Raijintek NYX PRO Quick Start Manual

OPEN FRAME PERFORMANCE MONSTER
4
Screw M3 L10 × 4
For SSD at Bottom
6
Fan Screw × 4
For Fan
8 9
Screw L3.5 × 2 Screw #6-32 L4 × 6
To Lock the Bottom of HDD & SSD For Side Wing
11 12
Allen Key × 1 Velcro × 4
For Screws with Hexagonal Sockets For Cable Tie
14 15
Screw M3 L8 × 12 Screw #6-32 L8 × 6
For SSD on MB Tray For HDD on MB Tray
16
Mounting Tool × 1
For MB Stand-off
17
PCIe - Riser Cable 500mm × 1
For VGA Card
A
Side Wing × 2
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
Nero, Rosso o cerca il tuo prodotto tra le
GLASS
1
Screw #6-32 L6 × 4
For PSU
2
Screw #6-32 L5 × 8
For VGA Holder
3
Stand-off L6 × 3
For Motherboard Tray
PCI CARD
5
Screw #6-32 L10 × 6
For HDD at Bottom
7
1
Screw M3 L5 × 17
For MB Stand-off
10
2
HDD & SSD Rubber Pad × 10
For the Bottom of the HDD & SSD
13
Holder × 2
To Hold VGA Cards
UNFOLDING
1
migliori offerte di Case e Alimentatori
1
2
13
2
13
Raijintek NYX Pro
MOTHERBOARD
2
2
3
13
2
13
2
7
3
