SATTLER LUCE VERDE ANELLO Assembly Instruction Manual

Assembly instruction
Date: 21.09.15
LUCE VERDE ANELLO
Safety instructions:
Read all of these instructions before installing fixtures.
• Keep all of the instructions for future reference.
• Turn off power before installing fixture.
• Installation is to be performed by a qualified electrician
only.
• All installations are to conform to the standards of
National Electrical Code as well as all local
jurisdictional codes and regulations.
• Any modification of the luminaire will void any and all
written or implied warranties.
• Do not open the luminaire - this will void the IP rating
• The manufacturer accepts no responsibility for
damage to persons of property arising through
improper use or installation.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE
WITH THE APPLICABLE INSTALLATION CODE BY A
PERSON FAMILIAR WITH THE CONSTRUCTION AND
OPERATION OF THE PRODUCT AND THE HAZARDS
INVOLVED
BO
Package 1, Frame
Aluminium-ringframe
Package 2, technical unit
Steel cable 5 m four-part
4 x straight suspension
Steel cable 5 m four-part
1 x trapeze suspension
Supply line Tu-Lf
Gloves, white
Screwdriver
Assembly instruction
Backup: Push terminal quadruple
Push terminal double
Stainless steel Decoration screw
RGB, X-Fade 6-channel
White, Dimmer 1-10 V Dimmer
DALI
pos. quantity
1
1 unit
2
3
1 unit
3
1 unit
4
1 unit
5
1 pair
5
1 unit
5
1 unit
1 unit
1 unit
1 unit
1 unit
1 unit
1 unit
Technical data:
Frame
Circular aluminum-profile with translucent film. Inner sur-
face made of dried moss. Pendant light full-scale lighting,
wall lamp from the outside inwards slightly decreasing
illumination.
Dimension
Ø 2000 H 60 B 260 mm
Ø 78.7" H 2.4" B 10.2"
1
1
Fixture technical-unit
Weight Weight
22 kg 5 kg
48.5 lb
11 lb
3
2
4
5
