- Page 1 H M I C A P A C I T I V E mikromedia 7 HMI CAPACITIVE U S E R M A N U A L...
- Page 2 Thank you for choosing MIKROE! We present you the ultimate multimedia solution for embedded development. Elegant on the surface, yet extremely powerful on the inside, we have designed it to inspire outstanding achievements. And now, it’s all yours. Enjoy premium.
-
Page 3: Table Of Contents
Ta b l e o f c o n t e n t s Introduction 5. Audio Speaker 1.Key microcontroller features 6. Haptic Feedback Motor 1.1 MCU programming/debugging 1.2 MCU reset What’s next 2. Capacitive display 3. Data Storage 4. Connectivity 4.1 USB - UART 4.2 mikroBUS shuttle connectors... -
Page 5: Introduction
mikromedia 7 HMI Capacitive board is designed as a complete The usability of mikromedia 7 HMI does not end with its ability to solution for the rapid development of multimedia and GUI-centric accelerate the prototyping and application development stages: it applications. -
Page 6: Key Microcontroller Features
1. Key microcontroller features At its core, mikromedia 7 HMI CAPACITIVE uses the MKV58F1M0VLL24 MCU. MKV58F1M0VLL24 is the 32-bit ARM® Cortex®-M7 core. This MCU produced by NXP is a high-performance solution offering exceptional precision, sensing, and control targeting Motor Control, Industrial Drives and Automation applications. Among many peripherals available on the host MCU, key features include: ∫... -
Page 8: Mcu Programming/Debugging
1.1 Microcontroller programming/debugging The host MCU can be programmed and debugged over the JTAG/SWD compatible 2x5 pin header (1), labeled as PROG/DEBUG. This header allows an external programmer (e.g. CODEGRIP or mikroProg) to be used. 1.2 MCU reset The board is equipped with the Reset button (2), which is located on the front side of the board. -
Page 10: Capacitive Display
2. Capacitive display A high-quality 7” TFT true-color display with a capacitive touch The capacitive multi-touch panel, based on the FT5426 CTP panel is the most distinctive feature of the mikromedia 7 HMI. controller, allows the development of interactive applications, The display has a resolution of 800 by 480 pixels, and it can offering a touch-driven control interface. - Page 11 Display and back view...
-
Page 12: Data Storage
3. Data storage The mikromedia 7 HMI development board is equipped with two types of storage memory: with a microSD card slot and a MicroSD card slot view Flash memory module. 3.1 microSD card slot 3.2 External flash storage The microSD card slot allows storing large amounts of data externally, mikromedia 7 HMI features EN25Q80B Serial Flash Memory which uses... -
Page 13: Connectivity
4. Connectivity mikromedia 7 HMI offers a USB-UART connectivity option. Besides that, it also offers two standardized mikroBUS™ Shuttle connectors. It is a considerable upgrade for the system, as it allows interfacing with the huge base of Click boards™. 4.1 USB-UART UART (Universal Asynchronous Receiver/Transmitter) interface is one of the Figure 12: USB view most common interfaces for data exchange between the MCU and other... -
Page 14: Mikrobus ™ Shuttle Connectors
4.2 mikroBUS shuttle connectors ™ mikromedia 7 HMI CAPACITIVE development board uses the mikroBUS ™ Shuttle connector, a brand new addition to the mikroBUS standard in the ™ form of a 2x8 pin IDC header with 1.27mm (50mil) pitch. Unlike mikroBUS ™... - Page 15 For more information about mikroBUS Shuttle extension board and ™ Shuttle click, please visit web pages: www.mikroe.com/mikrobus-shuttle www.mikroe.com/shuttle-click For additional information about the mikroBUS , please visit the official ™ web page at www.mikroe.com/mikrobus mikromedia 7 connected to mikroBUS Shuttle view...
-
Page 16: Audio Speaker
5. Audio Speaker To round-up its multimedia concept, mikromedia HMI 7 features an audio speaker paired with a Class-AB audio amplifier. The TPA6203A1 is a 1.25-W mono fully differential amplifier designed to drive a speaker with at least 8Ω impedance. Features like 85-dB PSRR from 90 Hz to 5 kHz and improved RF-rectification immunity, make the TPA6203A1 ideal for multimedia applications. -
Page 17: Haptic Feedback Motor
6. Haptic feedback motor Haptic feedback motor features a compact size Eccentric Rotating Mass (ERM) motor (1). This type of motor is often used for haptic feedback on many small handheld devices, such as the cellphones, pagers, RFID scanners and similar devices. This motor contains a small eccentric weight on its rotor, so while rotating it also produces vibration effect. - Page 18 RAPID DEVELOPMENT OF MULTIMEDIA AND GUI-CENTRIC HMI APPLICATIONS...
-
Page 20: What's Next
4 SUPPORT 2 PROJECTS Mikroe offers free Tech Support to the end of its life span, so if anything goes Once you have chosen your compiler, and since you already got the board, you wrong, we are ready and willing to help. We know how important it is to be able are ready to start writing your first projects. - Page 21 D I S C L A I M E R All the products owned by MikroElektronika are protected by copyright law and international copyright treaty. Therefore, this manual is to be treated as any other copyright material. No part of this manual, including product and software described herein, must be reproduced, stored in a retrieval system, translated or transmitted in any form or by any means, without the prior written permission of MikroElektronika.
