Contents
1
Area of applicability ................................................................................................................. 4
2
General information ................................................................................................................. 4
3 Important specification in the type code ............................................................................... 5
4 Technical data .......................................................................................................................... 6
5 Application conditions ............................................................................................................ 7
6
Protection against static electricity ....................................................................................... 8
7
Use of an overvoltage arrester ............................................................................................... 9
8 Grounding ................................................................................................................................. 9
9 Impact and friction sparks ...................................................................................................... 9
10 Material resistance .................................................................................................................. 9
11 Mounting with external display unit VEGADIS 61/81 ............................................................ 9
12 Removing and replacing the red threaded/dust cover ...................................................... 10
Supplementary documentation:
•
Operating Instructions VEGAPULS 61
•
EU-type approval certificate PTB 03 ATEX 2089 X (Document ID: 37990)
•
EU declaration of conformity (Document ID: 43634)
Editing status: 2020-02-28
2
VEGAPULS 61
Advertisement
Table of Contents
Related Manuals for Vega VEGAPULS 61 Series
Summary of Contents for Vega VEGAPULS 61 Series
-
Page 1: Table Of Contents
Contents Area of applicability ......................... 4 General information ......................... 4 3 Important specification in the type code ................5 4 Technical data .......................... 6 5 Application conditions ......................7 Protection against static electricity ..................8 Use of an overvoltage arrester ....................9 8 Grounding ..........................9 9 Impact and friction sparks ...................... 9 10 Material resistance ........................ - Page 2 VEGA upon request. Les présentes consignes de sécurité sont disponibles au téléchargement sous www.vega.com en standard en allemand, en anglais, en francais et en espagnol. VEGA met à disposition d'autres langues de l'Union Européenne selon les exigences.
-
Page 3: Area Of Applicability
Area of applicability These safety instructions apply to the radar sensor VEGAPULS 61 series VEGAPULS PS61(*).C****P/K/F/L**** according to EU type approval certificate PTB 03 ATEX 2089 X (certificate number on the type label) and the number of the safety instruction (37991) on the type label. -
Page 4: Important Specification In The Type Code
Important specification in the type code VEGAPULS PS61(*).abcdefghij Position Feature Description ATEX II 1G, 1/2G, 2G Ex ia IIC T6 Approval ATEX II 1G, 1/2G, 2G Ex ia IIC T6 + WHG ATEX II 1G, 1/2G, 2G Ex ia IIC T6 + Ship approval with encapsulated horn antenna (ø 40 mm) / PVDF / -40 … +80 °C Version / Material / Pro- cess temperature with plastic horn antenna (ø... -
Page 5: Technical Data
Position Feature Description without mounted without; lid with inspection window Laterally mounted Display and adjustment module PLICSCOM mounted; with Bluetooth, magnetic pen operation laterally mounted; with Bluetooth, magnetic pen operation mounted; with Bluetooth, magnetic pen operation, battery laterally mounted; with Bluetooth, magnetic pen operation, battery without Additional equipment with equipment... -
Page 6: Application Conditions
= 310 µH and C = 2 µF are not cable cable exceeded. When using the delivered VEGA connection cable between VEGAPULS PS61(*).C****P/K/F/L**** and the external indicating unit VEGADIS 61/81, the following listed cable inductances L and cable capacitances C must be taken into account with a cable length ≥... -
Page 7: Protection Against Static Electricity
Category 1G instruments Temperature class Temperature on the antenna Ambient temperature on the elec- tronics -20 … +42 °C -20 … +42 °C T4, T3, T2, T1 -20 … +60 °C -20 … +60 °C For applications requiring instruments of category 1G the process pressure of the media must be between 0.8 …... -
Page 8: Use Of An Overvoltage Arrester
VEGADIS 61/81 should be set up without grounding. The required insulation voltage is > 500 V AC. When using the VEGA connection cable included with the delivery, this requirement is fulfilled. If grounding of the cable screen is required, it must be carried out according to EN 60079-... -
Page 9: Removing And Replacing The Red Threaded/Dust Cover
When using certified i.e. suitable cable glands, sealing plugs or plug connectors, they must be mounted correctly and the respective certificates/documents must be observed. The sealing plugs included in the delivery by VEGA meet the necessary requirements. Red threaded or dust protection cap... - Page 10 Notes VEGAPULS 61...
