is 12 Volts DC. LGHW-3020 Hard Wired PIR Detector Installation Handbook Page 1.
- Page 4 Avoid facing foliage such as trees that can move in the wind. 2.5m Do not aim the detector at reflective surfaces such as cars and windows. Mounting height LGHW-3020 Hard Wired PIR Detector Installation Handbook Page 2.
- Page 5 IE: A must be followed by B within a short time period. This helps reduce activations from fluttering material and reflections etc. Detection works best when the subject walks ACROSS the beams and not TOWARDS the detector. 2.5m LGHW-3020 Hard Wired PIR Detector Installation Handbook Page 3.
- Page 6 1 but should not be used with high levels of pulse counting. Light calibration and restore defaults are special features and covered in other docu- ments. LGHW-3020 Hard Wired PIR Detector Installation Handbook Page 4.
- Page 7 NB: The switch settings are read only once when the power is connected. If any switches need to be changed the power must be disconnected and re-connected in order for the change to take place. LGHW-3020 Hard Wired PIR Detector Installation Handbook Page 5.
- Page 8 Luminite Genesis product range Wireless products Wireless PIR’s 30m x 20m LGWP3020 Wireless PIR’s 15m x 20m LGWP1520 Wireless PIR’s 40m x 4.5m LGWP4004 Wireless PIR’s 12m Horizontal curtain LGWP12HC Wireless PIR’s 12m Vertical curtain LGWP12VC Masthead/Repeater LGMT434 Masthead Relay Unit...
