Well ELPM-03-WL User Manual

Thank you for choosing WELL. Please read carefully the following instructions and keep them within reach.
WARNING!
Do not plug two or more meters together!
IMPORTANT
Don't plug in an appliance where the load exceeds 16 Amp. Always ensure the plug of any appliance is fully inserted into the
meter outlet. If cleaning of the meter is required, remove from mains power and wipe meter with a dry cloth.
KEYBOARD DEFINITION
1. MODE: Exchange display state.
2. SET: Set price with buttons UP.
3. UP: Set price combined with buttons SET.
GENERAL FEATURES
1. Display line power.
2. Display and memory accumulative total
3. Display and memory total power charge of price.
THE DATA DISPLAY
Press MODE button the data displays as follows:
W →KWh →PRICE →COST/KWH
↑_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ↓
1. Plug in socket and power on, the meter will display real power.
2. Press MODE button once again and release, the meter will display
3. Press MODE button once again and release, the meter will display total power charge.
4. Press MODE button once again and release, the meter will display COST/KWH.
COST/KWH
SETTING PRICE OF
1. Press SET button during display COST/KWH,the first
2. Press SET button once again and release, the second
3. Press SET button once again and release, the
4. Press SET button once again and release, the fourth
5. Press SET button once again and release, the
CLEAR DATA
Press and hold MODE button for 5 seconds will clear
SPECIFICATIONS
Power supply
Max. load
Min. power display
Measure power accuracy
Power quantity accuracy
Min. power quantity display
Accumulative power quantity range
Price range
Standby power consumption
Operating temperature
USER'S MANUAL
MULTIFUNCTION POWER METER
Code: ELPM-03-WL
power quantity.
digital COST/KWH flash, press UP
digital COST/KWH flash, press UP
third COST/KWH flash, press UP
COST/KWH flash, press UP
radix point COST/KWH flash, press UP
KWH, PRICE and
230V~50Hz
16A, 3680W
0.1W
+/-1% or +/-1W(0-100W);+/-1%(100-3600W)
+/-1%
0.01KWH
0.00-9999.99KWH
0.00-9999
<0.5W
o o
5 C to +40
accumulative KWh.
button to set it.
button to set it.
button to set it.
button to set it.
button to set it.
COST/KWH data.
C
