Instructions for Use
Stirrup Dolly 800-0074-S
INTENDED USE & COMPONENT OVERVIEW
Stirrup Dolly is a storage cart used to store components
of our Great White Platinum, Premium, Robotic and
Maxima Stirrups. The intended users of this device are
medical professionals within hospitals and surgery
centers.

INSTRUCTIONS

1. Position stirrup mounting blade as shown. If
mounting blade doesn't face down as shown, squeeze
trigger on handle and it will automatically position
itself.
2. Insert blade completely into blocks mounted on dolly
3. Locate left and right stirrup by label on bottom of
boot
4. Use hook and loop fastener straps provided on dolly to wrap around stirrups and fasten down

GENERAL SPECIFICATIONS

Device Dimensions (maximum)
• Length: 27" +/- 0.5" (69 cm +/- 1 cm)
• Width: 12" +/- 0.5" (31 cm +/- 1 cm)
• Height: 38" +/- 0.5" (97 cm +/- 1 cm)
• Device Weight: 28 +/- 0.5 lbs. (12.7 +/- .22 kg)
• Fully Assembled

GENERAL INFORMATION

• Product not made with Natural Rubber Latex
• Product warranty covers product from manufacturing defects for period of 2 years
• If damaged in shipping, call Customer Service at (888) 724-8763 or (781) 982-7000 to obtain Return
Material Authorization number. For product warranty issues, contact Customer Service.
• CE marked medical device according to MDR (EU) 2017/745
• Product is maintenance-free, check product condition before next use
• Life of device is 5 years under normal use
IFU-800-0074-S REV 3.05
Latest Revision: 2022-01
