Arca-Swiss Core60leveler Manual

We recommend
ARCA-SWISS QuickLink
Finally a professional solution that eliminates the
tedious fixing of the tripod head.
ARCA-SWISS presents the new tripod mounting
QuickLink. The combination of a mounting plate for
the tripod and an insert plate which is attached to the
tripod head makes attaching and detaching the tripod
head child's play. The installed plates can thus be left
permanently on the tripod or on the tripod head.
By means of a solid bayonet, the tripod head with its
insert plate is placed into the mounting plate and
securely fixed by a knurled rotating ring.
ARCA-SWISS X-table System
The X-Table System offers incredible precision when
working in macro photography! In addition to fine
focusing in the longitudinal plane, the X-Table
System also allows you to adjust the fine operation in
the transverse plane thanks to the crossover.
X-Table
The movement of the camera is effected inside the
circular arc, thus a change of the object distance as well
as the image
Core60leveler : ±10°
Core75leveler : ±15°
macro-Table
selection hardly develops.
