AXA Remote 2.0 S duo set User Manual

AXA Remote 2.0 S duo set
Remote controlled synchronous window openers
Information
You have just acquired a high quality AXA product. The
instructions below must be followed closely in order to
effectively install and operate this product.
88
38
310
Application:
Wide awning and top-hung windows, opening outwards
Package contents
(2x) AAA Batteries
1.
(1x) Adapter
2.
(2x) Closing unit
3.
(2x) Window casing plate
4.
(2x) Drill template
5.
2
1
3
User manual
Remote control (figure ):
A
The remote control has 3 buttons: Open, Stop and Close.
If the Open or Close button is pressed briefly, the window opens
or closes fully.
If the Open or Close button is pressed for longer, the window
opens or closes while the button is kept depressed. If the Stop
button is pressed, the movement stops.
Always point the remote control
closing unit (figure ).
3 B
Configuring the remote control and
synchronising the closing units requires a
specific configuration sequence
1 Insert 2x AAA batteries
(figure ).
C
2 Connect closing unit 1 to closing unit 2 with the
connection lead supplied
3 Connect the adapter lead
Insert the adapter into the power socket (figure
1
26
26
50
(2x) Cover
6.
(2x) Window plate
7.
(2x) Screw hook
8.
(4x) 3.5 x 30 mm screws
9.
4
at the front of the
12
into the remote control
1 12
(figure ).
13 D
to one of the closing units.
2
).
D
EN
Installation tools (recommended):
Tape measure, (cordless) drill, screwdriver, Ø 2 mm drill bit,
pencil or bradawl, screw hook and allen key
Installation location:
min.
30 cm
Awning/top-hung window
max.
100 cm
300 300
mm mm
min. 100 cm, max. 150 cm
Window width: minimum 100 cm - maximum 150 cm
Minimum window height: 30 cm.
Maximum range of remote control: distance 10 m.
10. (18X) 4.0 x 40 mm screws
11. (2x) Allen key
12. (1x) Remote control
13. (1X) 73 cm connection lead
5 7
6
A
Open
Stop
Close
C
EMC 2004/108/EC
Minimum required
installation space:
380 mm
Window
Frame
13
11 10
9
8
B
40 mm
38 mm
12
