- Page 1 Wireless Interlinked Combination Smoke and Carbon Monoxide Alarm 10-Year Sealed Battery Operated Model: SC06-W/SC07-W User Manual...
-
Page 2: Package Contents
NEVER IGNORE THE SOUND OF THE ALARM! Determining what type of alarm has sounded is easy with your X-Sense combination smoke and carbon monoxide alarm. The buzzer will inform you of the type of situation occurring. - Page 3 ≥ 85 dB at 10 ft (3 m) @ 3.2 ± 0.3 kHz pulsing alarm Alarm Loudness ≤ 9 minutes Silence Duration 915 MHz Operating Frequency 24 wireless units (only compatible with X-Sense Maximum Number of wireless alarms) Interconnected Units Over 820 ft (250 m) in open air Transmission Range NOTES: 1.
-
Page 4: Product Overview
Product Overview CAUTION! THIS COMBINATION SMOKE AND CARBON MONOXIDE ALARM IS DESIGNED FOR INDOOR USE ONLY. DO NOT EXPOSE TO RAIN OR MOISTURE. DO NOT KNOCK OR DROP THE ALARM. DO NOT OPEN OR TAMPER WITH THE ALARM AS THIS COULD CAUSE MALFUNCTION. LED Indicator (Red/Green/Yellow) Buzzer Test/Silence Button... - Page 5 you hear a short beep, indicating that the alarm has entered the test mode.Please refer to the ―Alarm Test‖ section for further information. The alarm goes back to the standby mode after testing. SC07-W: The Test/Silence button is used to test the unit's electronics and to silence the unit during an alarm.
- Page 6 Low Battery The LED indicator will flash yellow together with one beep every 60 seconds. THE UNIT MUST BE DEACTIVATED (see"Deactivation of the Alarm"section) AND REPLACED AS SOON AS POSSIBLE. If you press the test button when there is low battery, the low battery signal will temporarily cease for 10 hours.
- Page 7 Slight headache, nausea, fatigue (flu-like symptoms). Dizziness and headache within 2–3 hours. Nausea, frontal headache, drowsiness, confusion and rapid heart rate. Risk to life after over 3 hours of exposure. Severe headaches, convulsions, vital organ failures. Death possible within 2–3 hours. WARNING: THIS DEVICE IS DESIGNED TO PROTECT INDIVIDUALS FROM ACUTE EFFECTS OF CARBON MONOXIDE EXPOSURE.
- Page 8 alarm. time period. The LED seconds. alarm status. Open indicator flashes red4 times nearby windows and every 5.8 seconds. doors, and immediately move to fresh air. All other The LEDflashesred and 3 long beeps every Dangerous smoke interconnect green 3 times sequentially 4 seconds.
- Page 9 The LEDflashes red and Other interconnected green sequentially. alarms in the network. Flashesred3 times every 4 None. Smoke silence mode: Silence Mode seconds. After 9 minutes, the unit will exit silence mode. Flashes red 4 times every 5.8 None. CO silence mode: After seconds.
- Page 10 Unit detects Flashesred3 times every 3 long beeps Dangerous smoke smoke and 4 seconds. every 4 concentration is seconds. initiates an detected. Open nearby alarm. windows and doors, and immediately move to fresh air. Unit detects A CO concentration 4 quick beeps Dangerous CO CO and ranging from 30 to 999...
- Page 11 alarm. threshold, the alarm signal will stop. Then, the alarm goes back to the standby mode. Unit detected The LED indicator None. Alarm cancellation: CO and flashes green once every when the CO initiated an second for 5 seconds. concentration level alarm.
- Page 12 A maximum of 24 X-Sense safety devices may be interconnected in a multiple station arrangement. The interconnect system should not exceed the NFPA interconnect limit of 12 smoke alarms and/or 18 alarms total (smoke, CO, smoke/ CO combination, heat, etc.).
- Page 13 Choose one multi-pack as your base network and connect the other multi- packs to it. NOTE! The following instructions regarding wireless interconnection are applicable to the X-Sense Link wirelessinterlinked alarms only. How to Interconnect 1. Make sure you only work with 2 units at a time, and make sure that they are both turned on to ensure successful connection.
-
Page 14: Alarm Mode
2. Test all wireless alarms to ensure they are interconnected before installation. 3. A maximum of 24 wireless alarms can be interconnected on the same network. 4. The model can only be interconnected with other X-Sense Link wireless interlinked alarms. -
Page 15: Alarm Test
In addition to the weekly tests you should perform, it is recommended to test the alarm after returning from a long trip or vacation. If your X-Sense Link SC06-W/SC07-W is interconnected to other X-Sensewireless alarms, we recommend that every individual alarm is tested during the weekly test. -
Page 16: Basic Safety Information
first wake up your alarm by pressing the continuously with the LED flashing red test button. The LCD will turn on and the and green successively. Release the backlight will be lit. test/silence button and all the units will After testing, alarm will... -
Page 17: Installation Instructions
SENSOR. THE SMOKE ALARM IS NOT DESIGNED TO DETECT GAS, HEAT OR FLAMES. WARNING! NEVER IGNORE ANY ALARM. FAILURE TO RESPOND CAN RESULT IN SERIOUS INJURY OR DEATH. THE SILENCE FEATURE IS ONLY FOR YOUR CONVENIENCE AND WILL NOT CORRECT A PROBLEM. ALWAYS CHECK YOUR HOME FOR A POTENTIAL PROBLEM AFTER ANY ALARM. - Page 18 NOTE: Before installation, it is recommended to test the interconnectedalarms in the rooms where you intend to install them to ensure that they are within transmission range and that nothing will interfere with their communication. Installation Locations Prioritize the installation of a smoke/CO alarm in the bedroom and walkways, and make sure you can hear the alarm from all sleeping areas.
-
Page 19: Recommended Placement
Locations to Avoid: 1. Near large metal surfaces and/or bundles of wire. 2. Near fluorescent lights, amateur radios, electrical equipment, or other devices that may transmit an RF signal, as electronic noise may cause nuisance alarms. Recommended Placement WARNING! THIS ALARM SHOULD BE INSTALLED BY A COMPETENT PERSON. INSTALLATION OF THE ALARM SHOULD NOT BE USED AS A SUBSTITUTE FOR PROPER INSTALLATION, USE AND MAINTENANCE OF FUEL BURNING APPLIANCES INCLUDING APPROPRIATE... -
Page 20: How To Install This Alarm
How to Install This Alarm IMPORTANT! THIS ALARM IS DESIGNED TO BE MOUNTED ON THE CEILING OR WALL. WARNING! FAILURE TO PROPERLY INSTALL AND ACTIVATE THIS ALARM WILL PREVENT PROPER OPERATION OF THE ALARM AND WILL PREVENT ITS RESPONSE TO FIRE HAZARDS. Mounting Steps Mark three screw holes on the wall or ceiling according to the holes of the mounting bracket, and drill the screw holes to a depth of 1.18 in (30 mm) using a Ø... - Page 21 Test the unit by using the Test/Silence button. Ensure the unit sounds in an alarm pattern. NOTE: This model is equipped with a feature that automatically activates the alarm when the alarm is attached to the mounting bracket for the first time. Deactivation of the Alarm WARNING! DO NOT DEACTIVATE THE ALARM UNIT UNTIL THE END-OF-LIFE...
-
Page 22: Maintenance
2. Twist the plastic pin upwards to the ―DIS‖position or insert a screwdriver into the slot and turn the dial clockwise to the ―DIS‖position. 3. Dispose of the alarm. 4. Replace the alarm. Maintenance To keep your smoke/CO alarm in good working order, follow these simple steps: 1. -
Page 23: Fcc Statement
The alarm does not soundduring a •Check whether the alarm is properly attached to test. themounting bracket. •Make sure you have pushed the Test/Silence button firmly. •Check the installation positioning. The wireless signalmight be blocked or out of range. Check the location of your alarm (see ―Installation False alarms are triggered intermittently Locations‖). -
Page 24: Environmental Protection
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. Manufacturer and Service Information X-Sense Innovations Co., Ltd. Address: B4-503, Kexing Science Park, 15 Keyuan Road, Shenzhen, 518057, CHINA Email: support@x-sense.com...
