Linksys PCM1000 Quick Installation

®
A Division of Cisco Systems, Inc.
Package Contents
• One PCM1000 Gigabit Notebook
Adapter
• Setup Wizard CD-ROM with User Guide
in PDF format
• One Quick Install ation Guide
• Network Cable
• Registration Card
Quick Installation
Gigabit Notebook Adapter
Quick Installation
WIRED
Model No. PCM1000
Model No.
1

Install the Driver

IMPORTANT: Make sure to run the Setup
Utility before installing the Adapter or the
Setup won't work,
A
Insert the Setup Utility CD into
your PC's CD-ROM drive.
B
The Setup Utility's Welcome
screen should appear on your
monitor. If it does not, this
means the Setup Utility is not
automatically running as it
should. Start the Setup Utility
manually by clicking the Start
B
button, selecting Run, and typ-
ing d:\setup.exe (where "D" is
your PC's CD-ROM drive).
Click the Install button.
C
The Welcome screen will
appear. Click Next.
C
D
The Choose Destination Loca-
tion folder will appear next. To
install the driver in the default
folder location, click Next.
D
1
To install the driver in a different
folder, click Browse and select
a folder location. Then, click
Next.
D
2
E
The driver files will be copied
onto your PC.
E
F
This screen will appear when
the installation is complete.
Click Finish.
G
Click the Exit tab to exit the Util-
ity.
F
Continue to Step 2 to install the
Adapter.
2

Install the Hardware

A
Make sure that your Notebook
PC is turned off.
B
Locate your PC's PCMCIA slot
(usually located on the side).
Insert the pin end of the Giga-
bit Notebook Adapter into the
slot with the LEDs facing up. B
Make sure that the Adapter
seats firmly in place.
C
Connect an Ethernet cable to
the Ethernet port on the
Adapter, then connect the
other end to the Ethernet port
on the switch or other network-
ing device.
C
The setup and hardware
insttallation are complete.
For additional information or troubleshooting help, refer
to the User Guide on the Setup CD-ROM. You can also call
or email for further support.
24-hour Technical Support
800-326-7114
(toll-free from US or Canada)
E-mail Support
support@linksys.com
Website
http://www.linksys.com or
http://support.linksys.com
RMA (Return Merchandise Authorization)
http://www.linksys.com/support
FTP Site
ftp://ftp.linksys.com
Sales Information
800-546-5797 (800-LINKSYS)
