IFD-NET EVO EMS USER MANUAL
rev. 121022EN
.IFD-NET.
WWW
COM
EMS USER GUIDE AND INSTALLATION MANUAL
EVOLUTION, THE BEST EVER!
M.A.V.
V
L
2, 25025 M
(BS) I
://
.
-
.
AVIONIC DIVISION
IA
OMBARDIA
ANERBIO
TALY
HTTP
WWW
IFD
NET
COM
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVO and is the answer not in the manual?

Questions and answers

Related Manuals for IFD-NET EVO

Summary of Contents for IFD-NET EVO

  • Page 1 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. EMS USER GUIDE AND INSTALLATION MANUAL EVOLUTION, THE BEST EVER! M.A.V. 2, 25025 M (BS) I AVIONIC DIVISION OMBARDIA ANERBIO TALY HTTP...
  • Page 2 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. Revision Description 06/01/2022 Initial release 12/10/2022 Updated and corrected sections REVISIONS HISTORY M.A.V. 2, 25025 M (BS) I AVIONIC DIVISION OMBARDIA ANERBIO TALY HTTP...

  • Page 3: Table Of Contents

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. Summary INTRODUCTION 1.1. ELECTRICAL AND MECHANICAL SPECIFICATION SYSTEM DECRIPTION 2.1. IFD-NET EVO EMS OVERVIEW UNIT DESCRIPTION OPERATION 4.1. PAGE EMS 4.1.1. SCREEN SECTION 1: T CREEN 4.1.2. SCREEN SECTION 2: R IGHT CREEN 4.1.3.
  • Page 4 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. ELECTRICAL CONNECTIONS 7.1. POWERING AND EXPANSION BUS 7.2. EMS POWER CONNECTOR 7.3. EMS MASTER SLAVES CONNECTION 7.3.1. WIRING SPECIFICATION WIRING EXAMPLE SYSTEM CONFIGURATION EXAMPLE SENSORS LIST MECHANICAL DIMENSIONS DIAGRAM ORDERING INFORMATION M.A.V.
  • Page 5 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. CERTIFICATE OF WARRANTY LIMITED WARRANTY Seller warrants that the product hereby purchased is, upon delivery, free from defects in material and workmanship and that any such product which is found to be defective in such workmanship or material will be repaired or replaced by Seller (M.A.V.
  • Page 6 The information displayed by the family IFD-NET EVO is not certified for use for VFR or IFR flights. The family IFD-NET EVO is meant as an aid to VFR navigation and is not a substitute for certified EFIS or traditional gauges.

  • Page 7: Introduction

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 1. INTRODUCTION  Standard diameter installation shape 80mm (3’’ 1/8).  Adjustable brightness screen ever, sunlight visible, up to 1200 cd/m².  Special release under request to reach up to 2000 cd/m².

  • Page 8: System Decription

    Big Knob Little Knob The IFD-NET EVO is part of a large range of instruments. In the follow sections will be described how to use the new aeronautical interface based on a high force double rotary knob with push switch.

  • Page 9: Unit Description

    FULL DUAL ENGINE In order to realize a network, IFD-NET EVO EMS can be classified in:  Master: It consists in a single unit witch capture and visualize various engine data and generate a RS485 pack data that will be used from slaves connected to the bus.

  • Page 10: Operation

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. OPERATION 4.1. PAGE EMS EMS screen is divided in 4 main areas: The following sensors are displayed: ① MAP and RPM indicators. ② CHT, EGT and TIT indicators. System display only configured sensors, adjusting histogram bases ③...

  • Page 11: Screen Section 1: Top Screen

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 4.1.1. SCREEN SECTION 1: Top Screen In order to setup configuration, in this area will appears one or two arc setting indicators. Sensor priority is: 1. MAP 1 2. RMP 1 3. MAP 2 4.

  • Page 12: Screen Section 2: Right Screen

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 4.1.2. SCREEN SECTION 2: Right Screen In order to setup configuration, in this area will appears up to four horizontal linear indicators. Sensors priority are:  [MAP 2] if not in top screen ...

  • Page 13: Screen Section 3: Left Screen

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 4.1.3. SCREEN SECTION 3: Left Screen Three types of sensors are shown in this section:  Up to 6 CHT sensors  Up to 6 EGT sensors  1 Turbine Inlet Temperature Graphic dimensions depends to how many sensors are configured.

  • Page 14: Screen Section 3: Bottom Screen

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 4.1.4. SCREEN SECTION 3: Bottom Screen In order to setup configuration, in this area will appears up to four vertical linear indicators. Sensors priority are: 1. Battery Voltage (always available and shown) 2.

  • Page 15: Setup Menu

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 4.2. SETUP MENU The pilot can access the main menu by keeping pressed the knob for about 2 seconds until the screen. In every SETUP page there are 2 types of items: 1.

  • Page 16: Main Setup

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 4.2.1. MAIN SETUP  EXIT: Close setup.  ADDRESS: Bus Address.  LIGHT: Screen brightness regulation.  ENGINE: Presets of the selected engine.  THERMOCOUPLE: Thermocouples setup. See “4.2.2 THERMOCOUPLES ”. ...

  • Page 17: Thermocouples Setup

    .IFD-NET. 4.2.2. THERMOCOUPLES SETUP IFD-NET EVO EMS is able to read up to 12 thermocouples (TC) fully configurable. Through the THERMOCOUPLE setup it is possible to link the physical input (rear connector EMS1) of the thermocouple to its logical function.
  • Page 18 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. M.A.V. 2, 25025 M (BS) I AVIONIC DIVISION OMBARDIA ANERBIO TALY HTTP...

  • Page 19: Sensor Setup

    .IFD-NET. 4.2.3. SENSOR SETUP EVO EMS is able to read up to 12 sensors configurable according to the model. Like Thermocouples, through the SENSORS setup it is possible to link the physical input of the sensor to its logical function.

  • Page 20: Rpm/Flow Setup

    .IFD-NET. 4.2.4. RPM/FLOW SETUP EVO EMS can read up to 3 impulsive inputs fully configurable. Each sensor can be connected to each input REVn (See 5.3 EXPANSION CONNECTORS). Through the RPM / FLOW setup it is possible to link the physical input of the sensor to its logical function.

  • Page 21: Map/Vbat Setup

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 4.2.5. MAP/VBAT SETUP These setup allow the settings of coloured arcs for MAP and Power Supply instruments (See 4.2.8 ARCS SETUP 4.2.6. CURVES SETUP The sensor characterization curves are composed of 24 distinct points.

  • Page 22: Fuel Level Calib Setup

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 4.2.7. FUEL LEVEL CALIB SETUP This page appears only in case of FUEL LEVEL sensor. The user must empty the tank then fill it in ten steps; in each step the amount to be added is equal to 1/10 of the maximum capacity (defined in the arcs setup) 4.2.8.

  • Page 23: Connections

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 5. CONNECTIONS 5.1. REAR CONNECTORS VIEW AND DESCRIPTION IFD-NET EVO (80mm) ① The power connector is explained in the section “7.1 ② POWERING AND EXPANSION BUS”. Pneumatic inlets, MAP1 and MAP2* pressures, are provided by two brass 1/8 NPT female plugs.

  • Page 24: Power Connector

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 5.2. POWER CONNECTOR INSTRUMENT CONNECTOR PINOUT: ⑤ ①  Pin 1: Input 10-28 Vdc  Pin 2: Not used  Pin 3: Not used  Pin 4: RS485 A+ signal for FLY BUS®...

  • Page 25: Sensors And Thermocouples Wiring

    SENSORS AND THERMOCOUPLES WIRING 5.4.1. THERMOCOUPLES IFD-NET EVO EMS can read various type of thermocouples. Isolated thermocouples are better, but also not isolated thermocouples can be used; not isolated thermocouples can be affected by ground-common-mode noise while isolated thermocouples haven’t this problem and provide a better signal.

  • Page 26: Voltage Sensors Note

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 5.4.3. VOLTAGE SENSORS NOTE In case of voltage sensors, the maximum sensor output must be 5V. if the maximum sensor output exceeds 5 volts, a divider must be connected to the input pins, as shown below...

  • Page 27: Installation Guide

    80mm holes already prepared. To lock the IFD-NET EVO EMS (80mm) unit on your cockpit use the three black screws provided in the purchase box, otherwise select different screws with same dimension of 4MA x 10mm MAX.

  • Page 28: Disassembly/Assembly The Knobs

    IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 6.1. DISASSEMBLY/ASSEMBLY THE KNOBS To disassembly/assembly the knobs it need:  flat screwdriver (blade 4 x 0.8mm)  socket hex screwdriver (6mm) 6.1.1. DISASSEMBLY STEPS 1. Using a thin blade or fingernail, remove frontal cap ①...

  • Page 29: Selecting An Appropriate Installation Position

    6.2. SELECTING AN APPROPRIATE INSTALLATION POSITION IFD-NET EVO EMS is a multi-sensor system based on a variety of sophisticated transducers. Every sensor has a sensitive element which measure a different physical quantity  Avoid installing the equipment near hot surfaces. A good idea could be to ventilate the rear of the cockpit in order to protect instruments from overheating during exposure of the aircraft to direct sunlight.
  • Page 30 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 7. ELECTRICAL CONNECTIONS 7.1. POWERING AND EXPANSION BUS The electrical connection of the EMS models is very simple. As all of the sensors are inside the metal aluminum housing, the only electrical connection it...
  • Page 31 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 7.3. EMS MASTER SLAVES CONNECTION 7.3.1. WIRING SPECIFICATION The MASTER-SLAVE connection has to be made by shielded cable with at least 4 conductors with a section equal to or greater than 0.5mm (20AWG) and less than 1 meter in length.
  • Page 32 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 8. WIRING EXAMPLE - 4 EGT (thermocouples) - 4 CHT (thermocouples) - 1 OilT (R sensor) - 1 OilP (I sensor 4 -20 mA, need external resistor 240ohm 1/4w) - 1 F Lev (R sensor)
  • Page 33 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 9. SYSTEM CONFIGURATION EXAMPLE Sensors list to read: - 4 EGT (thermocouples) - 4 CHT (R sensor) - 1 OilT (R sensor) - 1 OilP (I sensor 4 -20 mA) - 1 F Lev (R sensor)
  • Page 34 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. SENSORS LIST NAME IFD-EMS CODE PARAMETER TYPE MAX VAL OPERATIONAL NOTES DYNON 100434-000 DY100434-000 GRT MAP 01/02 GRTMAP 01/02 ROTAX 912 100411-002 R912100411-002 OIL PRESS 240Ω GRT HPS-01 GRT HPS-01 OIL PRESS 240Ω...
  • Page 35 IFD-NET EVO EMS USER MANUAL rev. 121022EN .IFD-NET. 11. MECHANICAL DIMENSIONS DIAGRAM M.A.V. 2, 25025 M (BS) I AVIONIC DIVISION OMBARDIA ANERBIO TALY HTTP...
  • Page 36 12. ORDERING INFORMATION IFD-NET EVO is part of a large range of products. Because of their differing internal electronic configuration, is not possible to switch between the different models after final testing. Please select the model keeping in account your exact needs or talk to our technical department for guidance to meet your aircraft configuration.
