Instruction Guide
ICID Double Wall Adjustable Starter Section
INITIAL INSTALLATION
1. Remove loose strip of insulation and keep to one side.
2. Insert male spigot of liner into the appliance spigot.
3. Seal using the rope gasket, fire cement or similar.
4. Insulate liner using strip of insulation with joint to rear.
Width of insulation strip can be trimmed to suit.
5. Slide adjustable case down over the insulation to cover the
appliance spigot.
Please see reverse side of this guide for instructions to allow
removal of stove for servicing and re-installation of stove.
Schiedel Chimney Systems Ltd.
Crowther Estate
Washington
Tyne & Wear NE38 0AQ
Tel. 0191 4161150
Follow SchiedelUK
Schiedel.co.uk
Visit our website:
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Schiedel ICID
Summary of Contents for Schiedel ICID
- Page 1 Instruction Guide ICID Double Wall Adjustable Starter Section INITIAL INSTALLATION 1. Remove loose strip of insulation and keep to one side. 2. Insert male spigot of liner into the appliance spigot. 3. Seal using the rope gasket, fire cement or similar.
- Page 2 Instruction Guide ICID Double Wall Adjustable Starter Section INSTRUCTION TO ALLOW REMOVAL OF STOVE FOR SERVICING RE-INSTALLATION OF STOVE 1. Position stove spigot 1. Slide adjustable case up immediately beneath liner inside the outer wall of the spigot of chimney.
