Page 1
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. USER GUIDE AND INSTALLATION MANUAL EVOLUTION, THE BEST EVER! M.A.V. 2, 25025 M (BS) I AVIONIC DIVISION OMBARDIA ANERBIO TALY HTTP...
Page 2
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. Revision Description 06/01/2022 Initial release REVISIONS HISTORY M.A.V. 2, 25025 M (BS) I AVIONIC DIVISION OMBARDIA ANERBIO TALY HTTP...
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. Summary INTRODUCTION 1.1. E LECTRICAL AND MECHANICAL PECIFICATION SYSTEM DECRIPTION 2.1. NET EVO EMS OVERVIEW UNIT DESCRIPTION OPERATION 4.1. P PFD EMS 4.1.1. S 1 : T CREEN ECTION CREEN 4.1.2. S...
Page 4
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. CERTIFICATE OF WARRANTY LIMITED WARRANTY Seller warrants that the product hereby purchased is, upon delivery, free from defects in material and workmanship and that any such product which is found to be defective in such workmanship or material will be repaired or replaced by Seller (M.A.V.
Page 5
The information displayed by the family IFD-NET EVO is not certified for use for VFR or IFR flights. The family IFD-NET EVO is meant as an aid to VFR navigation and is not a substitute for certified EFIS or traditional gauges.
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 1. I NTRODUCTION 80mm (3’’ 1/8) standard diameter installation shape Adjustable brightest screen ever, sunlight visible, up to 1200 cd/m². Special Release under request to reach up to 2000 cd/m².
EVO Bezel overview The IFD-NET EVO EMS PFD is part of a large range of instruments. In the follow sections will be described how to use the new aeronautical interface based on a high force double rotary knob with push switch.
BASE FULL DUAL ENGINE In order to realize a network, IFD-NET EVO EMS can be classified in: Stand Alone: it consists in a single unit witch capture and visualize various engine data Master: the unit reads data from sensors and generate RS485 pack data thet will be used from slaves connected to the bus.
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. OPERATION 4.1. PFD EMS The Primary Flight Display (PFD) contains EMS data in order to setup configuration. Screen is divided in 4 main areas: The following sensors are displayed on the “Errore. L'origine riferimento non è stata trovata.”: ①...
Page 10
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.1.1. Screen Section 1 : Top Screen In order to setup configuration, in this area will appears one or two arc setting indicators. Sensor priority is: 1. MAP 1 2. RMP 1 3.
Page 11
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.1.2. Screen Section 2 : Right Screen In order to setup configuration, in this area will appears up to four horizontal linear indicators. Sensor priority is: 1. [MAP 2] if not in area 1 2.
Page 12
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.1.3. Screen Section 3 : Left Screen Three types of sensors are shown in this section: 1. Up to 6 CHT sensors 2. Up to 6 EGT sensors 3. 1 Turbine Inlet Temperature Graphic dimensions depends to how many sensors are configured.
Page 13
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.1.4. Screen Section 3 : Bottom Screen In order to setup configuration, in this area will appears up to four horizontal linear indicators. Sensor priority is: 1. Battery Voltage (always available and shown) 2.
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.2. SETUP MENU The pilot can access the main menu by keeping pressed the knob for about 2 seconds until the screen. In every SETUP page there are 2 types of items: 1.
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.2.1. Main Menu EXIT: Close menu. ADDRESS: Net Address. See “NETWORK CONFIGURATION” paragraph LIGHT: Screen brightness regulation ENGINE: Self configuration in order to selected engine. THERMOCOUPLE: Setup thermocouples. See “MENU THERMOCOUPLES”.
Page 16
4.2.2. Menu Thermocouples IFD-NET EVO EMS is able to read up to 12 thermocouples fully configurable.. Each thermocouple you want to manage can be connected to each input -Thermomocouple- (See Errore. L'origine riferimento non è stata trovata.). Through the TERMOCOUPLE menu it is possible to link the physical input of the thermocouple to its logical function.
Page 17
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.2.3. Menu Sensors IFD-microNET_EMS is able to read up to 6 sensors configurable according to the model. Each sensor that you want to manage can be connected to each input -sensor- (See Errore. L'origine riferimento non è stata trovata.). Through the SENSORES menu it is possible to link the physical input of the sensor to its logical function.
Page 18
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.2.4. Menu RPM/FLOW IFD-microNET_EMS can read up to 3 impulsive inputs fully configurable. Each sensor can be connected to each input - REVn- (See EXPANSION CONNECTOR). Through the RPM / FLOW menu it is possible to link the physical input of the sensor to its logical function.
Page 19
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.2.5. Menu MAP / Menu VBAT These menu allow the settings of coloured arcs for MAP and Power Supply instruments. See Errore. L'origine riferimento non è stata trovata. 4.2.6. Menu Curves The sensor characterization curves are composed of 24 distinct points.
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 4.2.7. Menu Calib This page appears only in case of FUEL LEVEL sensor. The user must empty the tank then fill it in ten steps; in each step the amount to be added is equal to 1/10 of the maximum capacity (defined in the ARCS menu) 4.2.8.
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 5. CONNECTIONS 5.1. REAR CONNECTORS VIEW AND DESCRIPTION IFD-NET EVO EFIS (80mm) ① The power connector is the only electrical connection ② needed. The details about this connector are explained in the section “7.1...
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 5.2. POWER CONNECTOR Pin 1: Input 12/24 Vdc Pin 2: Not Used Pin 3: Not Used Pin 4: RS485 A+ signal for FLY BUS® Pin 5: GND ...
Page 24
IFD-NET EVO EMS can read varios type of thermocouples. Isolated thermocouples are better, but also not isolated thermocouples can be used; not-isolated thermocouples can be affected by ground-common-mode noise: IFD-NET EVO EMS has a differential input who limits this effects, but Isolated thermocouples haven’t this problem and provide a better signal.
Page 25
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 5.5.2. Current Sensor note In case of current sensors, connect an electrical resistance in parallel to the sensor, the value of which must be set in the setting table of the corresponding sensor.
80mm holes already prepared. To lock the IFD-NET EVO EMS (80mm) unit on your cockpit use the three black screws provided in the purchase box, otherwise select different screws with same dimension of 4MA x 10mm MAX.
.IFD-NET. 6.1. SELECTING AN APPROPRIATE INSTALLATION POSITION IFD-NET EVO EMS is a multi-sensor system based on a variety of sophisticated transducers. Every sensor has a sensitive element which measure a different physical quantity Avoid installing the equipment near hot surfaces. A good idea could be to ventilate the rear of the cockpit in order to protect instruments from overheating during exposure of the aircraft to direct sunlight.
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 7. ELECTRICAL CONNECTIONS 7.1. POWERING AND EXPANSION BUS IFD-NET EVO wiring The electrical connection of the EMS models is very simple. As all of the sensors are inside the metal aluminum housing, the only electrical connection it...
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 8. CONFIGURATION SYSTEM EXAMPLE 8.1. ENSORS Sensors to read : 4 EGT (thermocouples) 4 CHT (thermocouples) 1 OilT (R sensor) 1 OilP (I sensor 4 -20 mA) 1 F Lev (V sensor 0-3V)
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. 8.2. DEFAULT SENSORS NAME IFD-EMS CODE PARAMETER TYPE MAX VAL OPERATIONAL NOTES DYNON 100434-000 DY100434-000 Use 1K-1K5 divider resistor GRT MAP 01/02 GRTMAP 01/02 Use 1K-1K5 divider resistor ROTAX 912 100411-002...
10. ORDERING INFORMATION IFD-NET EVO EFIS PFD is part of a large range of products. Because of their differing internal electronic configuration, is not possible to switch between the different models after final testing. Please select the model keeping in account your exact needs or talk to our technical department for guidance to meet your aircraft configuration.
Page 33
IFD-NET EVO EFIS product USER MANUAL rev. 190422EN .IFD-NET. representatives to learn more on how to obtain the perfect unimodality of the instruments described in the present manual. M.A.V. 2, 25025 M (BS) I AVIONIC DIVISION OMBARDIA ANERBIO TALY HTTP...
