- Page 1 All manuals and user guides at all-guides.com Operation and Maintenance Manual MNL90138 03/01/05 MODEL 138 MODEL 138...
- Page 2 All manuals and user guides at all-guides.com...
-
Page 3: Installation
Your model 138 machine will have a long trouble-free life. Read this manual. Keep it with Specifications your machine; it's your key to proper operation and lasting service. -
Page 4: Controller Operation
All manuals and user guides at all-guides.com FOR USE BY QUALIFIED SERVICE PERSONNEL ONLY Operation Operation Timer/Temperature Control 1. It is recommended that you review the "How to Apply Instructions" (in our Product Information Sheet) before beginning heat sealing operations. 2. -
Page 5: Additional Notes
All manuals and user guides at all-guides.com FOR USE BY QUALIFIED SERVICE PERSONNEL ONLY ADDITIONAL NOTES: Temperature NOTE Fahrenheit/Centigrade (Celsius) Conversion The temperature controller can be programmed to display either °F or °C. To change: Press the MODE button until the temperature is displayed, then push and hold the SET button for 10 seconds. -
Page 6: Protective Earth Terminal
All manuals and user guides at all-guides.com FOR USE BY QUALIFIED SERVICE PERSONNEL ONLY International Symbols Preventive Maintenance Suggestions The IGS heat seal machines are relatively maintenance free. For long, trouble-free life, the Power Off following preventive maintenance should be followed: 1. - Page 7 All manuals and user guides at all-guides.com FOR USE BY QUALIFIED SERVICE PERSONNEL ONLY 4. The pad and metal must be thoroughly dry Replacement of Silicone Rubber Pads and clean, before starting the bonding operation. 1. Make sure heat platen is cool. 5.
- Page 8 12 Vac TEMPERATURE 12 Vac (BLUE-EUROPE) INPUT GN/YEL CONTROL GREEN TIMER SENSOR START (GN/YEL-EUROPE) BLUE 470 F TEMP LIMITER MICRO GN/YEL SW\ITCH GREEN BROWN BROWN HEAT PLATEN 12 Vac GN/YEL 230 Vac BLUE 138 Wiring Rev D - 03/01/05 TRANSFORMER...
- Page 9 All manuals and user guides at all-guides.com...
- Page 10 All manuals and user guides at all-guides.com MODEL MODEL NO PART NAME 120V AC 230V AC SHROUD, UPPER PLATEN MPS90000 MPS90000 SCREW, PAN HD #10x1.0 LG PHIL SH METAL MPSS143 MPSS143 INSULATION, FIBERGLASS 15X20 MPSP254 MPSP254 STRAIN, RELIEF CABLE MPS90014 MPS90014 INSULATORS, SPACER (4/SET) MPSI089...
- Page 11 All manuals and user guides at all-guides.com MODEL MODEL NO PART NAME 120V AC 230V AC 56B POWER CORD (GREAT BRITAIN) MPPW203 58 SCREW, PAN HD 8-32UNC x 1.00 LG MHSP8321 MHSP8321 59 WASHER, FLAT #8 (.164 I.D.) MHWSAE8 MHWSAE8 60 WASHER, #8 INTERNAL LOCK MHWLIT8 MHWLIT8...
- Page 12 All manuals and user guides at all-guides.com ® 13925 E. 166th Street • Cerritos CA USA 90702-7900 Service: (800) 426-3609 • (562) 861-2566 • Sales: (800) 421-6971 (562) 404-3000 • Fax: (562) 404-3010 • http://www.instagraph.com...
