Summary of Contents for Linksys PCM200HA
- Page 1 HomeLink ® Series Phoneline 10M Integrated PC Card Use this User Guide to Install the PCM200HA User Guide...
-
Page 2: Copyright And Trademarks
Linksys reserves the right to revise or update its products, software, or documentation without obligation to notify any individ- ual or entity. -
Page 3: Table Of Contents
Introduction The Linksys Phoneline 10M Integrated PC Card Congratulations on your purchase of the Linksys HomeLink Phoneline 10M Integrated PC Card. The Linksys HomeLink Phoneline 10M Integrated PC Card now offers instant connectivity to multiple PC's over a home's existing telephone lines. -
Page 4: Package Contents
The Transfer LED will blink green when data is being transmitted across the phone cable. The Phone port will allow you to connect a standard telephone to your PCM200HA. You may also use the phone port to connect to another HomeLink-equipped PC or into a phone jack. network. -
Page 5: Installing The 10M Integrated Pc Card
3. Attach one end of the telephone cable to the HomeLink card’s HomeLink port. Connect the other end of the cable into the telephone jack in your wall. The hardware installation is complete. Linksys HomeLink Series Phoneline 10M Integrated PC Card Connecting to a Phoneline Network Connecting to a Phoneline Network Computers on a HomeLink network can be connected in one of two ways. -
Page 6: Windows 98 And Me Installation And Setup
4. Select Search for the best driver for your device (Recommended). Click Next. 5. Select "CD-ROM drive". Click Next to continue. 6. A window will open saying that Windows is now ready to install the Linksys Phoneline 10M Integrated PC Card driver (seen on the next page). Click Next. - Page 7 M M E E S S S S A A G G E E I I N N S S T T R R U U C C T T I I O O N N S S • If your PC asks for the Linksys 1. Click O O K K .
- Page 8 • Linksys HomeLink Phoneline 10M Integrated PC Card • TCP/IP Dial-Up Adapter • TCP/IP Linksys HomeLink Phoneline 10M Integrated PC Card 3. Click on the Configuration tab, followed by the File and Print Sharing button. The File and Print Sharing window will appear.
- Page 9 This box is optional. Do not click OK when you have completed these fields. Phoneline 10M Integrated PC Card Linksys HomeLink Series 11. Optional: Choose the Access Control tab. Ensure that Shared-level access control is selected. If the setting is on User-Level access control and you can’t change it, skip to problem 6 in the Troubleshooting section.
-
Page 10: Troubleshooting
2. Windows will display the Found New Hardware Wizard box. Click Next. Insert the Linksys HomeLink Phoneline 10M Integrated PC Card Driver CD into your CD-ROM drive. N N o o t t e e : : Prior to... - Page 11 3. The Install Hardware Device Drivers dialog box will appear. When Linksys HomeLink Phoneline 10M Integrated PC Card is displayed, select “Search for a suitable driver for my device (Recommended)”. Click Next. 4. The Locate Driver Files dialog box will appear. Select the CD-ROM drive option.
-
Page 12: Troubleshooting
Windows’ networking. To do this, click on Start, Settings, Control Panel, then double-click on Network. Click once on the component entry with the words TCP/IP and Linksys or TCP/IP on its own, then click on the Remove button. Click OK when finished and restart your... -
Page 13: Appendix
When asked to restart your PC, remove any floppy disks and click OK. Be sure to do this on all of your computers that are having trouble seeing your entire network. Phoneline 10M Integrated PC Card Linksys HomeLink Series Appendix Sharing Your Files and Printers Overview By sharing your files and printers, other PCs on your network will be able to access the resources on your PC. -
Page 14: Starting Over In Windows 98, Me, Or 2000
Control Panel. 2. Double-click on the Network Icon. 3. If the Configuration box has a component called Dial-Up Adapter, skip forward to step 5. If it doesn’t, continue with step 4. N N o o t t e e : : Any printer you... - Page 15 4. Remove any instance of the name Linksys in the box. This includes IPX/SPX…Linksys, NetBEUI…Linksys, and TCP/IP…Linksys. Also remove Client for Microsoft Networks, Client for NetWare Networks, and File and Printer Sharing for Microsoft Networks. In some cases, removing one of these components may in turn automati- cally remove other components as well.
- Page 16 9. Remove all devices with the name Linksys in it’s description. (If at any point you are asked to restart the computer, Click No). 10. Scroll down to the Other Devices listing. Click the plus [+] sign. Remove PCI Ethernet Controller or PCI Ethernet Adapter. (If Other Devices is not listed, proceed to the next step.)
-
Page 17: Manually Installing The Network Components In
• Linksys HomeLink Phoneline 10M Integrated PC Card • TCP/IP Dial-Up Adapter • TCP/IP Linksys HomeLink Phoneline 10M Integrated PC Card There may be other components listed in addition to the ones shown above. If any of the above components are missing, add them as follows. -
Page 18: Specifications
Plug your telephone or fax machine into one of the splitter’s ports, and your HomeLink Phoneline 10M Integrated PC Card into the other. Linksys HomeLink Series Phoneline 10M Integrated PC Card Specifications Model Number:... -
Page 19: Warrant Information
CALL LINKSYS FOR MORE DETAILS. Phoneline 10M Integrated PC Card Linksys HomeLink Series Contact Information For help with the installation or operation of this product, contact Linksys Customer Support at one of the phone numbers or Internet addresses below. Sales Information Tech Support... - Page 20 h t t p : / / w w w. l i n k s y s . c o m...
