- Page 1 Ruwac USA Industrial Vacuums Powerhouse DB Series Installation, Operation, Maintenance & Service Model No. Serial No. Filter No. Start-Up Date • DIRECT BAGGING Version:V2.0 1/28/20 54 Winter St. • Holyoke, MA 01040 • (413) 532-4030 • info@ruwac.com...
-
Page 2: Table Of Contents
Table of Contents Contents Page Warranty Safety III. Start-Up Inspection and Maintenance Standard Instructions (All Vacuums) Trouble Shooting VI. Terms and Conditions. Questions? Call Ruwac at (413) 532-4030 or e-mail us at info@ruwac.com! -
Page 3: Warranty
RUWAC service personnel are covered by a 120-day parts only warranty. RUWAC, Inc. will not assume any responsibility under the terms of this limited warranty on equipment, which has not been paid in full. This warranty does not apply to any equipment that has been disassembled, repaired, or otherwise altered by any person without the written authorization of RUWAC’S service department, nor does it apply to any product that has... - Page 4 Note: If continuity is not found across any of these points, consult the parts manual to check that all ground wires are in place. For further assistance, contact Ruwac. Questions? Call Ruwac at (413) 532-4030 or e-mail us at info@ruwac.com!
-
Page 5: Start-Up
III. Start-Up DS2 SERIES STANDARD INSTRUCTIONS: AV SERIES START-UP OPERATION NOTE: AV2000 Vacuums run at 100 PSI and 100 CFM, to be used with a 1” NPT unrestricted air line. If included, affix the Attach a full port air To turn on the... -
Page 6: Inspection And Maintenance
1. Note: Using an object to dislodge material may tear the filter. Consult your RUWAC representative if material blockage is excessive. Do not use high pressure compressed air or water to clean off filter, as material may become permanently lodged into filter membrane. - Page 7 Inspection & Maintenance DS2 SERIES INSTRUCTIONS: HEPA MAINTENANCE CAUTION: Motor deck will be heavy and will require a crane to remove. To ensure optimal Release the clamps Locate and loosen the Remove and replace performance, replace and remove the bracket hardware.
- Page 8 Loosen turbine Remove and replace Tension the belt. silicone from around hardware (3 per belts as necessary. (See pg. 10) the turbines. turbine), then slide inward to slacken the belt. Questions? Call Ruwac at (413) 532-4030 or e-mail us at info@ruwac.com!
- Page 9 Inspection & Maintenance DS2 SERIES INSTRUCTIONS: BELT TENSIONING NOTE: Complete the previous operations to prepare the motor deck for service of the motor, turbine or belt. Replace any defective components and secure the motor with bolts before proceding. Measure belt tension by...
- Page 10 Remove the hardware Remove any excess Install turbine and belt. silicone seal around to release the turbine. silicone from the Adjust the belt the turbines. motor deck. (See pg. 10) Questions? Call Ruwac at (413) 532-4030 or e-mail us at info@ruwac.com!
-
Page 11: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Insufficient Vacuum - Motor in wrong direction - Check motor direction and ensure it is Pressure moving clockwise. - Dustpan improperly seated - Remove dustpan, inspect seal, replace dustpan. - Filter clogged or improperly - Follow filter inspection procedure (Section IV.) seated - Clogged hose... -
Page 12: Terms And Conditions
Buyer shall set aside and hold rejected goods without further processing until RUWAC has an opportunity to inspect and advise of the disposition, if any, to be made of such goods. In no event shall any rejected goods be returned reworked, or scrapped by Buyer without the express written authorization of RUWAC. - Page 13 LIMITED WARRANTY: RUWAC warrants that new equipment which are complete units and are sold and/or manufactured by RUWAC, Inc. will be free from defects in material and workmanship for a period of 18 months from date of shipment or 12 months from date of start-up, whichever comes first. RUWAC warrants that replacement parts sold hereunder will be free from defects in material and workmanship for a period of 120-days after the date of shipment.
- Page 14 RUWAC. RUWAC’S failure to strictly enforce any right on one occasion does not constitute a waiver of that or any on any other occasion.
