Related Manuals for Vega VEGAPULS 62 standpipeversion

Summary of Contents for Vega VEGAPULS 62 standpipeversion

  • Page 1: Operating Instructions

    Operating Instructions VEGAPULS 62 standpipe version Foundation Fieldbus Document ID: 36510 Radar...

  • Page 2: Table Of Contents

    Contents Contents About this document Function........Target group ......Symbolism used.
  • Page 3 Contents Communicator 375, 475 ..... . 34 Diagnosis, Asset Management and service Maintaining ....... 35 Measured value and event memory .

  • Page 4: About This Document

    1 About this document 1 About this document 1.1 Function This operating instructions manual provides all the information you need for mounting, connection and setup as well as important instructions for maintenance and fault rectification. Please read this information before putting the instrument into operation and keep this manual accessible in the immediate vicinity of the device.

  • Page 5: For Your Safety

    2 For your safety 2 For your safety 2.1 Authorised personnel All operations described in this operating instructions manual must be carried out only by trained specialist personnel authorised by the plant operator. During work on and with the device the required personal protective equipment must always be worn.

  • Page 6: Ce Conformity

    2 For your safety Depending on the instrument version, the emitting frequencies are in the C or K band range. The low emitting frequencies are far below the internationally approved limit values. When used correctly, there is no danger to health. 2.5 CE conformity The device fulfills the legal requirements of the applicable EC guidelines.

  • Page 7: Environmental Instructions

    2 For your safety The device must be non-sensitive to interfering immissions, including those that may cause undesirable operating conditions. Modifications not expressly approved by the manufacturer will lead to expiry of the operating licence according to FCC/IC. The instrument is in conformity with RSS-210 of the IC regulations. The instrument may only be operated in closed vessels made of metal, concrete, or fibre-reinforced plastic.

  • Page 8: Product Description

    Order-specific instrument features (HTML) Operating instructions at the time of shipment (PDF) Order-specific sensor data for an electronics exchange (XML) Test certificate "Measuring Accuracy" (PDF) Go to www.vega.com, "Service" "VEGA Tools" and "serial number search". VEGAPULS 62 standpipe version • Foundation Fieldbus...

  • Page 9: Principle Of Operation

    3 Product description Scope of the operating This operating instructions manual applies to the following instrument instructions manual versions: Hardware from 2.1.1 Software from 4.4.0 Versions The instrument is available in two different electronics versions. Each version can be identified via the product code on the type label as well as on the electronics.

  • Page 10: Packaging, Transport And Storage

    3 Product description Functional principle The antenna of the radar sensor emits short radar pulses with a duration of approx. 1 ns. These pulses are reflected by the product and received by the antenna as echoes. The running time of the radar pulses from emission to reception is proportional to the distance and hence to the level.
  • Page 11 The interface adapter VEGACONNECT enables the connection of communication-capable instruments to the USB interface of a PC. For parameter adjustment of these instruments, an adjustment software such as PACTware with VEGA-DTM is required. You can find further information in the operating instructions "Interface adapter VEGACONNECT" (Document-ID 32628).

  • Page 12: Mounting

    4 Mounting 4 Mounting 4.1 General instructions Screwing in With instruments with threaded process fitting, suitable tools must be applied for tightening the hexagon. Warning: The housing must not be used to screw the instrument in! Applying tightening force can damage internal parts of the housing. Moisture Use the recommended cables (see chapter "Connecting to power supply") and tighten the cable gland.

  • Page 13: Connecting To The Bus System

    5 Connecting to the bus system 5 Connecting to the bus system 5.1 Preparing the connection Safety instructions Always keep in mind the following safety instructions: Connect only in the complete absence of line voltage If voltage surges are expected, install overvoltage arresters The instrument requires a operating voltage of 9 …...

  • Page 14: Connect

    5 Connecting to the bus system 5.2 Connect Connection technology The voltage supply and signal output are connected via the spring- loaded terminals in the housing. The connection to the indicating and adjustment module or to the interface adapter is carried out via contact pins in the housing. Connection procedure Proceed as follows: Unscrew the housing cover...

  • Page 15: Wiring Plan, Single Chamber Housing

    5 Connecting to the bus system Tighten the compression nut of the cable entry. The seal ring must completely encircle the cable 10 Screw the housing cover back on The electrical connection is finished. Information: The terminal block is pluggable and can be removed from the electronics.

  • Page 16: Wiring Plan, Double Chamber Housing

    5 Connecting to the bus system 5.4 Wiring plan, double chamber housing Electronics compart- ment 6 7 8 Fig. 4: Electronics compartment, double chamber housing Internal connection to the connection compartment Contact pins for the indicating and adjustment module or interface adapter Simulation switch ("on"...

  • Page 17: Wiring Plan With Double Chamber Housing Ex D

    5 Connecting to the bus system Radio module PLICS- MOBILE integrated in Status the connection compart- SIM-Card Test ment Fig. 6: CConnection of the voltage supply of the radio module Voltage supply You can find detailed information for connection in the supplementary instructions "PLICSMOBILE GSM/GPRS radio module".
  • Page 18 5 Connecting to the bus system Connection compart- ment Fig. 8: Connection compartment, double chamber housing Ex d Voltage supply, signal output Ground terminal for connection of the cable screen Plug M12 x 1 for external indicating and adjust- ment unit Fig.

  • Page 19: Wiring Plan - Version Ip 66/Ip 68, 1 Bar

    5 Connecting to the bus system 5.6 Wiring plan - version IP 66/IP 68, 1 bar Wire assignment con- nection cable Fig. 10: Wire assignment fix-connected connection cable brown (+) and blue (-) to power supply or to the processing system Shielding 5.7 Switch-on phase After VEGAPULS 62 is connected to the bus system, the instrument...

  • Page 20: Set Up With The Indicating And Adjustment Module

    6 Set up with the indicating and adjustment module 6 Set up with the indicating and adjustment module 6.1 Insert indicating and adjustment module The indicating and adjustment module can be inserted into the sensor and removed any time. Four positions displaced by 90° can be selected.
  • Page 21 6 Set up with the indicating and adjustment module Fig. 12: Insertion of the indicating and adjustment module with double chamber housing In the electronics compartment In the connection compartment (with Ex d version not possible) Note: If you intend to retrofit the instrument with an indicating and adjustment module for continuous measured value indication, a higher cover with an inspection glass is required.

  • Page 22: Adjustment System

    6 Set up with the indicating and adjustment module 6.2 Adjustment system Fig. 13: Indicating and adjustment elements LC display Adjustment keys Key functions [OK] key: Move to the menu overview Confirm selected menu Edit parameter Save value [->] key: Presentation change measured value Select list entry Select editing position...

  • Page 23: Parameter Adjustment

    6 Set up with the indicating and adjustment module 6.3 Parameter adjustment Through the parameter adjustment the instrument is adapted to the application conditions. The parameter adjustment is carried out via an adjustment menu. Main menu The main menu is divided into five sections with the following functions: Setup: Settings, e.g., for measurement loop name, medium, applica- tion, vessel, adjustment, signal output...
  • Page 24 6 Set up with the indicating and adjustment module Through this selection, the sensor is adapted perfectly to the product and measurement reliability, particularly in products with poor reflective properties, is considerably increased. Enter the requested parameters via the appropriate keys, save your settings with [OK] and jump to the next menu item with the [ESC] and the [->] key.
  • Page 25 6 Set up with the indicating and adjustment module Enter the suitable distance value in m for the empty vessel (e.g. distance from the sensor to the vessel bottom) corresponding to the percentage value. Save settings with [OK] and move with [ESC] and [->] to the max. adjustment.
  • Page 26 6 Set up with the indicating and adjustment module Diagnoses/Curve indica- The "Echo curve" shows the signal strength of the echoes over the tion measuring range in dB. The signal strength enables an evaluation of the quality of the measurement. The "False signal suppression"...
  • Page 27 6 Set up with the indicating and adjustment module Further settings/False The following circumstances cause interfering reflections and can signal suppression influence the measurement: High sockets Vessel installations such as struts Agitators Buildup or welded joints on vessel walls Note: A false signal suppression detects, marks and saves these false signals so that they are no longer taken into account for level measurement.
  • Page 28 6 Set up with the indicating and adjustment module Note: Check the distance to the product surface, because if an incorrect (too large) value is entered, the existing level will be saved as false signal. The filling level would then no longer be detectable in this area. If a false signal suppression is already created in the sensor, then the following menu window appears when selecting "False signal suppression":...
  • Page 29 6 Set up with the indicating and adjustment module Caution: Note the following if the instrument with corresponding approval is used as part of an overfill protection system according to WHG: If a linearisation curve is selected, the measuring signal is no longer compulsorily linear proportional to the level.

  • Page 30: Saving The Parameter Adjustment Data

    6 Set up with the indicating and adjustment module The following table shows the default values of VEGAPULS 62: Menu section Menu item Default value Setup Measurement Sensor loop name Min. adjustment Length of the standpipe Ex factory 0.0 s Damping Display Language...
  • Page 31 6 Set up with the indicating and adjustment module VEGAPULS 62 standpipe version • Foundation Fieldbus...

  • Page 32: Setup With Pactware

    7 Setup with PACTware 7 Setup with PACTware 7.1 Connect the PC Via the interface adapter directly on the sensor Fig. 14: Connection of the PC directly to the sensor via the interface adapter USB cable to the PC Interface adapter VEGACONNECT 4 Sensor Information: The interface adapter VEGACONNECT 3 or additional previous...

  • Page 33: Saving The Parameter Adjustment Data

    The standard version is available as a free-of-charge download under http://www.vega.com. The full version is available on CD from the agency serving you. 7.3 Saving the parameter adjustment data We recommend documenting or saving the parameter adjustment data via PACTware.

  • Page 34: Set Up With Other Systems

    DD adjustment programs such as, for example, AMS™ and PDM. A free-of-charge download of these files is available via Internet. Move via www.vega.com and "Downloads" to "Software". 8.2 Communicator 375, 475 Device descriptions for the instrument are available as DD or EDD for parameter adjustment with the Field Communicator 375 or 475.

  • Page 35: Diagnosis, Asset Management And Service

    9 Diagnosis, Asset Management and service 9 Diagnosis, Asset Management and service 9.1 Maintaining If the device is used correctly, no maintenance is required in normal operation. 9.2 Measured value and event memory The instrument has several memories which are available for diagnosis purposes.

  • Page 36: Asset Management Function

    9 Diagnosis, Asset Management and service Further echo curves: Up to 10 echo curves can be stored in a ring buffer in this memory section. Additional echo curves are stored via: PC with PACTware/DTM Control system with EDD 9.3 Asset Management function The instrument features self-monitoring and diagnosis according to NE 107 and VDI/VDE 2650.
  • Page 37 9 Diagnosis, Asset Management and service Maintenance: Due to external influences, the instrument function is limited. The measurement is affected, but the measured value is still valid. Plan in maintenance for the instrument because a failure is expected in the near future (e.g. due to buildup). This status message is inactive by default.
  • Page 38 9 Diagnosis, Asset Management and service Code Cause Rectification PA Dev- Spec Text mes- Diagnosis sage Bit 6 F105 l The instrument is still l Wait for the warm-up in the start phase, the phase Determine measured value measured l Duration depending could not yet be de- value on the version and...
  • Page 39 9 Diagnosis, Asset Management and service Code Cause Rectification Text mes- sage C700 l Simulation active l Finish simulation Simulation l Wait for the automatic end after 60 mins. Out of specification The following table shows the error codes and text messages in the status message "Out of specification"...

  • Page 40: Remove Interferences

    9 Diagnosis, Asset Management and service Code Cause Rectification Text mes- sage M503 l The echot/noise ratio is the l Check installation and pro- small for a reliable measu- cess conditions Reliability too rement l Clean the antenna l Change polarisation direc- tion l Use instrument with higher sensitivity...
  • Page 41 9 Diagnosis, Asset Management and service The images in column "Error pattern" show the actual level with a broken line and the level displayed by the sensor as a continuous line. time Fig. 17: The broken line 1 shows the real level, the continuous line 2 shows the level displayed by the sensor Instructions: Wherever the sensor displays a constant value, the reason could...
  • Page 42 24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is also available outside the normal working hours on seven days a week around the clock.

  • Page 43: Exchanging The Electronics Module

    You can find detailed information on our homepage www. vega.com. Load sensor software to Go under "www.vega.com/downloads" to "Software" Select under "plics sensors and instruments", "Firmware updates" your instrument series and software version Load the zip file via the right mouse key with "Save target as", for example, on the desktop of your PC Go with the right mouse key to the folder and select "Extract all"...

  • Page 44: How To Proceed In Case Of Repair

    Prepare update Connecting the sensor to voltage supply and via the interface adapter to the PC Start PACTware and go via the menu "Project" to the VEGA project assistant Select "USB", "Create new project" and "Set instrument online" Activate the project assistant with "Start"; the connection to the sensor is carried out automatically and the parameter window "Sensor # online parameter adjustment"...

  • Page 45: Dismounting

    10 Dismounting 10 Dismounting 10.1 Dismounting steps Warning: Before dismounting, be aware of dangerous process conditions such as e.g. pressure in the vessel, high temperatures, corrosive or toxic products etc. Take note of chapters "Mounting" and "Connecting to power supply" and carry out the listed steps in reverse order.

  • Page 46: Supplement

    11 Supplement 11 Supplement 11.1 Technical data General data 316L corresponds to 1.4404 or 1.4435 Materials, wetted parts 316L, Hastelloy C22 Process fitting Process seal On site (instruments with thread: Klingersil C-4400 is attached) Antenna impedance cone PTFE, PP, PEEK, ceramic (99.7 % Al FKM (SHS FPM 70C3 GLT), FFKM (Kalrez 6375), seal, antenna system FFKM (Kalrez 2035), FFKM (Kalrez 6230 - FDA)

  • Page 47: Primary_Value

    11 Supplement The measured quantity is the distance between process fitting of the sensor and product surface. The reference plane is the seal surface on the hexagon or the lower side of the flange. Fig. 24: Data of the input variable Reference plane Measured variable, max.
  • Page 48 11 Supplement 10 mA, ±0.5 mA Non-Ex and Ex ia instrument 16 mA, ±0.5 mA Ex d instruments > 1 mm (0.039 in) Resolution, digital Accuracy (according to DIN EN 60770-1) Process reference conditions according to DIN EN 61298-1 Temperature +18 …...
  • Page 49 11 Supplement Gas phase Temperature Pressure 1 bar/ 10 bar/ 50 bar/ 100 bar/ 200 bar/ 14.5 psig 145 psig 725 psig 1450 psig 2900 psig 20 °C/68 °F 0.00 % 0.22 % 1.2 % 2.4 % 4.9 % 200 °C/392 °F -0.01 % 0.13 % 0.74 % 1.5 %...
  • Page 50 11 Supplement Process conditions For the process conditions, please also note the specifications on the type label. The lower value always applies. Seal Antenna impedance co- Process temperature (measured on the process fitting) FKM (SHS FPM 70C3 PFFE -40 … +200 °C (-40 … +392 °F) GLT) FFKM (Kalrez 6375) PFFE...
  • Page 51 11 Supplement 1 x closing cap ½ NPT, 1 x blind stopper ½ NPT, 1 x blind stopper M16 x 1.5 or 1 x plug M12 x 1 for external optionally indicating and adjustment unit 1 x plug (depending on the version), 1 x blind stopper M20 x 1.5;...
  • Page 52 11 Supplement 4 keys Adjustment elements Protection rating IP 20 unassembled IP 40 mounted into the sensor without cover Materials Housing Inspection window Polyester foil Integrated clock Date format Day.Month.Year 12 h/24 h Time format Time zone Ex factory Measurement electronics temerature 1 °C (1.8 °F) Resolution Accuracy...
  • Page 53 Instruments with approvals can have different technical data depending on the version. That's why the associated approval documents have to be noted with these instruments. They are part of the delivery or can be downloaded under www.vega.com via "VEGA Tools" and "serial number search" as well as via "Downloads" and "Approvals".

  • Page 54: Supplementary Information Foundation Fieldbus

    11 Supplement 11.2 Supplementary information Foundation Fieldbus The following table gives you an overview of the instrument versions and the corresponding device descriptions, the electrical characteristics of the bus system as well as the applied function blocks. Revisions Data DD-Revision Rev_01 010101.cff...
  • Page 55 11 Supplement Performance Function Blocks Instantiable General Information LAS (Link Active Scheduler) Master Capable Number of VCRs (Virtual Communication Relationships) Function blocks Transducer Block (TB) The Transducer Block "Analog Input (AI)" takes the original measured value (Secondary Value 2), carries out the min./max. adjustment (Secondary Value 1), carries out a linearization (Primary Value) and makes the values on its output available for further function blocks.
  • Page 56 11 Supplement The function block "Analog Input (AI)" takes the original measured value selected by a Channel Number and makes it available to additional function blocks on its output. Fig. 27: Schematic presentation function block Analog Input (AI) Function block Discret Input (DI) The function block "Discret Input (DI)"...
  • Page 57 11 Supplement The function block "PID Control " is a key component for various tasks in the process automation and is used universally. PID blocks can be cascaded if this is necessary or requested due to different time constants with the primary and secondary process measurement. Fig.
  • Page 58 11 Supplement The function block "Output Splitter" generates two control outputs out of one input. Each output is a linear image of a part of the input. A retrograde calculation function is realised by using the linear imaging function inversely. A cascading of several Output Splitters is supported by an integrated decision table for the combinability of inputs and outputs.
  • Page 59 11 Supplement The function block "Signal Characterizer" has two channels the outputs of which are not in linear relation with the respective input. The non-linear relation is defined by a look-up table with individually selectable x/y-pairs. The respective input signal is imaged on the corresponding output, hence this function block can be used in a control loop or signal path.
  • Page 60 11 Supplement The function block "Integrator" integrates a continuous input signal over the time and sums the results of an impulse input block. It is used as a totalizer up to a reset or as a subtotalizer up to a reference point at which the integrated and accumulated value is compared with the default values.
  • Page 61 11 Supplement The function block "Input Selector" offers selection possibilities for up to four inputs and generates an output signal according to the selection criteria. Typical input signals are AI blocks. Selection possibilities are maximum, minimum, mean value, average value and first useful signal. Through parameter combination, the block can be used as rotary switch or as preselection switch for the first useful value.

  • Page 62: Secondary Value 1 Type

    11 Supplement Fourth order Polynomial Based on PV Fig. 34: Schematic presentation function block Arithmetic Parameter list The following table gives you an overview of the parameters used. FF desciptor Description Unit PRIMARY_VALUE PRIMARY_VALUE (Linearized value). This is the process value after min/max adjustment and Linearization with the status of PRIMAR- the transducer block.
  • Page 63 11 Supplement FF desciptor Description Unit Secondary value 2 type SECONDARY_VALUE_2_- TYPE FILL_HEIGHT_VALUE_Type Filling height value type DIAGNOSIS AITB Diagnosis DIAG_MASK_1 DIAG_OUT_1 DIAG_MASK_2 DIAG_OUT_2 DEVICE_IDENTIFICATION Manufacturer ID, device type, bus type ID, measurement principle, serial number, DTM ID, device revision DEVICE_NAME Device name IS-SPARE_ELECTRONICS...
  • Page 64 11 Supplement FF desciptor Description Unit FALSE_SIGNAL_CMD_STA- Busy, last command, errorcode Amplitude safety of the 0 % curve, safety of the false signal FALSE_SIGNAL_CMD_CON- suppression, position of the 0 % and 100 % curve in near and FIGURATION1 far range FALSE_SIGNAL_CMD_CON- Gradient of the manual sectors, safety at the end of false echo FIGURATION2...
  • Page 65 11 Supplement FF desciptor Description Unit USER_MIN_MAX_PHYSI- Min.-/max.- distance values, date CAL_VALUE RESET_PEAK_PHYSICAL_- VALUE RESET_LINEARIZATION_- CURVE DEVICE_STATUS_ASCII Device status ECHO_CURVE_PLICSCOM_- Parameters as curve selection and resolution REQUEST ECHO_CURVE_PLICSCOM_- Parameters as start and end LIMITS APPROVAL_WHG Sensor acc. to WHG DEVICE_STATE_CONFIG Function check, maintenance required, out of specification ELECTRONIC_TEMPERATU- Electronics temperature...

  • Page 66: Dimensions

    11 Supplement 11.3 Dimensions The following dimensional drawings represent only an extract of the possible versions. Detailed dimensional drawings can be downloaded on www.vega.com under "Downloads" and "Drawings". Plastic housing ~ 69 mm ~ 84 mm (3.31") (2.72") ø 79 mm ø...
  • Page 67 11 Supplement Aluminium housing in protection rating IP 66/IP 68, 1 bar ~ 105 mm (4.13") ~ 150 mm (5.91") ø 84 mm ø 84 mm (3.31") (3.31") M16x1,5 M20x1,5 M20x1,5 M20x1,5/ ½ NPT Fig. 37: Housing versions in protection IP 66/IP 68 (1 bar) - with integrated indicating and adjustment module the housing is 9 mm/0.35 in higher Single chamber version Double chamber version...
  • Page 68 11 Supplement Stainless steel housing in protection rating IP 66/IP 68, 1 bar ~ 93 mm ~ 103 mm ~ 105 mm (4.13") (3.66") (4.06") ø 84 mm ø 80 mm ø 77 mm (3.31") (3.15") (3.03") M16x1,5 M20x1,5 M20x1,5/ ½...
  • Page 69 11 Supplement - Standpipe version with thread VEGAPULS 62 ø 39,5 mm ø 39,5 mm (1.56") (1.56") SW 32 mm SW 46 mm (1.26") (1.81") G1½A G¾A 1½ NPT ¾ NPT ø 21,3 mm ø 21,3 mm (0.84") (0.84") Fig. 40: VEGAPULS 62 - Standpipe version with thread The plant operator must provide a suitable support for the standpipe de- pending on the length and the process conditions.
  • Page 70 11 Supplement - Standpipe version with flange VEGAPULS 62 ø 39,5 mm (1.56") ø 21,3 mm (0.84") Fig. 41: VEGAPULS 62 - Standpipe version with flange The plant operator must provide a suitable support for the standpipe de- pending on the length and the process conditions. VEGAPULS 62 standpipe version •...
  • Page 71 Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellectuelle. Pour plus d'informations, on pourra se référer au site http://www.vega.com VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad industrial. Para mayor información revise la pagina web http://www.vega.com Линии...
  • Page 72 Index INDEX Key function 22 Accessory - External indicating and adjustment unit 11 - External radio unit 11 - Flanges 11 Linearisation curve 28 - Indicating and adjustment module 10 - Interface adapter 11 - Protective cap 11 Main menu 23 Adjustment 24 Meas.
  • Page 73 Index VEGAPULS 62 standpipe version • Foundation Fieldbus...
  • Page 74 Index VEGAPULS 62 standpipe version • Foundation Fieldbus...
  • Page 75 Index VEGAPULS 62 standpipe version • Foundation Fieldbus...
  • Page 76 All statements concerning scope of delivery, application, practical use and operating conditions of the sensors and processing systems correspond to the information avail- able at the time of printing. © VEGA Grieshaber KG, Schiltach/Germany 2012 36510-EN-120301 Subject to change without prior notice...
