永匯豐科技有限公司

Ever Sharp Technology, Inc

ES2088 Rotary Pumping Dispenser Manual

1. Package contains the following items：

ES2088 Rotary Pumping Dispenser

Power Cord

Teflon Tube

Dispensing Pen

Startup Kit

Foot Pedal or Finger Switch

2. Hardware Setup：

a. Connect the Power Cord on the back of the system and switch the power on. Please make sure all the display

and light indicator are working properly. (110V-240V full voltage)

b. Connect the Foot Pedal on the back of the system or Finger Switch on the front of the system.

c. Place the teflon tube inside the rotary pump.

d. Insert the front end of the teflon tube inside the dispensing pen, if you have finger switch please attach it on the

dispensing pen.

Turn on the main power switch before use.

INNOVATION TECHNOLOGY ADVANCES WORKFLOW

(02)2299-5367 ●

http://www.eversharp.com.tw

Need help?

Do you have a question about the ES2088 and is the answer not in the manual?

Page 1 永匯豐科技有限公司 Ever Sharp Technology, Inc ES2088 Rotary Pumping Dispenser Manual 1. Package contains the following items： ES2088 Rotary Pumping Dispenser Power Cord Teflon Tube Dispensing Pen Startup Kit Foot Pedal or Finger Switch 2. Hardware Setup： a. Connect the Power Cord on the back of the system and switch the power on. Please make sure all the display and light indicator are working properly.
Page 2 永匯豐科技有限公司 Ever Sharp Technology, Inc Figure 1 Rotary Pump 3. Control Setting： 1….. Power Button System power, switch on and the power light will light up. 2….. Training Button Press down to active the trainning mode 3….. Dispense Button Press this button to activate the dispensing process 4…..
Page 3 永匯豐科技有限公司 Ever Sharp Technology, Inc 9….. Timer Setting (Up) Increase the number on the timer setting 10…..Function Button Press to switch between Dispense and Reverse timer setting 11…..Timer Setting (Down) Decrease the number on the timer setting 12…..Reverse Time Display Display currently reverse time setting (0.01sec –...
Page 4 永匯豐科技有限公司 Ever Sharp Technology, Inc 7. Troubleshooting： Problem Possible Cause Correction Indicator or • no power input • check power cord connection display does not • PCB main board damage • turn on power light • replace new PCB main board Cannot dispense •...
