BALZER FIELD FLOATER Assembly Instructions Manual

High capacity grain carts
Hide thumbs Also See for FIELD FLOATER:

Advertisement

Quick Links

Download this manual
Assembly Instructions
July 2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the FIELD FLOATER and is the answer not in the manual?

Questions and answers

Related Manuals for BALZER FIELD FLOATER

Summary of Contents for BALZER FIELD FLOATER

  • Page 1 Assembly Instructions July 2012...

  • Page 2: Table Of Contents

    Index Table of Contents Unpacking......................Page 4 Inventory......................Page 5 Assembly......................Page 9 Lubrication.......................Page 66 Testing......................Page 70...
  • Page 3 Accuracy Balzer Inc is dedicated to providing the most reliable and durable AG related products. Balzer Inc has made every attempt to provide the most accurate and readily understandable information on our equipment. Due to our continuing efforts to produce the best products available, upgrades and improvements to our equipment may precede the manual updates.

  • Page 4: Unpacking

    Unpacking Field Floater IV Grain Cart Contents of container may have shifted during transit. Use caution WARNING while unpacking grain cart components. Once individual components have been removed from shipping container, the next step is to fold down the grain cart side panels. This will provide access to parts that have been stored in grain cart box.

  • Page 5: Inventory

    Inventory The individual components of the Field Floater IV grain cart that need to be installed have been broken down and are labeled with part numbers. Hydraulic hoses are marked on one end or tagged. Individual shipping configurations will vary due to options ordered with the Field Floater IV grain cart.
  • Page 6 Inventory BAG LABEL QTY DESCRIPTION PART # BOX A Continued LIGHTS 3/8X3 1/2 1216 3/8 WIZNUT 2082 1/4X1 1/4 1165 1/4 WIZNUT 2080 AUGER HOUSING TO HOPPER 5/8X2 1291 5/8 TOP LK 2546 AUGER TO UPPER AUGER HOUSING 5/8X1 1/2 1289 5/8 TOP LK 2546...
  • Page 7 Inventory BAG LABEL DESCRIPTION PART # BOX A Continued HOPPER RH 3/8X1 STB 1586 3/8X1 EXTRA 1206 HOPPER LH 3/8X1 STB 1586 15 3/8X1 1/4 EXTRA 1207 HOPPER FRONT 3/8X1 1206 3/8X1 1/4 1207 3/8 WIZNUT 2082 HOPPER REAR 3/8X1 1206 10 3/8X1 1/2 EXTRA 1208...
  • Page 8 Inventory BAG LABEL DESCRIPTION PART # BOX 1550 & 1325 1500 & 1300 3/4X2 1/4 1312 3/4X3 1315 3/4 FL WASHER 1603 3/4 TOP LK 2593 3/8 STB 1586 3/8X1 3/4 1209 3/8X1 1206 3/8 FLAT 1598 3/8 WIZNUT 2082 2000 .
  • Page 9 Assembly Front and Rear End Panels It is recommended to have either planking or plywood sheets to line box of grain NOTE cart. It is much easier to move around inside of cart with stable footing. Required Hardware Required Tools / Equipment (56) 3/8”...
  • Page 10 Assembly Front and Rear Panels Continued Required Hardware Required Tools / Equipment (64) 3/8” X 1 1/4” Bolt P# 1207 Crane Lifting Tackle Ratchet Strap (64)3/8” Locknut P# 2496 Center Punch Wrenches (8) 3/8” Flat Washer P# 1598 Once all nuts and bolts have been inserted, repeat steps for rear panel. See Figure 2. Insert bolt into lower part of panels.
  • Page 11 Assembly Side Panels Required Hardware Required Tools / Equipment (96) 3/8” X 1” Self Tap Bolt P# 85892 Center Punch Wrenches Using a center punch, start inserting self tapping bolts P# 85892 into holes in lower portion of side panels. Start towards the middle or wherever the holes are close. See Figure 1. P# 85892 Figure 1...
  • Page 12 Assembly Corner Brackets Required Hardware Required Tools / Equipment (32) 5/8” X 5” Bolt P# 1301 Hoist Ratchet Strap Wrenches (32) 5/8” Locknut P# 2546 Adjustable C-Clamp Center Punch The corner brackets need to make side and end panels fit tightly together. Position outside cornel bracket on one corner of cart.
  • Page 13 Assembly Upper Vertical Auger Cradle Required Hardware Required Tools / Equipment (4) 5/8” X 1 ½” Bolt P# 1289 Wrenches (4) 5/8” Toplock Nut P# 2546 Align upper auger cradle P# 85970, insert bolts P# 1289 and secure on inside of hopper with lock nut P#_2546.
  • Page 14 Assembly Ladder Required Hardware Required Tools / Equipment (2) ½” X 1 1/4” Bolt P# 1249 Wrenches (2) ½” Washer P# 1600 (2) ½” Flange Nut P# 2084 (2) 5/8” X 2 ½” Bolt P# 1293 (2) 5/8” Washer P# 1620 (2) 5/8”...
  • Page 15 Assembly Tongue Required Hardware Required Tools / Equipment (4) 1” X 3” Bolt P# 2534 Hoist Center Punch (4) 1” Lock Nut P# 1779 Wrenches Attach crane to grain cart. Raise cart and block in the air. Position Tongue assembly in front of grain cart.
  • Page 16 Assembly Suspension Towers Required Hardware Required Tools / Equipment (4) .75” X 5” Bolt P# 2624 Hoist Center Punch (4) .75” Lock Nut P# 2593 Wrenches Position suspension towers and secure with bolts P#2624 and lock-nuts P# 2593. See Figure 1. Repeat for remaining towers.
  • Page 17 Assembly Tandem Independent Suspension Required Hardware Required Tools / Equipment (2) 1.25” X 6” Bolt P# 2569 Hoist Center Punch (2) 1.25” Lock Nut P# 1780 Wrenches (2) 1” X 5” Bolt P# 1347 (2) 1” Lock Nut P# 1779 Position Drag Link and secure to tongue with bolt P# 1347 and lock-nut P# 1779.
  • Page 18 Assembly Tandem Independent Suspension Continued Required Hardware Required Tools / Equipment (2) 1” X 5” Bolt P# 1349 Hoist Center Punch (2) 1” Lock Nut P# 1779 Wrenches Position Fixed Axle and secure to suspension cylinders P# 900335 with bolts P# 1349, lock-nuts P# 1779, and spacers P#91294.
  • Page 19 Assembly Tandem Independent Suspension Continued Required Hardware Required Tools / Equipment (8) 1” X 5” Bolt P# 1347 Hoist Center Punch (4) 1” Lock Nut P# 1779 Wrenches Attach Upper Drag Link P# 900052 and Lower Drag Link P# 900098 with bolts P# 1347 and lock-nuts P#_1779.
  • Page 20 Assembly Suspension Hubs and Spindles Without Brakes Required Hardware Required Tools / Equipment (1) 1 1/4” X 8 1/2” Bolt P# 33870 Wrenches (1) 1 1/4” Locknut P# 1780 Slide hub and spindle assembly into spindle receiver and secure with bolt P# 33870 and lock-nut P#_1780.
  • Page 21 Assembly Tridem Independent Suspension Required Hardware Required Tools / Equipment (8) 1” X 5” Bolt P# 1347 Hoist Center Punch (2) 1” X 6” Bolt P# 1349 Wrenches (6) 1” Lock Nut P# 1779 Position Front Steering Axle and secure to suspension cylinders P# 900335 with bolts P# 1349 and lock- nuts P# 1779.
  • Page 22 Assembly Suspension Wheels Required Hardware Required Tools / Equipment (10)3/8” Lug nut P# 91849 Crane Lifting Tackle (PER TIRE) Center Punch Wrenches Secure tire to hub with lug nuts P# 91849. Figure 1...
  • Page 23 Assembly Jack Required Hardware Required Tools / Equipment Align jack P# 83338 with mounting bracket on tongue assembly. Insert Pins P# 90646. See Figure 1. Crank jack till bracing can be removed. Figure 1...
  • Page 24 Assembly Lower Vertical Auger Required Hardware Required Tools / Equipment (16) 5/8” X 2” Bolt P# 1291 Crane Lifting Tackle (16) 5/8” Locknut P# 2546 Center Punch Wrenches With adequate blocking under front end of grain cart, place wheel chocks on wheels to keep grain cart from moving.
  • Page 25 Assembly Lower Vertical Auger Continued Required Hardware Required Tools / Equipment (12) 5/8” X 2” Bolt P# 1291 Crane Lifting Tackle (2) 5/8” Locknut P# 2546 Center Punch Wrenches (4) 5/8” X 1 1/2” Bolt P# 1289 (2) 5/8” Washer P# 1620 Attach crane to lower vertical auger tube.
  • Page 26 Assembly Lower Vertical Auger Continued Required Hardware Required Tools / Equipment (4) 3/4” X 3” Bolt P# 1315 Crane Lifting Tackle (4) 3/4” Locknut P# 2593 Center Punch Wrenches (8) 3/4” Washer P# 1603 Insert bolts P# 1315, washers P# 1603 on bolts and before lock nuts P# 2593. Tighten after securing bolts and lock nuts around flange.
  • Page 27 Assembly Lower Vertical Auger Continued Required Hardware Required Tools / Equipment (1) 5/8” X 7 1/2” Bolt P# 52097 Crane Lifting Tackle (1) 5/8” Locknut P# 2546 (2) 5/8” Washer P# 1620 Attach crane to auger. See Figure 1. Raise auger and then insert into auger tube. See Figure 1. Figure 1...
  • Page 28 Assembly Lower Vertical Auger Continued Required Hardware Required Tools / Equipment (4) 5/8” X 3” Bolt P# 1295 Wrenches (4) 5/8” Locknut P# 2546 Remove Side Chain Shield P# 202204. See Figure 1. Slide rubber seal P#835500 and lower vertical auger bearing P# 84492 onto auger shaft and secure with bolt P# 1295 and locknut P# 2546.
  • Page 29 Assembly Lower Vertical Auger Continued Sawtooth Coupler Alignment Required Hardware Required Tools / Equipment (1) .125” X 2.18” X 2.87” Washer P# 92413 Crane Lifting Tackle (1) .375” X 2.18” X 2.87” Washer P# 92414 Wrenches Straight Edge (1) .25” X 2.18” X 2.87” Washer P# 92415 Measuring Tape The alignment of the sawtooth coupler is important to ensure the life of the vertical auger.
  • Page 30 Assembly Lower Vertical Auger Continued Required Hardware Required Tools / Equipment (4) 1/2” X 1 3/4” Bolt P# 1251 Wrenches Pry Bar (4) 1/2” Locknut P# 2539 Center Punch (4) 1/2” Washer P# 1600 Align holes with pry bar and center punch. See Figure 1. Insert bolts P# 1251 with washers P# 1600 through hanger bearing and secure with washers P# 1694 and lock nuts P#2539.
  • Page 31 Assembly Lower Vertical Auger Chain Required Hardware Required Tools / Equipment Key ½” X ½” X 2” P# 2437 Allen Wrenches Never Seize Clean auger shaft and key P# 2437. See Figure 1. Clean taperlock bushing P# 80512. Assemble Sprocket P# 80506, Taperlock Bushing P#_80512 using Allen screws provided in box with bushing.
  • Page 32 Assembly Lower Vertical Auger Chain Continued Required Hardware Required Tools / Equipment Key ½” X ½” X 2 1/2” P# 2439 Allen Wrenches Never Seize Straight Edge Slide Sprocket P# 80506 and bushing onto shaft until it hits bearing. Tighten Allen screws enough to allow for movement.
  • Page 33 Assembly Lower Vertical Auger Chain Continued Required Hardware Required Tools / Equipment Double Chain Link P# 90926 Needle Nose Pliers Pipe Wrench Insert chain P# 80510A on top of gearbox pulley. Wrap a rag around PTO splines and use pipe wrench to rotate gearbox sprocket.
  • Page 34 Assembly Lower Vertical Auger Chain Continued Required Hardware Required Tools / Equipment Double Chain Link P# 90926 Needle Nose Pliers Pipe Wrench Disassemble double chain connector link P# 90926. Bring both chain ends together at small sprocket. Insert double chain connector link to connect the two ends of the chain. Insert two center pieces of double chain connector link and then outer piece.
  • Page 35 Assembly Lower Vertical Auger Chain Continued Required Hardware Required Tools / Equipment Needle Nose Pliers Pipe Wrench Align auger sprocket and gearbox sprocket to fixed position of idler sprocket. Fully tighten Allen screws for auger sprocket and gearbox sprocket. Check alignment by rotating PTO spline. Adjust tension on idler sprocket and tighten fully.

  • Page 36: Assembly

    Assembly Clutch Assembly Required Hardware Required Tools / Equipment (5) 1/2” X 5” Bolt P# 1262 Wrenches (5) 1/2” Loc Nut P# 2539 (3) 1/4” x 2” Bolt P#1168 (3) 1/4” Loc Washer P#1368 Position Rotor P# 84461 and secure with bolts P# 1262 and loc nuts P# 2539. Attach washer P#84476 and caliper mount P# 84458.
  • Page 37 Assembly Automatic Oiler Brushes Required Hardware Required Tools / Equipment (2) 1/2” Nut P# 1704 Wrenches Position oiler brushes P# 72796 and secure with nuts P# 1704 to shields P# 202203 and 202204. See Figures 1 and 2. P# 1704 P# 202204 P# 72796 Figure 1...
  • Page 38 Assembly Auger Shields Required Hardware Required Tools / Equipment (2) 5/8” X 1 1/4” Bolt P# 1287 (3) 3/8” X 1 1/4” Bolt P# 1207 Wrenches (2) 5/8” Lock Washer P# 1640 (5) 3/8” Whiznut P# 2082 (2) 3/8” Washer P# 1598 (2) 5/16”...
  • Page 39 Assembly Grain Door Indicator / Access Covers Required Hardware Required Tools / Equipment (2) 1/4” X 1” Bolt P# 1164 Wrenches (2) 1/4” Toplock Nut P# 2564 (8) 1/2” X 1” Bolt P# 1249 (8) 1/2” Whiz Nut P# 2084 Position grain door indicator P# 85354 and secure with bolts P# 1164 and toplock nuts P# 2564.
  • Page 40 Assembly Standard Upper Vertical Auger Required Hardware Required Tools / Equipment (6) 3/8” X 3/4” Bolt P#1204 Wrenches Pliers (6) 3/8” Lock Nut P#2496 Remove hardware holding auger upper flap. See Figure 1. Raise upper flap out of the way. Align lower auger targetable downspout P# 71865 to hinge and attach with bolts P# 1204 and lock nuts P# 2496.
  • Page 41 Assembly Standard Upper Vertical Auger Continued Required Hardware Required Tools / Equipment (1) Hinge Pin 29 3/4” P# 91323 Hammer Crane (1) Vertical Pivot Pin 9” P# 91333 Lifting Tackle Pin Punch (2) Washer P# 81768 (2) Roll Pin P# 81767 Attach crane to upper auger P# 71750 and align with lower auger pivot.
  • Page 42 Assembly Standard Upper Vertical Auger Continued Required Hardware Required Tools / Equipment (4) 1/2” X 1 1/2” Bolt P# 1250 Wrenches (4) 1/2” Locknut P# 2539 Install (2) hydraulic fittings P# 842000 into hydraulics motor P# 12554. See Figure 1. Install hydraulic motor and mount to upper auger using bolts P# 1250 and lock nuts P# 2539.
  • Page 43 Assembly Automatic Chain Oiler Required Hardware Required Tools / Equipment (6) 5/16” X 3/4” Bolt P# 1183 Wrenches (4) 5/16” Washer P# 1597 Position oiler tank P# 72772 and secure with bolts P# 1183, washers P# 1597 and whiz nut P# 2081. Slide connecting hose P# 72773 onto tank and secure with hose clamp P# 72813.
  • Page 44 Assembly Automatic Chain Oiler Continued Required Hardware Required Tools / Equipment Wrenches Route plastic tubing P# 72779 to brush positions. Push hose ends into brushes P# 72796 and manifold P#72774. Connect hydraulic fitting P# 72817 to manifold P# 72774. Connect hydraulic hose P# 72819 to hydraulic fitting P# 72817 on oiler manifold, route hose to hydraulic control block port labeled OILER.
  • Page 45 Assembly Running Light Wiring Harness Required Hardware Required Tools / Equipment (7) 5/16” X 1” Bolt P# 1185 Wrenches Wire Cutters (7) 5/16” Washer P# 1597 Route running light wiring harness P# 72854 and secure with bolts P# 1185, washers P# 1597 and clamps P#_15742.
  • Page 46 Assembly Running Light Wiring Harness Continued Required Hardware Required Tools / Equipment (2) 3/8" x 3 1/2" Bolt P# 1216 Wrenches (4) 3/8” Locknut P# 2496 (4) 3/8” Washer P# 1598 (4) 1/4” x 1” Bolt P# 1164 (4) 1/4” Flange Nut P# 2080 (4) 1/4”...
  • Page 47 Assembly Running Light Wiring Harness Continued Required Hardware Required Tools / Equipment Wrenches Connect wires from running lights to wire harness P# 72854. See Figure 4. P# 72854 Figure 4...
  • Page 48 Assembly Wiring Harness Required Hardware Required Tools / Equipment Tie Wraps Wire Cutters Connect 7 pin wiring harness P# 72851 to Main wiring harness P#72852. See Figure 1. Connect harness P# 72853 to main wiring harness P# 72852. See Figure 2. Wiring harness components are not drawn to scale.
  • Page 49 Assembly Wiring Harness Continued Required Hardware Required Tools / Equipment Tie Wraps Wire Cutters Route work light connections from wiring harness P#72852 under and around horizontal auger and up to work light locations. Connect work light installed on upper auger. Leave wire for light mounted on extensions until they are installed.
  • Page 50 Assembly Wiring Harness Continued Required Hardware Required Tools / Equipment Tie Wraps Wire Cutters Route work light connections from wiring harness P#72852 under and around horizontal auger and up to work light locations. Connect work light installed on upper auger. Leave wire for light mounted on extensions until they are installed.
  • Page 51 Assembly Wiring Harness Continued Required Hardware Required Tools / Equipment Tie Wraps Wire Cutters Match labels on individual wires to location in Figure 6. Figure 6...
  • Page 52 Assembly Hydraulics Required Hardware Required Tools / Equipment Tie Wraps Wire Cutters Wrenches Connect grain door hydraulic lines P# 855168 to hydraulic manifold. See Figure 1. Refer to grain cart hydraulic schematic in Figure 2 for further detail. Figure 1...
  • Page 53 Assembly Hydraulics Continued Figure 2...
  • Page 54 Assembly Auger Grease Bank Required Hardware Required Tools / Equipment (2) 1/4” X 3/4” Bolt P# 1162 Wrenches Wire Cutter Remove bolts P# 1162 and remove cover P# 41704. Install grease tab P# 72335 using bolts P# 1162 and locknuts P# 2564. See Figure 119. Replace cover P# 41704 and replace bolts P# 1162 . Install decal P# 72354.
  • Page 55 Assembly 1325 Bushel Extensions Required Hardware Required Tools / Equipment (6) 3/4” X 2 1/4” Bolt P# 1312 Wrenches Lifting Tackle (12) 3/4” Flat Washer P# 1603 Crane (6) 3/4” Lock Nut P# 2593 Position Front End Panel P# 85738 and secure by installing bushings P# 85765 and securing with bolts P# 1312, washers P#1603 and lock nuts P# 2593.
  • Page 56 Assembly 1325 Bushel Extensions continued Required Hardware Required Tools / Equipment Wrenches Lifting Tackle (8) 3/4” X 2 1/4” Bolt P# 1312 Crane (2) 3/4” X 3” Bolt P# 1315 (20) 3/4” Flat Washer P# 1603 (10) 3/4” Lock Nut P# 2593 Position Lower Side Panels P# (Listed in illustration.) and secure by installing bushings P# 85765 and securing with bolts P# 1312, washers P#1603 and lock nuts P# 2593.
  • Page 57 Assembly 1325 Bushel Extensions continued Required Hardware Required Tools / Equipment (8) 3/8” X 1” Bolt P# 1206 Wrenches Lifting Tackle (8) 3/8” Whiz Nut P# 2082 Crane (8) 3/8” Flat Washer P# 1598 Connect Lower Side Panels with bolts P# 1209 washers P# 1598 and whiz nuts P# 2082. See Figures 3 and 4.
  • Page 58 Assembly 1325 Bushel Extensions continued Required Hardware Required Tools / Equipment (22) 3/8” X 1” Bolt P# 1206 Wrenches Lifting Tackle (22) 3/8” Whiz Nut P# 2082 Crane (22) 3/8” Flat Washer P# 1598 Position High Side front and rear corner weldments P#85740 and 85741 and secure with bolts P# 1206, washers P#1598 and whiz nuts P# 2082.
  • Page 59 Assembly 1550 Bushel Extensions Required Hardware Required Tools / Equipment Wrenches Lifting Tackle (6) 3/4” X 2 1/4” Bolt P# 1312 Crane (12) 3/4” Flat Washer P# 1603 (6) 3/4” Lock Nut P# 2593 (6) Bushing P# 85765 Position Front End Panel P# 85778 and secure by installing bushings P# 85765 and securing with bolts P# 1312, washers P#1603 and lock nuts P# 2593.
  • Page 60 Assembly 1550 Bushel Extensions continued Required Hardware Required Tools / Equipment (8) 3/4” X 2 1/4” Bolt P# 1312 Wrenches Lifting Tackle (2) 3/4” X 3” Bolt P# 1315 Crane (20) 3/4” Flat Washer P# 1603 (10) 3/4” Lock Nut P# 2593 Position Lower Side Panels P# (Listed in illustration.) and secure by installing bushings P# 85765 and securing with bolts P# 1312, washers P#1603 and lock nuts P# 2593.
  • Page 61 Assembly 1550 Bushel Extensions continued Required Hardware Required Tools / Equipment Wrenches Lifting Tackle (30) 3/8” X 1 3/4” Bolt P# 1209 Crane (30) 3/8” Whiz Nut P# 2082 (30)3/8” Flat Washer P# 1598 (2) Spacers P# 85793 Connect Extension panels LH P# 85771, P# 85785 and P# 85772 with bolts P# 1209 washers P# 1598 and whiz nuts P# 2082.
  • Page 62 Assembly 1550 Bushel Extensions continued Required Hardware Required Tools / Equipment Wrenches Lifting Tackle (40) 3/8” X 1” Bolt P# 1206 Crane (40) 3/8” Whiz Nut P# 2082 (40) 3/8” Flat Washer P# 1598 Position High Side front and rear corner weldments P#85790 and 85791 and secure with bolts P# 1206, washers P#1598 and whiz nuts P# 2082.
  • Page 63 Assembly 2000 Bushel Extensions Required Hardware Required Tools / Equipment Wrenches Lifting Tackle (6) 3/4” X 2 1/4” Bolt P# 1312 Crane (12) 3/4” Flat Washer P# 1603 (6) 3/4” Lock Nut P# 2593 (6) Bushings P# 85765 Position Front End Panel P# 85810 and secure by installing bushings P# 85765 and securing with bolts P# 1312, washers P#1603 and lock nuts P# 2593.
  • Page 64 Assembly 2000 Bushel Extensions continued Required Hardware Required Tools / Equipment (8) 3/4” X 2 1/4” Bolt P# 1312 Wrenches Lifting Tackle (2) 3/4” X 3” Bolt P# 1315 Crane (20) 3/4” Flat Washer P# 1603 (10)3/4” Lock Nut P# 2593 (10) Bushings P# 85765 Position Lower Side Panels P# (Listed in illustration.) and secure by installing bushings P# 85765 and securing with bolts P# 1312, washers P#1603 and lock nuts P# 2593.
  • Page 65 Assembly 2000 Bushel Extensions continued Required Hardware Required Tools / Equipment Wrenches Lifting Tackle (8) 3/8” X 1” Bolt P# 1206 Crane (8) 3/8” Whiz Nut P# 2082 (8) 3/8” Flat Washer P# 1598 Connect Lower Side Panels with bolts P# 1209 washers P# 1598 and whiz nuts P# 2082. See Figures 3 and 4.
  • Page 66 Assembly 2000 Bushel Extensions continued Required Hardware Required Tools / Equipment Wrenches Lifting Tackle (22) 3/8” X 1” Bolt P# 1206 Crane (22) 3/8” Whiz Nut P# 2082 (22) 3/8” Flat Washer P# 1598 Position High Side front and rear corner weldments P#85821 and 85816 and secure with bolts P# 1206, washers P#1598 and whiz nuts P# 2082.

  • Page 67: Lubrication

    Lubrication Pre-Startup The following procedure refers only to initial setup of the Field Floater IV Grain Cart. Refer to Lubrication and Maintenance section of the Field Floater IV Grain Cart manual for normal maintenance operations. The following components must be lubricated to avoid damage to CAUTION the grain cart.
  • Page 68 Lubrication Pre-Startup Continued...
  • Page 69 Lubrication Pre-Startup Continued...
  • Page 70 Lubrication Pre-Startup Continued...

  • Page 71: Testing

    Testing The following initial setup operational tests are to be performed by qualified maintenance personnel prior to delivery to customer. Refer to Field Floater IV Grain Cart manual for further instructions on safety, tractor requirements and in field operations. 1) Attach tractor draw bar to grain cart hitch with properly sized hitch pin that has a retainer device.
  • Page 72 Testing Make sure to have oil in chain oiler reservoir and gearboxes This will ensure proper oiling of chain and gears. Extend upper auger by pushing button. Make sure to have clutch dis-engaged at this point. Rotate swivel head forward and backwards by moving joystick left and right. At this point use a second person to do a visual inspection of the gear and chain.
  • Page 73 Notes —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— ——————————————————————————————————————————————————– ——————————————————————————————————————————————————– ——————————————————————————————————————————————————-...
  • Page 74 Notes —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— —————————————————————————————————————————————————–— ——————————————————————————————————————————————————– ——————————————————————————————————————————————————– ——————————————————————————————————————————————————-...
  • Page 75 County Road 27 East, PO Box 458, Mountain Lake, MN 56159 Phone Number: (800) 795-8551 (800) 727-3133 Main: (507) 427-3133 Fax Number: (507) 427-3640 Website: http://www.balzerinc.com...
