Linksys SRW224P Specifications

Secure, reliable, intelligent,
SNMP-managed PoE switching for
growing businesses
The Linksys WebView Managed Switch allows you to expand your network securely.
Configuration of the switch is secured using SSL for web access. User control is
secured using 802.1X security using a RADIUS authentication mechanism and can also
be controlled using MAC-based filtering.
Extensive QoS features make the solution ideal for real-time applications like voice and
video. The 4 priority queues together with the Weighted Round Robin and Strict Priority
scheduling techniques facilitate efficient coexistence of real-time traffic with data traffic
allowing them each to meet their QoS needs. Individual users or applications can be
prioritized above others using various Class of Service options - by port, layer 2 priority
(802.1p), or Layer 3 priority (ToS or DSCP). Intelligent broadcast and multicast storm control
minimizes and contains the effect of these types of traffic on regular traffic. IGMP snooping
limits bandwidth-intensive video traffic to only the requestors without flooding all users.
Incoming traffic can be policed allowing you to control network access and traffic flow.
There are features that allow you to expand and grow your network of switches. Link
aggregation allows multiple high-bandwidth trunks between switches to be setup. This also
provides a level of reliability in that the system continues to operate if one of the links break.
Spanning Tree (STP), Fast Spanning Tree, and Multiple Spanning Tree allow you to build a mesh
of switches increasing the availability of the system.
The rich management functionality of the WebView Switches includes SNMP, RMON, and HTTP
Management options, allowing you to flexibly integrate and manage these devices in your
network.
Automatic Load Sensing - Power control circuitry automatically detects Power over Ethernet on
access devices before providing power. Power feeding of Ethernet is provided on the
10BASE-T/100BASE-TX ports with maximum output power per port of up to 15.4W simultaneously
on 12 ports. Alternatively, the switch can power all ports at a maximum of 7.5W per port.
Independent overload and short-circuit protection for each port is provided. LED indicators for
power status are provided per port.
Delivers reliable power Secure management via
over 10/100 Ethernet ports SSL and secure user control
using IEEE 802.3af standard via 802.1X & MAC-based
filtering
24-Port 10/100 + 2-Port
Gigabit Switch with
WebView
SRW224P
Model:
IGMP snooping, L2/L3 CoS Intelligent traffic
queuing & scheduling management with rate
makes solution ideal for limiting, policing ACLs, and
voice/video storm control
SRW224P
PRODUCT DATA
BUSINESS SERIES
