Step 17
1/4-20x1/2" truss head screws (x3)
Secure the left side shelf with three 1/4" flat washers (C) and three 1/4-20x1/2" truss head screws (A).
Step 18
5/32-32x2/5" truss head screws (x2)
1. Make sure that the shelf assembly is fully seated in the keyhole slot, then retighten the screw you loosened in step 16.
2. Secure the left shelf cover with two 5/32-32x2/5" truss head screws (B).
PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 17 PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_Assembly Man_V1_EN_BK1.indb 17
1/4" flat washers (x3)
EN
17
